Avaya ACIS 3605 Questions & Answers

• Question 121:

  Refer to the exhibit.



  A campus network has been established with four Ethernet Routing Switch (ERS) 8600 switches in a switch cluster, two pairs with an Inter Switch Trunks (IST) running Split Multi Link Trunk (SMLT) and Routed Split Multi-Link Trunking (RSMLT). The traffic filters are required to block specific source IP addresses to be forwarded through the core.

  With reference to the exhibit, how should these filters be set up?

  A. Configure the filters on the 1ST first before any other ports.

  B. Apply the filters to all ports that receive traffic from outside the immediate switch cluster.

  C. Configure the filters on the ports first and then the IST.

  D. Configure and apply all the filters on the two core IST links only

  Correct Answer: B

• Question 122:

  A switch with Simple Loop Prevention Protocol (SLPP) did not detect a loop. What are two reasons this occurred? (Choose two.)

  A. SLPP was not globally enabled.

  B. A premier license for SLPP is needed.

  C. SLPP was not enabled on the VLAN where the loop originated.

  D. Extended CP limit on the transmitting port was not configured.

  Correct Answer: AC

• Question 123:

  Which protocol can be used for end-to-end detection in a network as well as for point-to-point detection?

  A. LACP

  B. VLACP

  C. RSTP

  D. MSTP

  Correct Answer: B

• Question 124:

  A university campus network consists of an Ethernet Routing Switch (ERS) 8000 and Ethernet switches. Recently they implemented Routed Split Multi-Link Trunking (RSMLT) over a split Multi- Link Trunk (SMLT) configuration.

  What is the advantage of implementing RSMLT over SMLT?

  A. RSMLT increases the distance of the SMLT core.

  B. RSMLT achieves better data distribution across the SMLT.

  C. RSMLT extends fast failover benefits to the routed portion of the network.

  D. RSMLT allows the addition new users in a separate building.

  Correct Answer: C

• Question 125:

  What is a characteristic of Routed Split Multi-Link Trunking (RSMLT) configuration?

  A. RSMLT is only configured on edge SMLT connections.

  B. RSMI T uses priority values to distinguish between the primary and backup routers.

  C. RSMLT routers are implemented with Virtual Routing Forwarding (VRF)-Lite routers.

  D. RSMLT is always used in conjunction with routing protocols and SMLT connections.

  Correct Answer: D

• Question 126:

  To provide load distribution across two or more equal cost paths in a Layer 3 routing environment, the ECMP feature can be used to maximize load sharing. Which two statements correctly describe the ECMP features? (Choose two)

  A. All ECMP next hop addresses are in the routing table

  B. ECMP keeps traffic between two IP addresses on one single path.

  C. All ECMP paths are active and forwarding traffic.

  D. ECMP routes apply to OSPF, RIP and BGP only.

  Correct Answer: AC

• Question 127:

  When configuring an Ethernet Routing Switch (ERS) 8000 split Multi-Link Trunking (SMLT), protection against an edge switch in the factory default condition must be taken into consideration. Which parameter will help prevent loops on the SMLT ports?

  A. Discarded Untagged Frames

  B. Discard Looped Frames

  C. Spanning Tree Enable

  D. LACP Enable

  Correct Answer: A

• Question 128:

  When configuring link aggregation, a technician created a Distributed Multi-Link Trunk (DMLT) group on the Edge switch to the switch cluster core. What gets distributed?

  A. Access ports

  B. Discard Looped Frames

  C. Spanning Tree Enable

  D. LACP Enable

  Correct Answer: A

• Question 129:

  When configuring LINK aggregation, a technician created a Distributed Multi-Link Trunk (DMLT) group on the edge connecting switch cluster core. What gets distributed?

  A. Access ports

  B. VLANS

  C. Uplinks

  D. PVIDs

  Correct Answer: C

• Question 130:

  When configuring an Ethernet Routing Switch (ERS) 8000 redundant installation for warm standby, which protocol is used to give the fastest recalculation of a large layer 3 topology by the Standby CPU, after a Master CPU failure?

  A. STP

  B. RIP

  C. OSPF

  D. BGP

  Correct Answer: C
