Cisco CCNP Collaboration 350-801 Questions & Answers

• Question 71:

  Which application traffic does the DiffServ AF41 class according to the Cisco Collaboration System Solution Reference Network Design?

  A. audio call

  B. messaging

  C. video call

  D. signalling

  Correct Answer: C

• Question 72:

  Refer to the exhibit. Which codec should an engineer select for a call mode between "Dallas-REG" and "Austin-REG"?



  A. MP4A-LATM

  B. G.729

  C. OPUS

  D. G.711

  Correct Answer: B

  The codec preference list for the "Dallas-REG" region is "Factory Default low loss". This list includes the following codecs in order of preference:

  G.729

  G.711 OPUS MP4A-LATM The codec preference list for the "Austin-REG" region is "Factory Default low loss". This list includes the following codecs in order of preference:

  G.729

  G.711 OPUS MP4A-LATM Since both regions have the same codec preference list, the codec that will be used for a call made between "Dallas-REG" and "Austin-REG" is G.729. G.729 is a narrowband speech codec that was developed by the ITU-T in 1988. It is a low- bitrate codec that provides good quality speech at a bitrate of 8 kbps. G.729 is widely used in VoIP applications and is the default codec for many VoIP systems. G.711 is a wideband speech codec that was developed by the ITU-T in 1972. It is a high- bitrate codec that provides excellent quality speech at a bitrate of 64 kbps. G.711 is not as widely used as G.729 due to its high bitrate requirements. OPUS is a lossy audio codec that was developed by the IETF in 2012. It is a low-bitrate codec that provides good quality speech at a bitrate of 6 kbps. OPUS is widely used in VoIP applications and is the default codec for many VoIP systems. MP4A-LATM is a lossy audio codec that was developed by the IETF in 1999. It is a high- bitrate codec that provides excellent quality speech at a bitrate of 24 kbps. MP4A-LATM is not as widely used as G.729 or OPUS due to its high bitrate requirements.

• Question 73:

  What does average rate limiting allow?

  A. transmits traffic bursts up to the Bc size

  B. more traffic than the CIR to be sent when there is available bandwidth

  C. bandwidth up to the Be size

  D. traffic to burst to the Be size when there is available bandwidth

  Correct Answer: D

  Reference: https://www.cisco.com/c/en/us/td/docs/ios-xml/ios/qos_plcshp/configuration/15-mt/qos-plcshp-15-mt-book/qos-plcshp-oview.html

• Question 74:

  An engineer must configure a route pattern that can route all +E.164 globalized international numbers for the plans of all countries. Which Cisco UCM configuration accomplish this task?



  A. Option A

  B. Option B

  C. Option C

  D. Option D

  Correct Answer: D

• Question 75:

  Which cisco collaboration Edge architecture product allows remote end points to leverage corporate on- premises cisco Unified communications infrastructure?

  A. Cisco Webex

  B. Cisco VPN Client

  C. Cisco Unified Communications Mobile and Remote Access

  D. Cisco Umbrella

  Correct Answer: C

• Question 76:

  What are two characteristics of priority queueing? (Choose two.)

  A. It guarantees bandwidth for user-defined traffic classes.

  B. It applies strict priority to user-defined traffic classes.

  C. It allocates an equal share of bandwidth to each flow.

  D. It places traffic Into one of four queues.

  E. It ensures that critical traffic queues are serviced first.

  Correct Answer: DE

• Question 77:

  Which two actions must be taken to provision a new device using self-provisioning?

  A. Enable the self-provisioning IVR in the Cisco UCM

  B. Import the user profile to the corporate LDAP directory.

  C. Link the appropriate service profile to the provisioning template.

  D. Link the appropriate universal device template to the user profile.

  E. Ensure the user has a directory URI and a primary extension.

  Correct Answer: AD

• Question 78:

  A collaboration engineer must optimize the dial plan within Cisco UCM. There are multiple remote sites. And each site has its own route patterns and local gateways. What should the engineer do on the cisco UCM to optimize the dial plan?

  A. Configure a Standard Local Route Group to use a single route pattern for all calls within the cluster.

  B. Create a centralized dial plan with a Cisco UCM Session Management Edition cluster or a Cisco gatekeeper.

  C. Implement ILS with GDPR so the dial plan can dynamically replicate across clusters.

  D. Leverage Cisco UCM Express as SRST so the phones can have more features of each remote site

  Correct Answer: A

• Question 79:

  An administrator installs a new Cisco Telepresence video endpoint and receives this error: "AOR is not permitted by Allow/Deny list." Which action should be taken to resolve this problem?

  A. Correct the restriction policy settings.

  B. Change the SIP trunk configuration.

  C. Upload a new policy In VCS.

  D. Reboot the VCS server and attempt reregistration.

  Correct Answer: A

  The error message "AOR is not permitted by Allow/Deny list" indicates that the endpoint is not allowed to register with the VCS server because it is not on the Allow List or it is on the Deny List. To resolve this problem, you must correct the restriction policy settings.

  Reference: https://www.cisco.com/c/en/us/td/docs/telepresence/infrastructure/articles/vcs_endpoint_registration_problems_kb_460.html

• Question 80:

  After an administrator installs the Cisco jabber Client, it fails to register with the cisco UCM server. Which two actions should be taken to troubleshoot this problem? (Choose two.)

  A. Verify the installation of the LMHOST file on the PC

  B. Verify the configuration of the DNS SRV record.

  C. Verify corporate firewall settings for client connections.

  D. Verify Layer 3 connectivity on the gateway.

  E. Reboot the Cisco Unified Border Element Gateway.

  Correct Answer: BC

  Reference: https://www.cisco.com/c/en/us/support/docs/unified-communications/jabber/212471-jabber-login.html
