• Question 451:

  Which of the following statements are TRUE regarding a fully meshed VPLS service with a default setting? (Choose 3)

  A. The vc-id on the mesh-sdp must be explicitly configured.

  B. The vc-id on the mesh-sdp is automatically assigned by a PE using the service id.

  C. The VPLS service id, on all PE routers, does not have to match.

  D. The VPLS service id, on all PE routers, must match.

  E. If dynamic signaling is required, the signaling on all PE routers must be set to TLDP in the configuration of the SDPs.

  F. The signaling on all PE routers will default to TLDP in the configuration of the SDPs; therefore, no configuration change is required for dynamic signaling.

  Correct Answer: ADF

• Question 452:

  Which of the following statements is FALSE regarding SAPs?

  A. VPWS: SAPs can be defined on Ethernet, POS, Sonet/SDH, or TDM channels.

  B. VPWS: Two SAPs are defined for a service that originates and terminates on the same Alcatel-Lucent 7750 SR

  C. VPLS: More than two SAPs can be defined in a service.

  D. VPWS: SAPs are associated with an IP interface.

  Correct Answer: D

• Question 453:

  Click on the exhibit.



  This policy is applied as an LDP export policy. In addition to the FECs learned from its neighbors, which FECs will appear in this router's LIB?

  A. All FECs with a prefix of 192.168.1.0/30.

  B. Local FECs with a prefix of 192.168.1.0/30.

  C. All FECs excluding 192.168.1.0/30.

  D. Local FECs excluding 192.168.1.0/30.

  Correct Answer: D

• Question 454:

  Click on the exhibit.



  The link between routers R4 and R6 are configured with an admin group "red". What happens when the LSP is first signaled?

  A. The LSP will go through the path R1-R2-R4-R6.

  B. The LSP will go through the path R1-R3-R5-R6.

  C. The LSP is down because router R1 detects that no path can meet its constraints.

  D. The LSP is down because router R4 detects that no path can meet its constraints.

  Correct Answer: C

• Question 455:

  Click on the exhibit.



  All links are operationally up initially. When the link between routers R4 and R6 goes down, what will router R1 do?

  A. Router R1 will switch traffic to the secondary path immediately.

  B. Router R1 will discard traffic until a new IGP route to router R6 is re-calculated.

  C. Router R1 will discard traffic because the secondary path is not a fully strict path.

  D. Router R1 will signal the secondary path and switch traffic to it.

  Correct Answer: D

• Question 456:

  An Alcatel-Lucent 7750 SR label switches a packet it receives. The packet has an outer label TTL of 250 and an inner label TTL of 251. Which of the following is TRUE?

  A. The outer label TTL will be 249 and the inner label TTL will be 250.

  B. The outer label TTL will be 249 and the inner label TTL will be 251.

  C. The outer label TTL will be 251 and the inner label TTL will be 251.

  D. The outer label TTL will be 251 and the inner label TTL will be 252.

  Correct Answer: B

• Question 457:

  Which of the following commands is required to configure an Ethernet port to be used as a SAP in a service?

  A. Configure service sap sap-id access

  B. Configure port port-id Ethernet mode access

  C. Configure port port-id Ethernet mode network

  D. Configure port port-id mode access

  E. Configure port port-id mode network

  Correct Answer: B

• Question 458:

  Which of the following is NOT an advantage of RSVP-TE compared to LDP?

  A. RSVP-TE supports Connection Admission Control (CAC).

  B. RSVP-TE enables simplified configuration of LSPs.

  C. RSVP-TE supports path calculations that do not use IGP cost.

  D. RSVP-TE provides support for traffic protection features.

  Correct Answer: B

• Question 459:

  Click on the exhibit.



  Which of the following CANNOT be used to ensure the LSP toR6" will follow the path R1- R2-R4-R6?

  A. Admin groups

  B. Hop-limit

  C. Strict hops

  D. TE-Metric

  Correct Answer: B

• Question 460:

  Which of the following about RSVP-TE summary refresh messages is TRUE?

  A. They list the RSVP session names that the router is refreshing,

  B. They list the Message IDs that the router is refreshing,

  C. They list the Tunnel IDs that the router is refreshing.

  D. They list the LSP I Ds that the router is refreshing.

  Correct Answer: B
