Cisco CCNP Enterprise 350-401 Questions & Answers

• Question 151:

  An organization wants to use the cisco SD-WAN regionalized service-chaining feature to optimize cost and user experience with application in the network, which allows branch routers to analyze and steer traffic toward the required network function. Which feature meets this requirement?

  A. Cloud Services Platform

  B. VNF Service Chaning

  C. Cloud onRamp for Colocation

  D. Cloud onRamp for laaS

  Correct Answer: C

• Question 152:

  What is the difference in dBm when an AP power increases from 25 mW to 100mW?

  A. 75dBm

  B. 150dBm

  C. 6dBm

  D. 125dBm

  Correct Answer: C

• Question 153:

  Which free application make REST call against DNA center?

  A. Postman

  B. Ansible

  C. Chef

  D. Puppet

  Correct Answer: A

• Question 154:

  Which marking field is used only as an internal marking within a router?

  A. QoS Group

  B. Discard Eligibility

  C. IP Precedence

  D. MPLS Experimental

  Correct Answer: A

• Question 155:

  A customer requested a GRE tunnel through the provider network between two customer sites using loopback to hide internal networks. Which configuration on R2 establishes the tunnel with R1?

  A. R2(config)#interface Tunnel1 R2(config-if)#ip address 172.20.1.2 255.255.255.0 R2(config-if)#ip mtu 1500 R2(config-if}#ip tcp adjust-mss 1360 R2(config-if)#tunnel source 192.168.20.1 R2(config-if)#tunnel destination 10.10.1.1

  B. R2(config)#interface Tunnel1 R2(config-if)#ip address 172.20.1.2 255.255.255.0 R2(config-if)#ip mtu 1400 R2(config-if)#ip tcp adjust-mss 1360 R2(config-if)#tunnel source 192.168.20.1 R2(config-if)#tunnel destination 192.168.10.1

  C. R2(config)#interface Tunnel1 R2(config-if)#ip address 172.20.1.2 255.255.255.0 R2(config-if)#ip mtu 1400 R2(config-if)#ip tcp adjust-mss 1360 R2(config-if)#tunnel source 10.10.2.2 R2(config-if)#tunnel destination 10.10.1.1

  D. R2(config)#interface Tunnel1 R2(config-if)#ip address 172.20.1.2 255.255.255.0 R2(config-if)#ip mtu 1500 R2(config-if)#ip tcp adjust-mss 1360 R2(config-if)#tunnel source 10.10.2.2 R2(config-if)#tunnel destination 10.10.1.1Correct

  Correct Answer: C

• Question 156:

  Refer to the exhibit.TCP traffic should be reaching host 10.10.10.10/24 via R2. Which action resolves the issue?



  A. Allow TCP in the access list with no changes to the route map.

  B. Set IP next-hop to 10.10.12.2 under the route-map permit 10 to allow TCP traffic.

  C. Add a permit 20 statement in the route map to allow TCP traffic.

  D. TCP traffic will reach the destination via R2 without any changes.

  Correct Answer: A

  If we add a "permit 20" statement in the route-map then we will allow other traffic to pass through (in fact Policy-based routing allows other traffic to pass through by default). But the bandwidth of R1-R4 is higher than that of R1-R2 so TCP traffic might go through R4 instead of R2. Therefore we should allow TCP in the ACL so that TCP traffic is forwarded via R2.

• Question 157:

  Refer to the exhibit. A network administrator notices these console messages from host 10.11.110.12 originating from interface E1/0. The administrator considers this an unauthorized attempt to access SNMP on R1. Which action prevents the attempts to reach R1 E1/0?



  A. Configure IOS management plane protection using ACL 90 on interface E1/0.

  B. Configure IOS control plane protection using ACL 90 on interface E1/0.

  C. Add a permit statement including the host 10.11.110.12 into ACL 90.

  D. Create an inbound ACL on interface E1/0 to deny SNMP from host 10.11.110.12.

  Correct Answer: D

• Question 158:

  Refer to the exhibit.R4 is experiencing packet drop when trying to reach 172.16.2.7 behind R2. Which action resolves the issue?



  A. Insert a /24 floating static route on R2 toward R3 with metric 254.

  B. Disable auto summarization on R2.

  C. Insert a /16 floating static route on R2 toward R3 with metric 254.

  D. Enable auto summarization on all three routers R1, R2, and R3.

  Correct Answer: B

• Question 159:

  Refer to the exhibit.The control plane is heavily impacted after the CoPP configuration is applied to the router. Which command removal lessens the impact on the control plane?



  A. access-list 120 permit eigrp any host 224.0.0.10

  B. access-list 120 permit ospf any

  C. access-list 120 permit udp any any eq pim-auto-rp

  D. access-list 120 permit tcp any gt 1024 eq bgp log

  Correct Answer: D

• Question 160:

  Refer to the exhibit. R1 and R2 are configured for EIGRP peering using authentication and the neighbors failed to come up. Which action resolves the issue?



  A. Configure a matching key-id number on both routers.

  B. Configure a matching lowest key-id on both routers.

  C. Configure a matching key-chain name on both routers.

  D. Configure a matching authentication type on both routers.

  Correct Answer: B
