An engineer is implementing a storage area network where an NPV is used. The engineer notices that the servers in a storage farm are experiencing heavy traffic contention. The engineer needs to migrate traffic from heavily loaded server interfaces to interfaces with less load. When the new links are deployed, the existing traffic is not rebalanced as expected.
Which feature must be used to meet these requirements?
A. NPV
B. multiple VSAN support
C. DVM
D. disruptive load balancing
An engineer must design a disaster recovery solution for a Cisco ACI Multi-Site network. One requirement is that the applications must have seamless IP addressing across sites. The solution must also be highly resilient and support Layer 2 adjacency.
Which design meets these requirements?
A. localized bridge domain, subnet, and EPG stretched Layer 2 broadcast domain
B. stretched bridge domain with local subnet stretched Layer 2 broadcast domain
C. localized bridge domain with local subnet localized Layer 2 broadcast flooding
D. stretched bridge domain, subnet, and EPG localized Layer 2 broadcast flooding
An engineer is implementing management access to a Cisco Nexus platform. The customer requires a solution that provides isolation between the data and control planes, in addition to management that uses encryption and authentication. The customer will manage the device using both IPv4 and IPv6.
Which two components should be used to meet these requirements? (Choose two.)
A. mgmt0 interface
B. SSH protocol
C. SNMP
D. SVI interface
E. Telnet protocol
A cloud provider deploys an infrastructure based on Cisco ACI Fabric, Cisco UCS, and Cisco HyperFlex Data Platform. The storage area network will be based on Cisco MDS 9000 Series Switches with Hyper-V, VMware, and KVM used as the virtualization platform. The requirement is to deploy the overall solution by using a robust automation and orchestration tool.
Which tool meets these requirements?
A. Cisco Prime Infrastructure
B. Cisco Network Assurance
C. Cisco UCS Director
D. Cisco Cloud Center
A network architect needs secure access to the organization's perimeter routers and firewalls. The administrator must access network devices from a remote location that is reachable from the WAN cloud
Which action meets these requirements?
A. Create a secure IPsec tunnel interface using an internet link for device management purposes
B. Enable the SSH protocol with a strong username and password using an internet link for management purposes
C. Create an out-of-band network management network
D. Create an in-band network management network
An engineer working for a private telecommunication company with an employee ID 4419 90 979 is installing a pair of Nexus 7000 Series Switches and must deploy the solution with these requirements:
1.
The environment must be separated for test and production purposes
2.
The separation should include control, data and management plane with fault domain isolation and improved security
3.
The test environment needs only F2 series line cards and a maximum of 256 VLANs
Which set of actions meets these requirements?
A. Use VRF faQUMIife environments Configure allow feature set for both VRFs Enable limit-resource vlan minimum for the test VRF
B. Use VDC for each of the environments Configure limit-resource module-type functionality for the test VDC Enable limit resource vlan for the test VDC.
C. Use VDC for each of the environments Configure allow feature set for both VRFs Enable limit-resource vlan maximum for the test VRF
D. Use VRF for each of the environments Configure limit-resource module-type functionality for the test VDC. Enable module-type for the VRF
A customer deploys 32 virtualization hosts in a Cisco UCS domain. All hosts run in the same cluster and have Identical hardware specifications. The operating system requires that all firmware is consistent across the hosts (or driver support.
The customer must provision additional interfaces later for expandability.
Which feature of Cisco UCS Manager meets these requirements?
A. Initial Service Profile Template
B. Initial vNIC Template
C. Updating Service Profile Template
D. Updating vNIC Template
Which type fields can an engineer use to identify an iSCSI participant? (Choose two.)
A. type
B. preshared key
C. port number
D. identifying tag
E. hostname
An engineer must design Layer 2 connectivity for a subnet between two data centers. The engineer must ensure seamless host mobility and optimal first-hop routing. Which attribute must be synchronized across all data centers to achieve this goal?
A. NX-OS version
B. DCNM to manage both fabrics
C. multicast group
D. anycast gateway MAC
A company data center requires a new disaster recovery solution to host critical services. The solution can sustain several hours of data loss because the services are routinely backed up to an offsite location. Also, the disaster recovery solution must provide 24-hour availability. Due to the strict policy requirements, the company wants to retain complete control of when the failover process occurs.
Which solution meets these requirements?
A. active/active
B. hot standby
C. warm standby
D. cold standby
