HP HP ExpertONE Certification HP0-J64 Questions & Answers

• Question 61:

  The CTO for a healthcare IT company just returned from HP Discover. They would like a presentation about the HP StoreServ family of arrays. The company has one data center with servers and storage. Government regulations require the company to have one copy of patient data in the data center and two additional copies.

  The company utilizes Amazon Storage Services to retain the two additional copies due to their data center limitations. The current array also failed to recover from a controller failure three months ago. Which HP value proposition will increase data availability and efficiency for the customer?

  A. HP Remote Copy software

  B. HP Autonomic storage provisioning and data tiering

  C. HP Peer Motion

  D. HP 3PAR Mesh-Active clustering and persistent cache

  Correct Answer: D

  Mesh-Active Controller Design All HP 3PAR Storage Systems feature a unique Mesh-Active design as part of a next-generation architecture designed for virtual and cloud data centers. Unlike legacy "active-active" controller architectures -- where each volume is active on only a single controller -- this Mesh-Active design allows each volume to be active on every controller in the system. The result is robust, load-balanced performance and greater headroom for costeffective scalability that is designed to overcome the tradeoffs associated with modular and monolithic storage systems. A high-speed, full-mesh, passive system backplane joins multiple Controller Nodes to form a cachecoherent, active-active cluster that represents the next generation of Tier 1 Storage. http://h20195.www2.hp.com/v2/GetPDF.aspx/4AA2-9918ENW.pdf

• Question 62:

  A customer has an HP BladeSystem c7000 with HP Virtual Connect Flex-10 modules interconnect bays 1 and 2. The customer wants to install an HP Proliant BL460c Server Blade with no options. Which Feature is unavailable to the customer with this configuration?

  A. Fibre Channel

  B. Ethernet

  C. iSCSI

  D. VLANs

  Correct Answer: A

  http://h18004.www1.hp.com/products/quickspecs/13127_div/13127_div.pdf http://h18000.www1.hp.com/ products/quickspecs/productbulletin.html#spectype=worldwideandty pe=htmlanddocid=13127

  Overview HP Virtual Connect Flex-10 10Gb Ethernet Module for c-Class BladeSystem

  Simplify and make your data center change-ready. The HP Virtual Connect Flex-10 10Gb Ethernet Module for the c-Class BladeSystem is the simplest, most flexible connection to your networks. The Virtual Connect Flex-10 Ethernet Module is a new class of blade interconnect that simplifies server connections by cleanly separating the server enclosure from LAN, simplifies networks by reducing cables without adding switches to manage Virtual Connect wire-once connection management allows you to change servers in just minutes, not days, and tailors network connections and speeds based on application needs. HP Flex-10 technology significantly reduces infrastructure costs by increasing the number of NICs per connection without adding extra blade I/O modules, and reducing cabling uplinks to the data center network. The HP Virtual Connect Flex-10 10Gb Ethernet Module for c-Class BladeSystem is an innovative, new class of integrated interconnects from HP.



• Question 63:

  A regional market leader in direct financial services runs several call centers across the United States and is opening a number of new call centers in the near future. The client uses Windows XP on dedicated workstations. The IT infrastructure consists of numerous HP Proliant HP DL360 G5 and HP Proliant DL380 G6 servers running VMware ESX or Windows 2003, direct- attached storage, and Hp Ultrium tape drivers.

  Which HP storage and virtualization solution should be designed to support the customer IT infrastructure roadmap for client virtualization?

  A. HP 3PAR StoreServ 7000 with KVM

  B. HP EVA P6000 with VMs

  C. HP StoreVirtual 4000 with VMware View

  D. HP StoreSure 2000 with XenDesktop

  Correct Answer: D

  A. kernel-based virtual machine (KVM)

  B. virtual machine(s) VMs

  C. VMware?Horizon ViewTM (formerly VMware View) is a virtual desktop infrastructure solution that simplifies desktop management and provides users with what they need, when they need it. D. Citrix XenDesktop is the award winning solution for virtual desktop delivery and apps on demand. XenDesktop delivers virtual apps and desktops on a single unified platform, providing self- service access for users and simplified management for IT. D. HP StoreSure 2000 Modular Smart Array (MSA) solutions 2312fc, 2324, and P2000 and focuses on implementing and managing an MSA SAN solution.



  C. HP StoreVirtual 4000 http://www8.hp.com/pt/pt/products/disk-storage/product-detail.html? oid=4118659#!tab=features Question possibility are HP StoreVirtual 4000 with VMware View, but



  http://h20195.www2.hp.com/v2/GetPDF.aspx%2F4AA2-5654ENW.pdf

• Question 64:

  An advantage of using HP StoreOnce Catalyst with the HP StoreOnce B6200 Backup System is a reduction in bandwidth between which two components?

  A. the HP StoreOnce B6200 Backup System and the tape library

  B. the media server and the client

  C. the HP StoreOnce B6200 Backup System and the client

  D. the media server and the HP StoreOnce B6200 Backup System

  Correct Answer: D

  http://h20195.www2.hp.com/V2/GetDocument.aspx?docname=4AA4-4480ENWandcc=usandlc=en http:// www.conres.com/stuff/contentmgr/files/0/a1d681554de12de089adc5229589f778/downloa d/ hp_storeonce_catalyst_best_practice_release1.pdf

• Question 65:

  Which tool helps a customer determine if the interoperability of their bill of materials (BOM) is supported by HP?

  A. HP Sizing and Configuration Tool

  B. HP Single Point of Connectivity Knowledge(SPOCK)

  C. HP SAN Designer

  D. HP Storage Product Selector

  Correct Answer: B

  http://h71028.www7.hp.com/enterprise/us/en/solutions/storage-tools.html

  HP Sizer for Microsoft Exchange Server 2010 Microsoft?Exchange Server 2010 is a complex application that requires intensive knowledge of deployment strategies, interdependencies, server and storage performance related issues. HP has developed the HP Sizer for Microsoft Exchange Server 2010 to assist customers with proper server and storage sizing for their Exchange Server 2010 deployments. The algorithms developed and implemented in this tool are based upon extensive testing of Exchange Server 2010 server roles and technologies, HP's deep experience with Microsoft Exchange, and intricate knowledge of server CPU, memory, and I/O subsystems. This tool is free to download and use, and is designed to simplify configuration across a broad range of deployments. This newest Microsoft Exchange Server Sizer provides support for multiple site deployments, varied client types and access methods, all Exchange Server 2010 server roles, Database Availability Group (DAG) high availability options, choice of tower, rack mounted, or HP BladeSystem server platforms, and either direct attached or SAN-based storage solutions. Based on your input, the tool provides a comprehensive bill of materials along with a deployment overview of the Exchange Server 2010 server roles and storage configurations. Once this Sizer is installed, updates can be downloaded automatically to the underlying software engines that are necessary to provide support for HP server and storage product information details.

• Question 66:

  The customer wants to implement an HP StoreOnce soltuion for the environment show. You have been given the following information:

  Each branch office has approximately 100 GB of data.

  Philadelphia has approximately 2 TB data.

  Pittsburg has approximately 1 TB data.

  All backup data will be replicated back to the data center in Pittsburg.

  Costs should be kept to a minimum but allow for the possibility of adding three more sites. Which HP StoreOnce solution should you propose for pittsburg?



  A. HP StoreOnce B6200 Backup

  B. HP StoreOnce 4220 Backup

  C. HP StoreOnce 4420 Backup

  D. HP Storeonce 2620 Backup

  Correct Answer: B

  Replication Licensing:

  HP delivers replication by license, either as a standalone replication solution, or as part of the HP StoreOnce Catalyst licensing (see the following section below). With HP StoreOnce Backup, replication is licensed by VTL/NAS target, this

  means that with one replication license:

  1 source appliance can replicate to a single HP StoreOnce VSA* 8 source appliances can replicate to a single HP StoreOnce 2620 24 source appliances can replicate to a single HP StoreOnce 4210 or 4220 50 source appliances can

  replicate to a single HP StoreOnce 4420 or 4430 96 source appliances can replicate to a single HP StoreOnce B6200 48 TB target http://h18004.www1.hp.com/products/ quickspecs/14450_div/14450_div.pdf

  In this time you have 8 source appliances can replication and future you need adding three more sites. (8 + 3= 11 minimum source)

• Question 67:

  Which HP 3PAR InForm Operating System feature provides Tier 1 resiliency and allows for non-disruptive online software upgrades on HP 3PAR StoreServ Storage systems without replying on multipathing software?

  A. HP 3PAR Autonomic Rebalance

  B. HP 3PAR Access Guard

  C. HP 3PAR Persistent Cache

  D. HP 3PAR Persistent Ports

  Correct Answer: D

  http://h20195.www2.hp.com/V2/GetPDF.aspx%2F4AA3-2542ENW.pdf

  HP 3PAR Persistent Ports HP 3PAR Persistent Ports is another Tier 1 resiliency feature that provides non-disruptive online software upgrades on HP 3PAR StoreServ Storage without relying on multipathing software to initiate failover. This feature, available on all HP 3PAR StoreServ models, brings Tier 1 resiliency across the 3PAR StoreServ product line, including midrange models, by helping to ensure that host paths remain online throughout the software upgrade process. The use of standard NPIV (N_Port ID Virtualization) technology enables a single host-facing 3PAR StoreServ port to assume the identity of additional predesignated partner ports, thus enabling transparent switchover of host path connections.

• Question 68:

  A customer is interested in replacing their old storage arrays with HP 3PAR StoreServ StoreServ storage arrays. They are very concerned about data availability primary benefit that should be considered?

  A. mainframe support

  B. automated tiering

  C. clustered architecture

  D. static management

  Correct Answer: C

  http://h20195.www2.hp.com/V2/GetPDF.aspx%2F4AA3-2542ENW.pdf

  HP 3PAR StoreServ Architecture The tightly clustered, multi-tenant HP 3PAR StoreServ Architecture allows you to start small and grow as you go, adding new applications and workloads affordably and nondisruptively--all within a single, autonomically tiered, flash-optimized array HP 3PAR ASIC with Thin Built In Flash-optimized architecture featuring a Mesh-Active design Fine-grained virtualization and system-wide striping HP 3PAR Persistent Cache HP 3PAR Persistent Ports



• Question 69:

  A customer has these servers in their IT environment. .1 Exchange server .6 SQL database servers .5 file servers .16 application servers

  The customer is using an HP StoreOnce Backup System to back up their data. To achieve the best deduplication ratio/performance compromise, how many virtual libraries should be created?

  A. 1

  B. 4

  C. 5

  D. 13

  Correct Answer: B

  http://www.manualslib.com/manual/484560/Hewlett-Packard-D2d.html?page=7 Key factors for performance considerations with deduplication:

  The inline nature of the deduplication process means that there will always be some performance trade-off for the benefits of increased disk space utilization.

  With each Virtual Library or NAS Share created there is an associated dedicated deduplication deduplication across all backups is required, this will only happen if a single store. If Global virtual library or NAS share is configured and all

  backups are sent to it. The best deduplication ratio will be achieved by configuring a minimum number of libraries/shares. Best performance will be gained by configuring a larger number of libraries/shares and optimising for individual

  deduplication store complexity. If servers with lots of similar data are to be backed up, a higher deduplication ratio can be achieved by backing them all up to the same library/share. If servers contain dissimilar data types, the best

  deduplication ratio/performance compromise will be achieved by grouping servers with similar data types together into their own dedicated libraries/shares. For example, a requirement to back up a set of exchange servers, SQL database

  servers, file servers and application servers would be best served by creating four virtual libraries or NAS shares; one for each server set.

  When restoring data from a deduplicating device it must reconstruct the original un-deduplicated data stream from all of the data chunks. This can result in lower performance than that of the backup. Full backup jobs will result in higher

  deduplication ratios and better restore performance (because only one piece of media is needed for a full restore). Incremental and differential backups will not deduplicate as well

• Question 70:

  You are responding to a request for proposal (RFP) for a new HP 3PAR StoreServ array. The company decision-market has asked you to justify the cost of the array. Which benefits of the Alinean ROI Analysts should be included in the business case to justify the cost of the array (Select three)

  A. regulatory documentation

  B. payback period

  C. competitive data

  D. internal rate of return (IRR)

  E. value proposition

  F. architecture of the array

  Correct Answer: BDE

  http://www.certificationexplorer.com/Documents/HP0-J64.pdf
