VMware VMware Certifications VCP5-DCV Questions & Answers

• Question 111:

  An administrator needs to create an alarm to monitor when a specific ESXi host in an HA/DRS cluster becomes disconnected from other vSphere components like HA agents or the vCenter server. Which process must the administrator use to accomplish this?

  A. Define a Host type alarm, monitor for the event Cannot connect host, and supply a conditional trigger on Host name equal to a specific label.

  B. Define a Cluster type alarm, monitor for the event Cannot connect host, and supply a conditional trigger on Host name equal to a specific label.

  C. Define a Cluster type alarm, monitor for the event Host status changed, and supply a specific label for each host.

  D. Define a Host type alarm, monitor for the condition Host status changed, and supply a specific label for each host.

  Correct Answer: A

• Question 112:

  When a vSphere administrator attempts to remediate a host with Update Manager, the host is unable to enter maintenance mode. Which condition is likely preventing the host from entering maintenance mode?

  A. A virtual machine on the host has a removable device connected.

  B. A virtual machine on the host is configured to use Fault Tolerance.

  C. A virtual machine is powered off and cannot be migrated to another host.

  D. A virtual machine is configured with a local .vswp file.

  Correct Answer: A

• Question 113:

  While troubleshooting a crash event on an ESXi 5.x host, an administrator determines the log files related to the event are NOT present. Which action should the administrator take to resolve the logging issue?

  A. Increase the amount of memory committed to log storage.

  B. Increase the statistic data collection level to 4.

  C. Change the roll-up type to maximum.

  D. Create a persistent scratch location.

  Correct Answer: D

• Question 114:

  -- Exhibit -



  -- Exhibit -The administrator needs to modify the problematic configuration shown in the exhibit to meet the following requirements:

  1.

  Uplink ports must connect to a 2-port Etherchannel connection.

  2.

  Traffic must pass, even in the event of a port failure.

  Which two configuration changes should the administrator make? (Choose two.)

  A. Change the Load balancing algorithm to Route based on ip hash

  B. Change the Load balancing algorithm to Route based on physical NIC load

  C. Move Uplink 1 into Active Uplinks and Uplink 2 into Standby Uplinks

  D. Move both uplinks into the Active Uplinks

  Correct Answer: AD

• Question 115:

  An administrator needs to install vSphere Update Manager using an external SQL Server 2008 R2 database. The administrator has created the database successfully, but cannot establish connectivity when testing the DSN. Which configuration setting could be causing the issue?

  A. The database was configured to use Windows authentication.

  B. The DSN was configured using a 32-bit ODBC connection.

  C. Update Manager does not support the use of a remote database.

  D. Port 9087 is being blocked by Windows Firewall on the Update Manager server.

  Correct Answer: A

• Question 116:

  A host in a 4-node HA\DRS cluster has failed. HA initiates restart tasks for the virtual machines on the remaining hosts in the cluster but half of them fail to restart. What is the likely reason virtual machines fail to restart?

  A. HA admission control is blocking the restart of the virtual machines due to insufficient resources to support the configured failover level of the cluster.

  B. The vMotion network has failed on the remaining hosts preventing the virtual machines from migrating.

  C. Storage vMotion has failed on the datastore containing the virtual machines preventing them from migrating.

  D. The failed host was the Master host in the cluster and no other hosts are able to perform the necessary HA function to restart the virtual machines.

  Correct Answer: A

• Question 117:

  A vSphere administrator needs to add a CPU to a virtual machine, but upon editing the VM settings the option is grayed out. What would explain this behavior?

  A. The virtual machine is running

  B. The virtual machine has been configured with a CPU limit

  C. CPU Hot-add has not been enabled on the virtual machine

  D. The virtual machine is in a resource pool with no available CPU resources

  Correct Answer: AC

• Question 118:

  The vSphere administrator needs to migrate a virtual machine from one ESXi 5.5 host to another ESXi 5.5 host. The virtual machine has a virtual disk that is stored in local storage. Assuming only the vSphere Essentials licensing is in place, which technique should the administrator use to accomplish the migration?

  A. vMotion migration

  B. Cold migration

  C. Enhanced vMotion migration

  D. Storage vMotion migration

  Correct Answer: B

• Question 119:

  What two requirements must be met to create a fully automated Distributed Resource Scheduler (DRS) cluster? (Choose two.)

  A. Shared storage

  B. Hosts with identical processor features

  C. Storage vMotion

  D. vMotion

  Correct Answer: AD

• Question 120:

  A vSphere administrator has been using vSphere in evaluation mode and now wants to deploy an environment that provides the same features.

  Which edition of vSphere provides similar functionality to evaluation mode?

  A. Enterprise Plus

  B. Enterprise

  C. Standard

  D. Essentials

  Correct Answer: A
