OMG OMG Certifications OMG-OCUP-200 Questions & Answers

• Question 71:

  What does the composite structure notation in the exhibit show?



  A. p is a hidden port of C

  B. p is a behavior port of C

  C. p is a port providing a system service.

  D. p is a port on a part of C, which is not shown.

  Correct Answer: A

• Question 72:

  What are true about the composite structure exhibit? (Choose two)



  A. C has one part.

  B. C has at least two properties.

  C. Every instance of X must be connected to an instance of Y.

  D. Every instance of Y must be connected to an instance of X.

  E. All instances corresponding to x and y will be destroyed when an instance of C is destroyed.

  Correct Answer: AB

• Question 73:

  What characteristic does a ConnectableElement possess?

  A. can own connectors

  B. can have associations

  C. represents the end of a communication channel

  D. can be connected to other elements by connectors

  Correct Answer: D

• Question 74:

  What is true of a required interface associated with a port?

  A. represents an interface that must be defined within the classifier that owns the port

  B. identifies the services that the object owning the port expects of objects connected via that port

  C. identifies the services that the object owning the port can offer to other objects connected via that port

  D. represents an interface that must be defined in the same package in which the classifier owning the port is defined

  Correct Answer: B

• Question 75:

  What characteristic does a behavior port possess?

  A. is a kind of behavior

  B. must have a protocol state machine

  C. owns the behavior of the classifier that owns the port

  D. defines the behavior that the owning classifier must realize

  E. has its own behavior that is distinct from the behavior of the classifier

  F. relays any incoming messages directly to the behavior of the owning object

  Correct Answer: F

• Question 76:

  What interface restrictions does a port have?

  A. multiple required interfaces or multiple provided interfaces

  B. multiple provided interfaces and multiple required interfaces

  C. equal numbers of provided interfaces and required interfaces

  D. exactly one provided interface or exactly one required interface

  E. exactly one required interface and exactly one provided interface

  Correct Answer: B

• Question 77:

  What does the lower bound of the multiplicity of a part in a structured classifier indicate? The minimum number of .

  A. links that can be connected to that part

  B. connectors that can be connected to that part

  C. instances corresponding to that part that can exist when the classifier is instantiated

  D. times that an instance corresponding to that part can be created during the lifetime of the structured classifier instance

  Correct Answer: C

• Question 78:

  What may a profile NOT own?

  A. stereotypes

  B. metaclasses

  C. new associations

  D. associations that redefine existing associations

  Correct Answer: C

• Question 79:

  What is NOT true of a profile?

  A. A profile can be removed at any time from a model.

  B. A profile can be combined with others applied on the same model.

  C. Applying a profile means that it is required to apply the stereotypes that are part of the profile.

  D. Applying a profile means that it is allowed, but not required to apply the stereotypes that are part of the profile.

  Correct Answer: C

• Question 80:

  What is permitted for the profile mechanism?

  A. creates new metamodels

  B. extends existing metamodels

  C. changes existing metamodels

  D. removes existing metamodels

  Correct Answer: B
