Cisco CCNP Collaboration 350-801 Questions & Answers

• Question 201:

  Refer to the exhibit.



  An administrator configures a secure SIP trunk on Cisco UCM. Which value is needed in the Secure Certificate Subject or Subject Alternate Name field to accomplish this task?

  A. the common name of the remote device certificates

  B. the fully qualified domain name of all Cisco UCM nodes that run the CallManager service

  C. the common name of the Cisco UCM CallManager certificate

  D. the fully qualified domain name of the remote device that is configured on the SIP trunk

  Correct Answer: D

  https://video.cisco.com/video/6196744148001

• Question 202:

  A company hosts a conference call with no local users. How does the administrator stop the conference from continuing?

  A. remove the transcoder

  B. modifies the Block OffNet to OffNet Transfer service parameter

  C. changes the codecs that are supported on the conference resource

  D. modifies the Drop Ad Hoc Conference service parameter

  Correct Answer: D

• Question 203:

  Callers from a branch report getting busy tones intermittently when trying to reach colleagues in other office branches during peak hours. An engineer collects Cisco CallManager service traces to examine the situation. The traces show:

  50805567.000 |07:35:39.676 |SdlSig |StationOutputDisplayNotify |restart0 |StationD(1,100,63,6382) |StationCdpc(1,100,64,4725) |1,100,40,7.101980^*^* |[R:N-H:0,N:0,L:0,V:0,Z:0,D:0] TimeOutValue=10 Status=x807 UnicodeStatus= Locale=1 50805567.001 |07:35:39.676 |AppInfo | StationD: (0006382) DisplayNotify timeOutValue=10 notify=`x807' content=`Not Enough Bandwidth' ver=85720014.

  What should be fixed to resolve the issue?

  A. class of service configuration

  B. geolocation configuration

  C. region configuration

  D. codec configuration

  Correct Answer: C

• Question 204:

  An administrator needs to create a partial PRI consisting of the first seven timeslots available. Which configuration snippet configures the ISDN E1 PRI for this task?

  A. config t 2900(config)#isdn switch-type primary-ni 2900(config)#pri-group timeslots 1-7

  B. config t 2900(config)#isdn switch-type primary-ni 2900(config)#controller e1 0/0/0 2900(config-controller)#pri-group timeslots 1-7

  C. config t 2900(config)#isdn switch-type primary-ni 2900(config)#interface Serial0/0/0:15 2900(config-controller)#pri-group timeslots 1-7

  D. config t 2900(config)#isdn switch-type primary-ni 2900(config)#controller e1 0/0/0 2900(config-controller)#pri-timeslots 1-7

  Correct Answer: B

• Question 205:

  Refer to the code.



  Which two codec permutations should be transcoded by this dspfarm?

  A. G.722 to G.729r8

  B. G.729r8 to G.711ulaw

  C. G.729br8 to G.711alaw

  D. iLBC to G.711ulaw

  E. G729ar8 to G.711alaw

  Correct Answer: BE

• Question 206:

  A company's employees have been complaining that they have been unable to select options on the internal IVR of the help desk. IT support has been given Cisco UCM traces and below is the snippet of the SDP of the INVITE packet.

  m=audio 25268 RTP/AVP 18 101 a=rtpmap:0 PCMU/8000 a=rtpmap:18 G729/8000 a=ptime:20 a=fmtp:18 annexb=no a=rtpmap:101 telephone-event/8000 a=fmtp:101 0-15

  How is this issue resolved?

  A. Configure DTMF for KPML.

  B. Configure CODEC for G.729.

  C. Configure DTMF for RFC 2833.

  D. Configure CODEC for G.722.

  Correct Answer: A

• Question 207:

  An administrator works with an ISDN PRI that is connected to a third-party PBX. The ISDN link does not come up, and the administrator finds that the third-part PBX uses the QSIG signaling method. Which command enables the Cisco IOS Gateway to use QSIG signaling on the ISDN link?

  A. isdn switch-type basic-qsig

  B. isdn switch-type basic-ni

  C. isdn switch-type primary-qsig

  D. isdn incoming-voice voice

  Correct Answer: C

  Reference: https://www.cisco.com/en/US/docs/ios/dial/configuration/guide/dia_cfg_isdn_pri_external_docbase_0900e4b1806c752c_4container_external_docbase_0900e4b18216dd1b.html

• Question 208:

  A collaboration engineer troubleshoots issues with a Cisco IP Phone 7800 Series. The IPv4 address of the phone is reachable via ICMP and HTTP, and the phone is registered to Cisco UCM. However, the engineer cannot reach the CLI of the phone. Which two actions in Cisco UCM resolve the issue? (Choose two.)

  A. Enable Settings Access under Product Specific Configuration Layout in Cisco UCM.

  B. Enable FIPS Mode under Product Specific Configuration Layout in Cisco UCM.

  C. Enable SSH Access under Product Specific Configuration Layout in Cisco UCM.

  D. Set a username and password under Secure Shell Information in Cisco UCM.

  E. Disable Web Access under Product Specific Configuration Layout in Cisco UCM.

  Correct Answer: CD

  Enable ssh for phone, and then setup username and password so that engineer can login to phone via CLI

• Question 209:

  Which two steps are required for bulk configuration transactions on the Cisco UCM database utilizing BAT? (Choose two.)

  A. A server template must be created in Cisco UCM.

  B. A data file in Extensible Markup Language format by uploaded to Cisco UCM.

  C. A data file in Abstract Syntax Notation One format by uploaded to Cisco UCM.

  D. A device template must be created in Cisco UCM.

  E. A data file in comma-separated values format must be uploaded to Cisco UCM.

  Correct Answer: DE

  For bulk configuration transactions on the Cisco Unified Communications Manager database, the BAT process uses two components: a template for the device type and a data file in comma separated value (CSV) format that contains the unique values for configuring a new device or updating an existing record in the database. The CSV data file works in conjunction with the device template.

  Reference: https://www.cisco.com/en/US/docs/voice_ip_comm/cucm/bat/9_0_1/CUCM_BK_C22BD805_00_cucm-bulk-administration-guide_chapter_01.pdf

• Question 210:

  An engineer implements a new Cisco UCM based telephony system per these requirements:

  1.

  The local Ethernet bandwidth is sized based on the total bandwidth per call.

  2.

  A G.736 codec is used.

  3.

  The bit rate is 64 kbps.

  4.

  The codec sample interval is 10 ms.

  5.

  The voice payload size is 160 bytes per 20 ms.

  What should the size of the Ethernet bandwidth be per call?

  A. 31.2 kbps

  B. 38.4 kbps

  C. 55.2 kbps

  D. 87.2 kbps

  Correct Answer: D

  To calculate the Ethernet bandwidth per call, we need to take into account the total number of bytes per second in each direction (transmit and receive) and add additional overhead for Ethernet, IP, and UDP headers.

  The total number of bytes per second is calculated as follows:

  160 bytes per 20 ms = (160 bytes/20 ms) x (50 packets/s) = 8000 bytes/s

  The bit rate is 64 kbps, so we need to add an additional 8 kbps for overhead:

  64 kbps + 8 kbps = 72 kbps

  The total number of bytes per second including overhead is:

  72,000 bps / 8 bits per byte = 9,000 bytes/s

  Adding additional overhead for Ethernet, IP, and UDP headers, we can estimate that the total number of bytes per second will be approximately 12,000 bytes/s in each direction. Therefore, the Ethernet bandwidth per call should be:

  12,000 bytes/s x 8 bits per byte = 96 kbps

  Therefore, the correct answer is D. 87.2 kbps is not sufficient to support the required bandwidth per call.
