An application retrieves records from a data store and displays the retrieved data on an HTML page. The HTML page contains a scroll bar to view all of the attributes. A user must scroll down through 4 screens of information to see all of the attributes contained on the HTML page. How is this counted?
A. 1 EOs
B. 4EOs
C. 1 EQ
D. 4 EQs
Which requirement(s) would be accounted for using only the GSCs?
A. Design the screen so that all transactions would be done in less than three keystrokes
B. Provide support for four spoken languages
C. Provide conversion and installation guides
D. All the above
A transaction file contains records to maintain the Master file. A flag is included on each incoming record to indicate if the Master file record is to be added, changed or deleted. A batch job is developed to process the transaction file. How many transactional functions would be counted?
A. 1
B. 2
C. 3
D. 4
The Compliance application sends an electronic transaction of summary compliance data to the Laboratory Management application, which then updates an ILF. How would this (these) transactional function be measured?
A. 1 EI for the Compliance application, 1 EI for the Laboratory Management application
B. 1 EO for the Compliance application, 1 EI for the Laboratory Management application
C. 1 EI for the Compliance application
D. 1 EIF and 1 EI for the Laboratory Management application
What would be the correct sequence of activities for measuring transactional functions? 1. Classify each transactional function as an EI, EO or EQ 2. Identify each elementary process required by the user
3. Determine the functional complexity for each transactional function 4. Determine the functional size for each transactional function 5. Count FTRs for each transactional function 6. Count DETs for each transactional function
A. 1-3-2-1-4-5
B. 2-3-1-6-5-4
C. 4-2-1-5-6-3
D. 2-1-5-6-3-4
An EO maintains 1ILF and references 3 ILFs. What is the minimum number of DETs necessary for it to be valued at 7 LFP?
A. 1
B. 6
C. 20
D. It can never be valued at 7 LFP
The user can request the same data to be displayed in four languages. The data in the different languages are stored in user-maintained tables. How would this display of data be measured?
A. 1 EQ
B. 4 EQs
C. 1 EO
D. 4 EOs
At the end of the month, Application X sends a transaction file to Application Y. The transaction file contains a listing of employees that includes employee id, department, department description, and the total number of employees. Three of these attributes are contained in the Employee ILF in Application X, with the exception of the total number of employees which Is a computed attribute. Which statement is true for Application X?
A. The elementary process is measured as an EO
B. The elementary process is measured as an EQ
C. Three DETs are measured for the transaction sent to Application Y
D. None of the above
The data retrieved from the state drop down list is obtained by reading the State file that contains only state code and state description. The State file is not updated frequently as states are not added on a frequent basis. How would the drop down list be measured?
A. 1 EQ with 1 FTR
B. 1 EO with 1FTR
C. 1 EQ with OFTR
D. Not counted
Which of the following rules apply when counting DETs for both EOs and EQs?
A. Count one DET for each unique user recognizable, non-repeated attribute that crosses the boundary
B. Count one DET for each literal such as report titles or screen identifiers
C. Count one DET for each attribute generated within the boundary and saved to an ILF without exiting the boundary
D. Count one DET for each navigation aid used to navigate within a list
