Nokia Nokia Certifications 4A0-C01 Questions & Answers

• Question 91:

  Which of the following statements is TRUE regarding service mirroring?

  A. Mirror slicing is used to logically separate a port that is being monitored.

  B. Mirror slicing configuration is earned out in the mirror destination.

  C. By default, mirror slicing is enabled so that only the protocol headers of data traffic are replicated to a mirror port.

  D. The maximum number of mirror slices that can be made on a network and access port are 256 and 8, respectively

  Correct Answer: B

• Question 92:

  Click the exhibit.



  Which tool produced this output?

  A. ping

  B. Isp-ping

  C. traceroute

  D. Isp-trace

  Correct Answer: B

• Question 93:

  Click the exhibit.



  Part of a 6VPE deployment is shown in this exhibit. Which of the following is the correct configuration and context on PE1 for a BGP peering session with CE1?



  A. Option A

  B. Option B

  C. Option C

  D. Option D

  Correct Answer: A

• Question 94:

  Which of the following about F-pipes is FALSE?

  A. F-pipes use SAPs in the form of port: DLCI (e.g. 1/2/3:65).

  B. To the customer, the PE appears as a native Frame Relay UNI (User Network Interface).

  C. Multiple Frame Relay circuits can be mapped to a single F-pipe service on the Alcatel- Lucent 7750 SR.

  D. The MPLS control word is required because the Frame Relay header is not encapsulated in the frame.

  Correct Answer: C

• Question 95:

  Click the exhibit.



  Routes are exchanged between CE1 and PE1 using BGP. CE2 and PE2 use static routes to forward traffic to and from the VPRN. Which of the following is FALSE?

  A. An export policy is required on PE1 to advertise routes to CE1.

  B. An export policy is required on CE1 to advertise local routes to PEL

  C. An export policy is required to advertise routes between the PE routers.

  D. No export policy is required on PE2 or CE2 due to the static routes.

  Correct Answer: C

• Question 96:

  Which one of the following items CANNOT be used as a mirror source on an Alcatel-Lucent 7750 SR?

  A. IP filter

  B. MAC filter

  C. Egress label

  D. Ingress label

  Correct Answer: C

• Question 97:

  Click the exhibit.



  Assuming CE1 exports its system address using BGP, is a routing policy required on PE1 to advertise CE1's system address to PE2?

  A. Yes, A routing policy is required to advertise routes between PE routers in a VPRN regardless of the CE-PE routing.

  B. Yes, A routing policy is required in this case because BGP is used as the PE-CE routing protocol.

  C. No, a routing policy is not required. By default, the Alcatel-Lucent 7750 SR will advertise all VPRN routes between PE routers.

  D. No, a routing policy is not required on PE1, but an import policy is required on PE2.

  Correct Answer: C

• Question 98:

  Which of the following statements about SAPs that are part of a VPVVS is FALSE?

  A. SAPs can be defined on Ethernet, POS, Sonet/SDH, or TDM channels.

  B. Only one SAP is required for a service that originates and terminates on the same Alcatel-Lucent 7750 SR.

  C. SAPs can have QoS policies assigned to them.

  D. Multiple SAPs can be defined on the same port.

  Correct Answer: B

• Question 99:

  Click the exhibit.



  R1 and R4 are providing a VPRN for the CEs. Which of the following about the traceroute run on router R5 is TRUE?

  A. The traceroute will only show one hop: R5-R6.

  B. The traceroute will only show 2 hops; R5-R1 and R4-R6.

  C. The traceroute will only show 3 hops: R5-R1, R1-R4 and R4-R6.

  D. The traceroute will show one hop for each router in the provider core and one for each CE-PE hop.

  Correct Answer: C

• Question 100:

  A VPRN service is configured with BGP used as the CE-PE routing protocol. What address families are required on the PE-CE BGP session?

  A. VPN-IPv4 address families are required in order for routes to be exchanged with the PE.

  B. Only default IPv4 address families are required since the CE is not aware of the VPRN service

  C. Either IPv4 or VPN-IPv4 address families can be configured on the PE-CE BGP session

  D. An IPv4 address family configuration is required for the PE-PE configuration.

  Correct Answer: B
