VMware VMware Certifications VCP5-DCV Questions & Answers

• Question 201:

  An administrator has configured a vSphere 5.5 test environment to evaluate the Virtual SAN feature using Automatic Mode Disk Groups. The administrator needs to disable the Virtual SAN cluster while preserving the virtual machines running on that cluster. The administrator has already installed a vSphere 5.5 Client on a Windows 7 desktop and also has access to the vSphere 5.5 Web Client. What should the administrator do to disable the Virtual SAN?

  A. Use Storage vMotion to migrate the virtual machines to another datastore then use the vSphere 5.5 Client to disable the Virtual SAN.

  B. Use Storage vMotion to migrate the virtual machines to another datastore then use the vSphere 5.5 Web Client to disable the Virtual SAN.

  C. Use the vSphere 5.5 Client to disable the Virtual SAN, which will automatically migrate the virtual machines via the Storage DRS feature.

  D. Use the vSphere 5.5 Web Client to disable the Virtual SAN, which will automatically migrate the virtual machines via the Storage DRS feature.

  Correct Answer: B

• Question 202:

  Which statement is true about the hardware configuration for ESXi hosts participating in a virtual SAN?

  A. The hosts must have identical hardware.

  B. Each host must have at least one Solid State Drive (SSD).

  C. The hosts must have network attached storage.

  D. Each host must have a RAID Controller.

  Correct Answer: B

• Question 203:

  A vSphere administrator observes a problem with the Virtual SAN Cluster Setting as shown:

  -- Exhibit -



  -- Exhibit -

  Which action should the administrator take on the vmkernel portgroup on all hosts used by Virtual SAN cluster to resolve this problem?

  A. Select the Virtual SAN traffic option

  B. Increase the MTU value

  C. Change the DNS server address

  D. Increase the Port Speed

  Correct Answer: A

• Question 204:

  What should an administrator do to configure multi-pathing using software iSCSI?

  A. Bind the VMkernel ports to the software iSCSI initiator

  B. Configure Zoning between the hosts and SAN switches

  C. Configure NIC teaming on the associated uplinks

  D. Ensure jumbo frames are enabled end-to-end

  Correct Answer: A

• Question 205:

  A virtual machine has the following configuration:

  Thin provisioned virtual disks

  The VMFS datastore on which it resides is on a thin provisioned LUN.

  The storage array is VAAI-enabled.

  What is the behavior of the virtual machine when it encounters an out-of-space condition?

  A. It is suspended.

  B. It is gracefully shut down.

  C. It is powered off.

  D. It is converted to space-efficient sparse.

  Correct Answer: A

• Question 206:

  Which two statements are true regarding a new vSphere deployment that is using software FCoE boot from SAN? (Choose two.)

  A. Multi-pathing options must be configured by the vmkernel after boot.

  B. The adapter must support iBFT or UEFI.

  C. The adapter must support FBFT or FBPT.

  D. Multi-pathing options must be configured in the Boot ROM.

  Correct Answer: AC

• Question 207:

  Which feature requires an administrator to configure an RDM with Virtual Compatibility Mode?

  A. vMotion

  B. Virtual Machine Snapshots

  C. High Availability

  D. N-port ID Virtualization

  Correct Answer: B

• Question 208:

  A virtual machine is unable to communicate with another virtual machine. Both virtual machines are connected to the Production port group on the same virtual switch and are running on the same host.

  Which configuration is causing the inability of the virtual machines to communicate?

  A. LLDP was enabled instead of CDP for the vSphere Distributed Switch.

  B. Promiscuous Mode has been set to Allow on the Production port group.

  C. The Production port group is configured to use a secondary PVLAN.

  D. The speed and duplex settings for the virtual machine vmnics do not match.

  Correct Answer: C

• Question 209:

  A virtual machine is receiving a large number of network packets, which is affecting the performance of other virtual machines connected to the same virtual network. What should the vSphere administrator do to resolve the issue?

  A. Migrate the virtual machine to a standard switch that has been configured for ingress traffic shaping

  B. Configure the distributed switch to which the virtual machine is connected for ingress traffic shaping

  C. Migrate the virtual machine to a different port group on the same distributed switch

  D. Enable Network I/O Control on the standard switch to which the virtual machine is connected

  Correct Answer: B

• Question 210:

  An administrator is deploying vSphere 5.5. The administrator creates a vSphere Distributed Switch, then uses Auto Deploy to deploy several ESXi hosts. After the hosts are deployed, the administrator notices that LACP packets are not being

  sent between them.

  Which condition would cause this issue to occur?

  A. The LACP support settings do not exist in the Host Profile.

  B. The LACP installation bundle is not included in the Image Profile.

  C. The LACP setting is not enabled on vCenter Server.

  D. LACP has not been configured on the Auto Deploy server.

  Correct Answer: A
