Cisco CCNP Data Center 300-635 Questions & Answers

• Question 51:

  What is the network bootstrap program used by Cisco NX-OS iPXE?

  A. NETBOOT

  B. NX-OS iPXE

  C. iPXE-POAP

  D. Mini-OS

  Correct Answer: A

  Reference: https://developer.cisco.com/docs/nx-os/#!pxe-process

• Question 52:

  Refer to the exhibit.



  How often is the subscription stream for sys/bgp going to be sent?

  A. 5 sec

  B. 5 msec

  C. 5000 sec

  D. 5 min

  Correct Answer: A

• Question 53:

  Refer to the exhibit.



  Where and how often does the subscription stream data for Ethernet port 1/1?

  A. to four different destinations every 10000 microseconds

  B. to four different destinations every 100 milliseconds

  C. to four different destinations every 10 seconds

  D. to four different destinations every 10000 seconds

  Correct Answer: C

  Reference: https://www.cisco.com/c/en/us/td/docs/switches/datacenter/nexus3000/sw/programmability/7_x/ b_Cisco_Nexus_3000_Series_NX-OS_Programmability_Guide_7x/b_Cisco_Nexus_3000_Series_NXOS_Programmability_Guide_7x_chapter_011101.pdf

• Question 54:

  When should the API Inspector be used?

  A. to send an API request to the APIC

  B. to learn or identify the sequence of API calls for a specific operation in the APIC GUI

  C. to verify the XML structure of an object based on a specific operation in the APIC GUI

  D. to launch an Ansible playbook

  Correct Answer: B

  Devnet training

• Question 55:

  Refer to the exhibit.



  The code should create a new tenant named Cisco via the Cobra SDK, which shows up after the execution of this script in the APIC dashboard. Which code must he inserted into the red box to create this tenant?

  A. fvTenant = NewTenant(name='Cisco')

  B. tenant = Tenant(topMo. name='Cisco')

  C. fvTenant = Tenant(topMo, name='Cisco')

  D. fvTenant = Tenant('Cisco')

  Correct Answer: C

  Reference: https://cobra.readthedocs.io/en/latest/api-examples/

• Question 56:

  What is a key characteristic of an ACI policy model?

  A. Logical and concrete domains are separated.

  B. All configuration is carried out against concrete entities.

  C. It allows communications with newly connected devices.

  D. Network administrators configure logical and physical system resources directly.

  Correct Answer: A

  Reference:

  https://www.cisco.com/c/en/us/td/docs/switches/datacenter/aci/apic/sw/1-x/aci- fundamentals/b_ACI-Fundamentals/b_ACI-Fundamentals_chapter_010001.html#:~:text=Policy%20Model%20Key%20Characteristics,- Key%20characteristics%

  20ofandtext=As%20a%20model%2Ddriven%20architecture,devices%20attache d%20to%20the%20network.

• Question 57:

  What is the default data encoding for the response output of the ACI APIC API inspector?

  A. CSV

  B. JSON

  C. XML

  D. YAML

  Correct Answer: A

• Question 58:

  Which Kubernetes container network interface provides intent-based networking from the same pane of glass that VMs and bare-metal servers are managed?

  A. ACI CNI plug-in

  B. Contiv CNI plug-in

  C. Ingress CNI plug-in

  D. Calico CNI plug-in

  Correct Answer: D

  Reference: https://docs.projectcalico.org/reference/faq

• Question 59:

  Refer to the exhibit.



  Which two actions does this Python code perform with the Cisco ACI? (Choose two.)

  A. It creates a subnet "DevNet_Subnet" inside VRF "DevNet_VRF" located in ACI tenant "DevNet_Tenant" and sets the scope to "private".

  B. It creates a subnet "DevNet_Subnet" inside AppProfile "DevNet_App" located in ACI tenant "DevNet_Tenant" and sets the network address to "10.10.10.1/24".

  C. It creates an EPG "DevNet_EPG" inside AppProfile "DevNet_App" located in ACI tenant "DevNet_Tenant" and link the EPG with BridgeDomain "DevNet_BD".

  D. It creates a subnet "DevNet_Subnet" inside VRF "DevNet_VRF" located in ACI tenant "DevNet_Tenant" and sets the network address to "10.10.10.1/24".

  E. It creates an EPG "DevNet_EPG" inside VRF "DevNet_VRF" located in ACI tenant "DevNet_Tenant" and link the EPG with BridgeDomain "DevNet_BD".

  Correct Answer: CE

• Question 60:

  Which Python code creates a VRF in an ACI tenant using the Cobra SDK?

  A. Vrf(fvTenant(uniMo, 'CustA'), 'CustA_VRF')

  B. Ctx(Tenant(uniMo, 'CustA'), 'CustA_VRF')

  C. Vrf(Tenant(uniMo, 'CustA'), 'CustA_VRF')

  D. Ctx(fvTenant(uniMo, 'CustA'), 'CustA_VRF')

  Correct Answer: B

  Reference:

  https://community.cisco.com/t5/networking-blogs/learning-aci-programming-the-aci-fabric/ba-p/3659518
