HP HP ExpertONE Certification HP0-J66 Questions & Answers

• Question 31:

  A customer network environment has the following components:

  -HP ProLiant rack-mounted servers

  -Microsoft Hyper-V virtualization

  -

  a third-party storage system

  The customer plans to implement an HP 3PAR StoreServ 7000 Storage System.

  A.

  SmartStart server

  B.

  physical Service Processor

  C.

  Windows Server 2012

  D.

  virtual Service Processor

  Correct Answer: C

  Setting Up a Windows Hyper-V Server/HP 3PAR StoreServ Storage Configuration Required is a Windows server with an x64-based processor running an x64 version of Windows Server 2012, Windows Server 2008 Standard, Windows Server 2008 Datacenter, Windows Server 2008 Enterprise (SP1, SP2), or Windows Server 2008 R2 Server.

  Incorrect: Not A, not B, not D: No particular parameters need to be set in the Hyper-V software to work with the HP 3PAR StoreServ Storage; no additional steps are necessary on the HP 3PAR StoreServ Storage to work with a Windows Hyper-V server

  Reference; HP 3PAR Windows Server 2012 and Windows Server 2008 Implementation Guide

• Question 32:

  A customer needs to be able to perform an instant recovery of database data files. The recovery point is one hour to enable them to have a specified point time to restore the data if the data migration fails. Which form of data replication enables the customer to achieve this goal?

  A. volume clones

  B. backups to disk

  C. asynchronous replication

  D. snapshots

  Correct Answer: B

• Question 33:

  A company has a first-generation deduplication appliance and is considering adding an HP StoreOnce 6200 Backup System to its environment. Which benefits can this company realize by deploying an HP StoreOnce 6200 Backup System? (Select two.)

  A. can scale up to 784 TB of usable storage

  B. federated non-disruptive data mobility between third-party systems

  C. deduplicates data anywhere without the need for rehydration

  D. performance throughput of 200 TB/hour

  E. automatic failover on couplet failure

  Correct Answer: CE

  The HP B6200 StoreOnce Backup System provides:

  *

  Deduplication to drive more efficient storage of data

  *

  Large device scalability to ensure every backup has access to devices and, so, reduce queuing time

  *

  In-built low bandwidth replication for cost-effective copies of data offsite as part of a Disaster Recovery plan

  *

  HP Autonomic failover (with appropriate ISV software) to allow backups to continue, even if a node in an HP B6200 StoreOnce Backup System fails.

  *

  High scalability in terms of capacity, performance and replication to ensure the system grows as your business grows.

  Incorrect: Not A: Capacity: 48TB Raw 32TB Useable Scalable to 192 TB Raw 128 TB Useable

  Not C:

  *

  HP StoreOnce Catalyst delivers industry-leading backup speeds of up to 100TB/hour to meet shrinking backup windows.

  *

  Transfer rate 100 TB/hr; Maximum, depending on model

• Question 34:

  A customer is migrating data from a third-party storage system to an HP 3PAR StoreServ 7000 Storage System. They want the new storage system to contain 480 disk drives at minimal cost.

  A. two HP 3PAR StoreServ 7200 storage systems

  B. one HP 3PAR StoreServ 7400 two-node storage system

  C. one HP 3PAR StoreServ 7400 four-node storage system

  D. one HP 3PAR StoreServ 7200 storage system

  Correct Answer: C

  HP 3PAR StoreServ 7400 Number of disk drives: 8-480 drives Number of controller nodes: 2 or 4

  This model offers up to 4-node architecture with up to 480 drives (SSD, SAS, NL).

  Incorrect: Not A, not D: HP 3PAR StoreServ 7200 Number of disk drives: 8-144 drives

• Question 35:

  A storage administrator plans to migrate data from an HP EVA4400 to an HP 3PAR StoreServ 7000 Storage System. The administrator needs to ensure that after the upgrade, in the event of a failure, hosts can access data replicated to another HP 3PAR without disruption.

  Which licensed option of the HP 3PAR StoreServ 7000 Storage System provides this capability?

  A. SmartStart

  B. Peer Persistence

  C. Virtual Service Processor (VSP)

  D. N_Port ID Virtualization (NPIV)

  Correct Answer: B

  HP 3PAR Peer Persistence Software allows you to break the boundaries of storage, enabling your hosts, and data to move freely across data centers without impacting your business applications. It helps you in implementing a true cloud solution, where storage resources are shared across data centers, and are not constrained by their physical boundaries. Peer Persistence enables 3PAR systems located at metropolitan distances to act as peers to each other, presenting a nearly continuous storage system to hosts and servers connected to them.

  This capability allows customers to configure a high-availability solution between two sites or data centers where switchover and switchback remains transparent to the hosts and applications running on those hosts. This secures business continuity without impacting performance and enables load balancing putting investments at both the data centers to optimal use.

  Incorrect: Not A:

  *

  SmartStart assisted with Windows OS installation process and integrated and optimized HP ProLiant server support software drivers, utilities and management agents, known as ProLiant Support Packs (PSPs).

  *

  SmartStart was a single-server deployment tool that simplified HP ProLiant G7 server (and earlier) setup, providing a repeatable way to deploy consistent configurations. It was included in the HP Insight Foundation suite for ProLiant. Insight Foundation suite and SmartStart products are end-of-life (EOL) and the last servers they ship with are ProLiant G7 servers. ProLiant Gen8 servers and beyond use Intelligent Provisioning which is initiated by pressing during the server boot (POST) process.

  Not C: HP 3PAR Service Processor functions as the communication interface between the customer's IP network and HP 3PAR Central by managing all service-related communications in both directions.

  Not D: N_Port ID Virtualisation (NPIV) is an industry-standard Fibre Channel (FC) protocol that provides a means to assign multiple FC addresses on the same physical link.

• Question 36:

  A customer is planning to maximize the capacity of a new HP 3PAR StoreServ 7400 Storage System. Including the base controller enclosures, what is the maximum number of disk enclosures that are supported?

  A. 5

  B. 10

  C. 20

  D. 26

  Correct Answer: C



  The 7400 has two basic drive enclosures with 4 nodes an can add up to 18 additional drive enclosures, total 20. That makes sense because the maximum number of supported disk is 480 / 24= 20.

• Question 37:

  A customer with a Fibre Channel SAN needs to ensure that in-transit data is secure through the use of device authentication and encrypted secure key exchange.

  Which Fibre Channel standard enables them to meet this goal?

  A. FC-PH

  B. FC-OE

  C. FC-CHAP

  D. FC-SP

  Correct Answer: D

  Fibre Channel Security Protocol (FC-SP) capabilities provide switch-switch and host-switch authentication to overcome security challenges for enterprise-wide fabrics.

  Incorrect:

  Not B: FCoE (Fibre Channel over Ethernet) is a storage protocol that enable Fibre Channel communications to run directly over Ethernet. FCoE makes it possible to move Fibre Channel traffic across existing high-speed Ethernet

  infrastructure and converges storage and IP protocols onto a single cable transport and interface.

• Question 38:

  A company is planning a large client Virtualization environment featuring an HP BladeSystem with ProLiant servers, HP Virtual Connect Flex-10, and HP StoreVirtual 4800 Storage Systems. Which storage advantage does this architecture provide over competitors' client Virtualization solutions?

  A. Storage traffic that enters the Virtual Connect module is prioritized automatically.

  B. Storage traffic remains within the Virtual Connect domain for better Performance.

  C. Each SAN provides dedicated storage for each hypervisor.

  D. Each SAN is its own cluster, eliminating data segmentation across multiple clusters.

  Correct Answer: A

  HP Virtual Connect FlexFabric interconnects pair with HP FlexFabric 10Gb 2-port onboard or mezzanine based adapters and provide FlexNIC functionality with Converged Network Adapters (CNAs) capable of either iSCSI, FCoE or native Fibre Channel storage protocols. With Virtual Connect 4.00, this flexible bandwidth capability is extended further with minimum and maximum bandwidth settings configurable from within the Virtual Connect management interface. This allows you to prioritize certain types of traffic over other types if contention occurs as well as insuring that certain networks have guaranteed bandwidth.

• Question 39:

  A customer needs a grid-based storage solution that provides Fibre Channel/iSCSI mixed volumes. Which storage system should the customer implement?

  A. HP StoreVirtual 4330 FC

  B. HP StoreVirtual 4830 FC

  C. HP StoreVirtual 4330

  D. HP StoreVirtual 4130

  Correct Answer: A

  Fibre Channel connectivity is only available onHP StoreVirtual 4330 FC Storage. Note:

  * Figure 2.HP StoreVirtual 4030 FC Storage with iSCSI and Fibre Channel connectivity



• Question 40:

  What are the benefits of migrating to an HP 3PAR StoreServ 7000?

  A. Virtualization of homogenous storage devices

  B. increased efficiency through reduced capacity requirements

  C. multi-tier storage availability in hyperscale enterprise platform

  D. federated non-disruptive data mobility between third-party systems

  Correct Answer: C
