Cisco CCNP Data Center 300-610 Questions & Answers

• Question 211:

  An engineer must use a template to add Fibre Channel SAN connectivity to Cisco UCS B-Series servers. Any changes made to this template in the future must propagate to all servers. Which template must the engineer choose?

  A. Initial vNIC template

  B. Updating vNIC template

  C. Updating vHBA template

  D. Initial vHBA template

  Correct Answer: C

• Question 212:

  Which orchestration tool must be used to manage VXLAN fabrics and includes a built-in dashboard and d real-time network health summary for managed devices?

  A. Puppet

  B. Cisco Intersight

  C. Cisco Nexus Dashboard Fabric Controller

  D. Ansible

  Correct Answer: C

• Question 213:

  A data center with over 4000 VLANs must be stretched to a disaster recovery site. The solution must support the migration of virtual machines to a disaster recovery site. To support the scalability of the solution, the internal fabric of the main site must be from the DCI network. The connecting network infrastructure uses a 10 Gbps link with PIM ASM supported, which will be replaced with a different overlay in the next 12 months. The solution must support head-end replication for

  broadcast, unknown unicast, and multicast traffic. Which solution must be used to meet these requirements?

  A. LISP

  B. VXLAN Multi-Site

  C. OTV

  D. MPLS over GRE

  Correct Answer: B

• Question 214:

  What must be configured in Cisco Intersight when Enum is selected as the data type in a workflow input?

  A. Widget type

  B. Regex

  C. Secure

  D. Object Selector

  Correct Answer: A

• Question 215:

  An engineer is configuring Fibre Channel policies in a service profile template. The requirement is to set the default vHBA behavior policy as part of the deployment. The Cisco UCS Manager must also create the required vHBA type based on

  the adapter installed on the server and associated with the service profile.

  Which action meets the requirements?

  A. Configure the Windows settings profile.

  B. Enable the HW Inherit settings.

  C. Set the dynamic-uuid identity.

  D. Apply the Linux settings profile.

  Correct Answer: B

• Question 216:

  A Cisco engineer is configuring a customer design scenario that consists of Cisco Nexus 7000 series switches. The remote management access of all the Layer 2 switches is configured on a specific VLAN 12, with subnet 10.0.12.0/24. The route goes through a firewall that has rules to restrict traffic to/from VLAN 12. The engineer is adding a Nexus 3064 with the primary use as a core router for the VLANs. How must the engineer specify the management VRF to use VLAN 12 for management so it is on the same subnet as the rest of the LAN switches?

  A. The L3 SVI on the switch must not accept management traffic.

  B. Configure VLAN 12 on the switch, and add it to the mgmt VRF.

  C. Plug the physical management interface into an access port on VLAN 12.

  D. Create SVI, add management to a new VRF, and keep it in global

  Correct Answer: B

• Question 217:

  Which type of Cisco Intersight workflow input controls the availability of other specific workflow inputs during the execution of a workflow?

  A. Parameter Set rule

  B. String Object Selector

  C. Progressive Disclosure rule

  D. conditional operation

  Correct Answer: C

• Question 218:

  Refer to the exhibit.



  An engineer must design a solution to support a customer's rapidly growing online business. After consulting with the customer, the engineer determined:

  1.

  VXLAN multipod will provide the most optimal Layer 3 transport between web server clusters.

  2.

  Devices should be multihomed in an active/active configuration using LACP.

  3.

  No FEX or virtual switching is needed.

  4.

  vPC will be implemented to maximize throughput and provide redundancy for web server clusters.

  Which feature must the engineer select to support this design?

  A. vPC+

  B. single-sided vPC

  C. enhanced vPC

  D. double-sided vPC

  Correct Answer: D

• Question 219:

  Refer to the exhibit.



  A Cisco engineer is configuring a PBR in a Cisco ACI data center scenario and plans to insert a transparent firewall. The APIC release is 4.1, the Cisco ACI fabric is configured to be the gateway for the servers and for the PBR node, and the Layer 4/ Layer 7 devices are deployed as Layer 1/ Layer 2 mode in the physical domain. Layer 1/Layer 2 PBR node interfaces are also configured to be in a bridge domain and not in an L3Out. What is required for the consumer and provider connectors of the Layer 1/Layer 2 device for this scenario to work?

  A. PBR is used with Multi-Pod.

  B. IP-SLA Tracking is active.

  C. Active/active symmetric PBR is required.

  D. They must be in different BDs.

  Correct Answer: D

• Question 220:

  An engineer must interconnect two data centers to support the dynamic virtual machine migration. The data centers are currently interconnected using an IPv4 network. However, the data plane encapsulation of the underlay network is expected to change next year. To meet the VM migration requirement, the solution must track MAC route changes, update all other remote devices simultaneously and prevent excessive MAC flapping with broadcast and unicast traffic loops. The company must also use networking equipment from different manufacturers to prevent vendor-locking. Which solution meets these requirements?

  A. EoMPLS

  B. OTV

  C. EVPN

  D. VXLAN

  Correct Answer: C
