VMware VMware Certifications VCP-510 Questions & Answers

• Question 271:

  An administrator decides to implement a Fixed multipathing policy for an ESXi 5.x host with four available paths to one VMFS datastore. After the policy has been enabled for the datastore, how many paths will have an active status by default?

  A. 4

  B. 3

  C. 1

  D. 2

  Correct Answer: A

• Question 272:

  An administrator is updating a program running on a virtual machine. The update file has been downloaded as an .iso file and placed on a shared NFS datastore. An attempt to mount the .iso file to the virtual machine fails, but subsequent testing shows that the .iso file can be mounted to a virtual machine running on another ESXi 5.x host. Which step can be taken to enable access to the .iso file for the affected virtual machine?

  A. Reboot all ESXi hosts in the cluster where the affected virtual machine is running.

  B. Refresh all datastores on the ESXi host running the affected VM.

  C. Rescan all datastores on the ESXi host running the affected VM.

  D. Unmount the volume from the ESXi host running the affected VM, and then add as a new datastore.

  Correct Answer: B

• Question 273:

  When PSA is coordinating the VMware NMP and any installed third-party MPPs, the MPPs perform which task?

  A. Implement logical device bandwidth sharing

  B. Handle I/O queuing to the logical devices

  C. Provide logical device and physical path I/O statistics

  D. Manage physical path claiming and unclaiming

  Correct Answer: D

• Question 274:

  Which VMware solution uses the security of a vSphere implementation and provides linked-clone technology to virtual desktops?

  A. VMware ACE

  B. VMware View

  C. VMware Workstation

  D. VMware ThinApp

  Correct Answer: B

• Question 275:

  A new ESXi 5.x host is set up with two virtual machines. A memory limit is applied so that users will have predictable performance as virtual machines are added to the host. What is the effect of applying a memory limit to these virtual machines?

  A. No physical memory will be granted above the limit, but VSWP can be used.

  B. No physical memory will be granted above the limit, unless expandableVM shares are set to high.

  C. Physical memory will be granted above the limit under normal conditions. Disk pages will be used if contention occurs.

  D. Physical memory will be granted above the limit under normal conditions, unless physical memory runs out.

  Correct Answer: A

• Question 276:

  Which are the correct parameters to specify when adding an iSCSI target to an ESXi 5.x host using the Static Discovery tab?

  A. iSCSI server ip address, port 902

  B. iSCSI server ip address, port 3260

  C. iSCSI server ip address, port 902, iSCSI target name

  D. iSCSI server ip address, port 3260, iSCSI target name

  Correct Answer: D

• Question 277:

  Which two options cannot be edited if vApp Options is disabled in the Options tab of a virtual machine that is part of a vApp? (Choose two.)

  A. Transient IP Addresses

  B. Configure OVF properties

  C. IPv6 Protocol

  D. IPv4 Protocol

  Correct Answer: AB

• Question 278:

  When an explicit failover order has been configured on a virtual switch with multiple uplinks, what determines which uplink is used when a failover event occurs?

  A. The first available uplink that reports a positive link state

  B. The reported uptime for the surviving uplinks

  C. The next available uplink on the list

  D. The uplink with the shortest route

  Correct Answer: C

• Question 279:

  Click the Exhibit button. Users are having difficulty accessing a Web server since a new Web application was configured in a virtual machine running on sc-titanium03.vmeduc.com. The web server has been assigned 1 vCPU. The vSphere Client reports the error shown in the exhibit. DRS is set to fully automated mode, but the problem has not resolved. Which action can resolve the issue?



  A. Set a CPU reservation for the web server VM.

  B. Manually move the Virtual Machine using high priority vMotion.

  C. Configure the DRS Migration Threshold to Aggressive.

  D. Set CPU affinity for the virtual machine.

  Correct Answer: A

• Question 280:

  Users are complaining that they cannot access their files on a file server virtual machine. The vSphere Client shows that a triggered alarm stating disk latency is beyond the default threshold for the datastore where the file server virtual machine is located. The path selection policy has been set by the ESXi host to Fixed with default path settings. Which two options could be used to increase performance of the file server virtual machine? (Choose two.)

  A. Use disk shares to increase the priority for the datastore housing the file server virtual machine.

  B. Use vMotion to relocate the VM to an ESXi host with loser HBA saturation.

  C. Change the path selection policy to Round Robin.

  D. Change the path selection policy to Most Recently Used (MRU).

  Correct Answer: BC
