Cisco CCNP Data Center 300-615 Questions & Answers

• Question 101:

  Refer to the exhibit.



  The EEM script is applied in the default VDC to collect the outputs during high CPU utilization on the Cisco Nexus 7000 Series Switch for all VDCs. Which configuration set must be added to the script to fix the issue?

  A. switch(config-applet)# event snmp 1.3.6.1.4.1.9.9.109.1.1.1.1.6.1 get-type exact entry-op ge entry-val 50 poll-interval 1switch(config-applet)# action 0.2 cli enableswitch(config-applet)# action 0.5 cli switchto vdc Coreswitch(config-applet)# action 0.8 cli switchto vdc Distribution

  B. switch(config-applet)# event snmp 1.3.6.1.4.1.9.9.109.1.1.1.1.6.1 get-type exact entry-op ge entry-val 50 poll-interval 1switch(config-applet)# action 0.2 cli config tswitch(config-applet)# action 0.5 cli switchto vdc Coreswitch(config-applet)# action 0.8 cli switchto vdc Distribution

  C. switch(config-applet)# event snmp oid 1.3.6.1.4.1.9.9.109.1.1.1.1.6.1 get-type exact entry-op ge entry-val 50 poll-interval 1switch(config-applet)# action 0.2 cli config tswitch(config-applet)# action 0.5 cli switchto vdc Coreswitch(config-applet)# action 0.8 cli switchto vdc Distribution

  D. switch(config-applet)# event snmp oid 1.3.6.1.4.1.9.9.109.1.1.1.1.6.1 get-type exact entry-op ge entry-val 50 poll-interval 1switch(config-applet)# action 0.2 cli enableswitch(config-applet)# action 0.5 cli switchto vdc Coreswitch(config-applet)# action 0.8 cli switchto vdc Distribution

  Correct Answer: D

  Need exact snap shot to confirm the following.

  The selection of is due to SNMP command has the key word "oid".

  The command "switchto vdc Core" show run in "enable" mode, not "config t" mode.

  Reference: https://community.cisco.com/t5/networking-documents/eem-script-on-nexus-7000-switches-to-monitor-cpu-utilization/ta-p/3120112

• Question 102:

  An engineer must configure Linux hosts that are deployed on Cisco UCS B-Series Servers to boot from SAN. The SAN boot policy is configured in Cisco UCS Manager, and the boot order is verified to be set as expected. However, the Linux hosts fail to boot. Which action resolves the issue?

  A. Remove all of the local storage that is installed

  B. Delete and reconfigure the pWWN of the SAN boot target

  C. Remove all of the ISO images that are mounted as a virtual CD-ROM

  D. Delete and reconfigure the boot LUN

  Correct Answer: A

  Reference: https://www.cisco.com/c/en/us/td/docs/unified_computing/ucs/sw/cli/config/guide/2-2/b_UCSM_CLI_Configuration_Guide_2_2/configuring_server_boot.pdf page 5

• Question 103:

  Refer to the exhibits.





  An engineer troubleshoots switch N5K1, which fails to receive traffic from the file server Which set of actions resolves this problem?

  A. Bind native VLAN 10 with Ethemet1/10 and allow VSAN 101 in trunk configuration.

  B. Assign native VLAN 10 with vfc111 and allow VLAN 1101 in trunk configuration.

  C. Bind native VLAN 10 with Ethemet10/1/1 and allow VLAN 10 in trunk configuration

  D. Assign native VLAN 10 with fc2.'l - 2 and allow VLAN 10 in trunk configuration.

  Correct Answer: A

• Question 104:

  An engineer enables the packet postcards feature on a Cisco Nexus 9000 Series Switch but receives the error message

  "Error: Cannot configure postcard when inband-telemetry is configured."

  Which action resolves the issue?

  A. Disable the telemetry feature

  B. Disable the software-telemetry feature

  C. Disable the hardware-telemetry feature

  D. Disable the inband-telemetry feature

  Correct Answer: C

  Reference: https://www.cisco.com/c/en/us/td/docs/switches/datacenter/nexus9000/sw/92x/programmability/guide/b-cisco-nexus-9000-series-nx-os-programmability-guide-92x/b-cisco-nexus-9000-series-nx-os-programmability-guide92x_chapter_0100001.html

• Question 105:

  An engineer must upgrade all components in a Cisco UCS domain to the same package version, but the upgrade process fails to complete. Which set of Auto Install actions resolves the problem?

  A. Install Infrastructure Firmware, then Install Server Firmware.

  B. Install infrastructure Firmware, then Install Hypervisor Firmware.

  C. Install Hypervisor Firmware, then Install Infrastructure Firmware

  D. Install Server Firmware, then Install Infrastructure Firmware

  Correct Answer: A

  Reference: https://www.cisco.com/c/en/us/td/docs/unified_computing/ucs/ucs-manager/GUI-User-Guides/Firmware-Mgmt/3-1/b_UCSM_GUI_Firmware_Management_Guide_3_1/ b_UCSM_GUI_Firmware_Management_Guide_3_1_chapter_011.html#concept_4F52361A2A7D4459B64BE93BC9CA566A

• Question 106:

  An engineer must place a Cisco UCS B-Series Server in a single server pool in Cisco UCS Manager. The engineer creates a qualification policy, but the server is still seen in multiple pools. Which two actions resolve the issue? (Choose two.)

  A. Select the Server Pool Policy Qualification from the qualification drop-down menu in the Server Pool Policy

  B. Select the Server Pool Policy from the qualification drop-down menu in the Server Pool Policy Qualification

  C. Set the operating system qualifier inside the Server Pool Policy Qualification

  D. Set the number of vNICs qualifier inside the Server Pool Policy.

  E. Set the storage capacity qualifier inside the Server Poo. Policy Qualification.

  Correct Answer: AC

• Question 107:

  Refer to the exhibit.



  A remote device connected to fc 1/2 fails to come online. Which do you configure to resolve the issue?

  A. remote and local ports to be in the correct VSAN

  B. local switch for NPV

  C. remote device for NPIV

  D. port on remote device as an f-port-channel

  Correct Answer: A

• Question 108:

  Which action do you take to recover a Cisco UCS Director password?

  A. Use SSH to log in to the device, and then reset the password.

  B. Mount the Cisco UCS Director image on a KVM, reload the device, and then reset the password.

  C. Log into the Cisco UCS Director appliance as root, and then run the admin password reset script.

  D. Press CTRL-Break when the system boots, and then configure the config-register command to ignore the current configuration.

  Correct Answer: C

• Question 109:

  Refer to the exhibit.



  The spanning tree is blocking the connection between N9K-DC1-Core-1 and N9K-DC1-Access-1. All ports are up and configured. Which configuration resolves the issue?

  A. Set the pathcost method to long on all three switches

  B. Configure a vPC between N9K-DC1-Core-1 and N9K-DC1-Access-1

  C. Configure LACP between N9K-DC1-Core-1 and N9K-DC1-Access-1

  D. Lower the spanning tree cost on the connection between N9K-DC1-Core-2 and N9K-DC1-Access-1

  Correct Answer: D

• Question 110:

  Refer to the exhibit.



  The VEMs fail to join a Cisco Nexus 1000V Series Switch. You determine that a system VLAN must be set on a system-uplink port profile. Which VLAN do you configure as a system VLAN?

  A. 40

  B. 10

  C. 20

  D. 30

  Correct Answer: B
