VMware VMware Certifications VCP5-DCV Questions & Answers

• Question 231:

  Immediately after installing ESXi, an administrator observes that the Configure Lockdown Mode option is grayed out in the Direct Console User Interface (DCUI). What is the most likely explanation?

  A. The host has not yet been added to a vCenter Server.

  B. The BIOS on the host does not have NX/XD enabled.

  C. The ESXi host is running in evaluation mode.

  D. The host requires a reboot before this feature is available.

  Correct Answer: A

• Question 232:

  What is a valid plug-in status for a plug-in that has been added to a vSphere client?

  A. Disabled

  B. Unknown

  C. Stopped

  D. Installed

  Correct Answer: A

• Question 233:

  An administrator is evaluating whether to deploy vCenter Server on a Windows server or on a vCenter Server appliance. The administrator has the following requirements:

  A web browser will be utilized to manage the vSphere environment.

  16 ESXi hosts will be deployed.

  Licenses must be shared with a vCenter Server at another site.

  An external Oracle 10g database server will be used to host the vCenter Server database.

  Why will the administrator need to deploy vCenter Server on a Windows server?

  A. Linked Mode is a requirement for the solution.

  B. Oracle 10g is a requirement for the solution.

  C. The vSphere web client is a requirement for the solution.

  D. Management of more than 5 hosts is a requirement for the solution.

  Correct Answer: A

• Question 234:

  An administrator needs to modify a virtual machine alert to increase the threshold value of the trigger. Once connected to the vCenter Server, the administrator navigates to the virtual machine to make the change. However, the administrator is unable to edit the alarm. What is the reason that this alarm cannot be edited?

  A. The alarm was not defined on this inventory object.

  B. The administrator is not the owner of this inventory object.

  C. The alarm was not created by the administrator.

  D. The alarm has not been acknowledged.

  Correct Answer: A

• Question 235:

  A vSphere administrator can create an alarm on which two objects? (Choose two.)

  A. LUN

  B. Datastore

  C. Template

  D. Folder

  Correct Answer: BD

• Question 236:

  A vSphere administrator needs a way of sending noncritical ESXi events to a remote server. Due to budget constraints, no additional costs should be incurred. Which tool will best meet this requirement?

  A. vSphere Syslog Collector

  B. vSphere ESXi Dump Collector

  C. vSphere vCenter Log Insight

  D. vSphere Management Appliance

  Correct Answer: A

• Question 237:

  -- Exhibit -



  -- Exhibit -

  An administrator determines that traffic shaping does not appear to be working on Production, a virtual machine port group on vSwitch1. Traffic shaping is working on all other port groups on the switch. The administrator examines the Traffic

  Shaping settings as shown in the exhibit:

  What should the administrator do to resolve the problem?

  A. Select the Status checkbox to enable Traffic Shaping on the portgroup.

  B. Reduce the Average Bandwidth to 50% of the Peak Bandwidth.

  C. Reduce the Burst Size to 50% of the Peak Bandwidth.

  D. Click the Security tab and create the necessary security exception.

  Correct Answer: A

• Question 238:

  -- Exhibit -



  -- Exhibit -The vSphere administrator needs to remove the Production virtual machine port group from an ESXi host. The ESXi host's Networking Configuration tab is shown in the exhibit.

  After disconnecting the Fileserver02 VM, what step does the administrator need to take, assuming that vSwitch1 will still be needed for further configuration?

  A. Remove the Production port group by accessing the properties for the port group.

  B. Remove the Production port group by accessing the properties for vSwitch1.

  C. Remove the Production port group by accessing the properties for the Network.

  D. Remove the Production port group by removing vSwitch1.

  Correct Answer: B

• Question 239:

  An administrator determines that when a host residing in a High Availability (HA) cluster fails, the virtual machines fail to restart on a remaining host, or will only restart after a long delay. Which two conditions would account for this behavior? (Choose two.)

  A. The virtual machines were not protected by vSphere HA at the time the failure occurred.

  B. Distributed Resource Scheduler was not enabled at the time the failure occurred.

  C. There is insufficient spare capacity on hosts with which the virtual machines are compatible.

  D. The virtual machines contain physical Raw Device Mappings.

  Correct Answer: AC

• Question 240:

  -- Exhibit -



  -- Exhibit -

  What is portrayed in the performance chart?

  A. The ESXi host running the VM has Transparent Page Sharing enabled.

  B. The virtual machine's memory share value is set too high.

  C. The virtual machine is memory constrained.

  D. The ESXi host running the VM is low on memory.

  Correct Answer: D
