Nokia Nokia Certifications 4A0-C01 Questions & Answers

• Question 411:

  Which of the following commands is used to disable an Epipe service?

  A. config>service# epipe service-id shutdown

  B. config>service# vpws service-id shutdown

  C. config>service# service-id shutdown

  D. config>port# port-id shutdown.

  E. config>service# epipe service-id disable

  Correct Answer: A

• Question 412:

  Which of the following are the default settings for the Alcatel-Lucent 7750 SR when using LDP?

  A. Per-platform label space, conservative retention mode

  B. Per-interface label space, conservative retention mode

  C. Per-platform label space, liberal retention mode

  D. Per-interface label space, liberal retention mode

  Correct Answer: C

• Question 413:

  Click on the exhibit button below.



  Assuming the customer only needs to monitor traffic from PE3 to the customer site, what two items are missing in the configuration of PE5, the Alcatel-Lucent 7750 Service Router in the Head Office? (Assume that the IP/MPLS network structure between the local and remote PEs is in place.)

  A. The mirror destination configuration on PE5 is missing the "remote-source" command.

  B. There needs to be a mirror source configuration on PE5 with the "remote-source" command.

  C. This is not possible since the protocol analyzer is located at the Central Office. It needs to be at the customer site.

  D. There needs to be a configuration command to put sap 1/1/3 on the mirror destination of PE5.

  E. There needs to be a configuration command to put sap 1/1/3 on the mirror source of PE5

  Correct Answer: AD

• Question 414:

  When configuring an IES spoke termination to a VPLS, what must be explicitly configured in order for the service to come up? (Choose 2)

  A. MTU must match on both services,

  B. Mesh-SDP with matching vc-id configured,

  C. Spoke-SDP with matching vc-id configured.

  D. Spoke-SDP.

  Correct Answer: AC

• Question 415:

  Click on the exhibit.



  An LDP-over-RSVP tunnel is established between PE-1 and PE-2. Which of the following is NOT required to protect the LDP-over-RSVP tunnel?

  A. PE-1 requires T-LDP sessions to both ABR-1 and ABR-2.

  B. PE-1 requires a full mesh of RSVP-TE LSPs to all routers in area 1.

  C. ABR-1 requires T-LDP sessions to all ABRs in area 0.

  D. PE-1 requires fast reroute enabled on all RSVP-TE LSPs.

  Correct Answer: B

• Question 416:

  Which of the following statements is FALSE regarding 6VPE?

  A. 6VPE is a tunneling technology that makes use of MPLS tunnels to transport IPv6 information over an IPv4 MPLS infrastructure.

  B. Customers connected to 6VPE could run native IPv6 or IPv4.

  C. On the PE router, the next hop for a VPN IPv6 address is an IPv6 address, regardless of the nature of the network between the PEs.

  D. 6VPE requires an IPv6-aware MPLS core.

  E. Both C and D are false.

  F. All of the above statements are true.

  Correct Answer: D

• Question 417:

  What are the default settings for RSVP-TE on the Alcatel-Lucent 7750 SR?

  A. Per-interface label space, liberal retention mode

  B. Per-platform label space; liberal retention mode

  C. Per-interface label space, conservative retention mode

  D. Per-platform label space, conservative retention mode

  Correct Answer: D

• Question 418:

  Which of the following statements is TRUE concerning a VPRN data plane flow?

  A. A data packet will receive a service label at the CE and a transport label at the ingress PE.

  B. A data packet intended for a remote CE will have its service label swapped at each P router along the path towards the egress PE.

  C. At the egress PE, the transport label will be popped and the data packet forwarded with the service label.

  D. The service label is popped by the remote CE. The unlabeled packet is forwarded based on the longest match lookup algorithm in the VRF.

  E. All of the above statements are false.

  F. All of the above statements are true.

  Correct Answer: E

• Question 419:

  Which of the following best describes a VPRN?

  A. Layer 3 direct Internet access service.

  B. Layer 2 point-to-point service.

  C. Layer 2 multipoint-to-multipoint service.

  D. Layer 3 IP multipoint-to-multipoint VPN service.

  Correct Answer: D

• Question 420:

  Which of the following about the Link LDP discovery process on the Alcatel-Lucent 7750 SR is FALSE?

  A. LDP Hello messages are sent over TCP.

  B. LDP Hello messages are sent to the All Routers address 224.0.0.2.

  C. LDP Hello messages are exchanged between all directly connected LDP enabled routers.

  D. Each LDP enabled router must have its own unique system IP address.

  Correct Answer: A
