Cisco Cisco Certified DevNet Associate 200-901 Questions & Answers

• Question 121:

  Which Cisco network management platform facilitates data center automation across private or public clouds?

  A. Meraki Systems Manager

  B. Cisco DNA Center

  C. SD-WAN

  D. ACI Anywhere

  Correct Answer: D

  Slide 6: https://www.cisco.com/c/dam/m/en_sg/techconnect-webinar/pdfs/aci-anywhere-webinar.pdf

• Question 122:

  Refer to the exhibit. An administrator uses RESTCONF to retrieve the interface configuration of Gi1/0/1. Which URL path retrieves filtered information only for Gi1/0/1?





  A. Option A

  B. Option B

  C. Option C

  D. Option D

  Correct Answer: A

  https://www.cisco.com/c/en/us/td/docs/ios-xml/ios/prog/configuration/1610/b_1610_programmability_cg/restconf_programmable_interface.html

• Question 123:

  A development team needs to containerize an application named 'custapp4o3p2r6d3s6w7x6t9'. A Dockerfile has been created and now the docker build command must be run using the current folder to find the Dockerfile, build the image and create a local repository named 'custapp4d5c-repo' that points to that image. Which command must be used?

  A. docker build custapp4d5c-repo Dockerfile.

  B. docker build -t acustapp4d5c-repo Dockerfile.txt

  C. docker build custapp4d5c-repo -f Dockerfile.txt

  D. docker build -t custapp4d5c-repo -f Dockerfile.

  Correct Answer: D

  Tag an image (-t, --tag) Specify a Dockerfile (-f, --file)

  Source: https://docs.docker.com/engine/reference/commandline/build/

• Question 124:

  Which CI/CD component allows for the storing of code packages and enables the testing of the same code that is running on the live system?

  A. Artifactory

  B. Jira

  C. ITSM

  D. Git

  Correct Answer: A

  "Git is used for source code and Artifactory is used for the binaries which go with the source code." Source: https://foxutech.medium.com/what-is-jfrog-artifactory-its-component-and-features-d0dbe85482ff

• Question 125:

  Refer to the exhibit. A developer has created an XML-based configuration model for a Cisco switch that is going to configure the device using NETCONF. From which configuration is the Interface Ethernet 0/0 deleted when this script is executed?



  A. candidate

  B. startup

  C. current

  D. base

  Correct Answer: C

  https://www.rfc-editor.org/rfc/rfc4741 but the phrasing is not clear.

  "Only the configuration datastore is present in the base model. Additional configuration datastores may be defined by capabilities."

• Question 126:

  Refer to the exhibit.



  An administrator attempts to perform a GET operation by using the Cisco IOS XE RESTCONF API to return the hostname of a device. The sequence diagram in the exhibit illustrates the HTTP messages observed. Which change to the API request resolves the issue?

  A. Remove the -H 'Accept: application/yang-data+json' header.

  B. Replace -u cisco:cisco parameter with -u `cisco:cisco'.

  C. Change the request method from -X `GET' to -X `POST'.

  D. Add the -H `Content-Type: application/yang-data+json' header.

  Correct Answer: B

  There is likely a typo somewhere because quotes are required around the credentials.

  Source: https://www.cisco.com/c/en/us/td/docs/routers/csr1000/software/restapi/restapi/RESTAPIintro.html

• Question 127:

  What is the purpose of a router in a network?

  A. to provide wireless connectivity to a LAN

  B. to filter harmful incoming traffic on a network

  C. to connect multiple networks

  D. to implement network high availability

  Correct Answer: C

• Question 128:

  A web app must be accessible from computers and mobile devices. It must maintain the same data structure on both types of devices. What is the advantage of using the MVC design pattern for this app?

  A. to asynchronously update the graphical interface

  B. to define different algorithms for data manipulation

  C. to separate the logic of the graphic interface of the different devices

  D. to have only one instance of the objects that contain the data

  Correct Answer: C

  The MVC (Model-View-Controller) design pattern is a software architecture pattern commonly used in web development to separate an application into three interconnected components: Model, View, and Controller.

  In this case, using the MVC design pattern can help in separating the logic of the graphic interface of the different devices, as the View component can be customized for the different devices while maintaining the same underlying data structure in the Model component. This can make it easier to maintain and update the application, as changes to the interface of one device will not affect the data or interface of the other devices.

• Question 129:

  A customer's cloud services must:

  1.

  Migrate services to another data center on demand.

  2.

  Save the operational state of the machine on demand.

  3.

  Support Windows and Linux GUIs.

  4.

  Maximize hardware utilization.

  Which type of deployment meets these requirements?

  A. bare metal

  B. container

  C. virtual machine

  D. Kubernetes

  Correct Answer: C

  Windows and Linux GUI is achievable only via Virtual Machine

• Question 130:

  How does edge computing analyze sensitive data in the context of privacy control?

  A. locally instead of sending the data to the cloud for analysis

  B. locally or on the cloud depending on the configuration

  C. all at once by sending the data to the cloud

  D. locally on each node, and then sends the data to the cloud

  Correct Answer: A
