Cisco CCDE 400-007 Questions & Answers

• Question 61:

  Refer to the exhibit.



  This network is running legacy STP 802.1 d. Assuming "hello_timer" is fixed to 2 seconds, which parameters can be modified to speed up convergence times after single link/node failure?

  A. Only the maximum_transmission_halt_delay and diameter parameters are configurable parameters in 802.1d to speed up STP convergence process.

  B. The max_age and forward delay parameters can be adjusted to speed up STP convergence process.

  C. The transit_delay=5 and bpdu_delay=20 are recommended values, considering hello_timer=2 and specified diameter.

  D. Only the transit_delay and bpdu_delay timers are configurable parameters in 802.1d to speed up STP convergence process.

  Correct Answer: B

  Reference: https://www.cisco.com/c/en/us/support/docs/lan-switching/spanning-tree-protocol/19120-122.html

• Question 62:

  An enterprise network has two core routers that connect to 200 distribution routers and uses full-mesh IBGP peering between these routers as its routing method. The distribution routers are experiencing high CPU utilization due to the BGP process. Which design solution is the most cost effective?

  A. Implement route reflectors on the two core routers

  B. Increase the memory on the core routers

  C. Implement e BGP between the core and distribution routers

  D. Increase the memory on the distribution routers

  E. Increase bandwidth between the core routers

  Correct Answer: A

• Question 63:

  Which two actions must merchants do to be compliant with the Payment Card Industry Data Security Standard? (Choose two.)

  A. conduct risk analyses

  B. install firewalls

  C. use antivirus software

  D. establish monitoring policies

  E. establish risk management policies

  Correct Answer: BC

• Question 64:

  Company XYZ has 30 sites running a legacy private WAN architecture that connects to the Internet via multiple high- speed connections The company is now redesigning their network and must comply with these design requirements :

  1.

  Use a private WAN strategy that allows the sites to connect to each other directly and caters for future expansion.

  2.

  Use the Internet as the underlay for the private WAN.

  3.

  Securely transfer the corporate data over the private WAN.

  Which two technologies should be Incorporated into the design of this network? (Choose two.)

  A. S-VTI

  B. IPsec

  C. DMVPN

  D. GET VPN

  E. PPTP

  Correct Answer: CD

  GETVPN alongwith DMVPN can be run over internet, see below: https://lostintransit.se/2016/02/12/ccde-introduction-to-get-vpn-and-get-vpn-design-considerations/?doing_wp_cron=1682702436.4848649501800537109375

• Question 65:

  While reviewing an existing network design, you are discussing the characteristics of different STP versions. Which protocol minimizes unicast flooding during a Topology Change Notification in a Layer 2 switched network with many VLANs?

  A. PVRSTP

  B. MST

  C. STP

  D. PVSTP+

  Correct Answer: A

• Question 66:

  DRAG DROP

  Drag and drop the QoS technologies from the left onto the correct capabilities on the right.

  Select and Place:



  Correct Answer:



• Question 67:

  DRAG DROP

  Drag and drop the design characteristics from the left onto the correct network filter techniques on the right. Not all options are used.

  Select and Place:



  Correct Answer:



• Question 68:

  DRAG DROP

  Drag and drop the end-to-end network virtualization elements from the left onto the correct network areas on the right.

  Select and Place:



  Correct Answer:



• Question 69:

  DRAG DROP

  Drag and drop the optical technology design characteristics on the left to the correct optical technologies on the right. Not all options are used.

  Select and Place:



  Correct Answer:



• Question 70:

  DRAG DROP

  Drag and drop the FCAPS network management reference models from the left onto the correct definitions on the right.

  Select and Place:



  Correct Answer:
