VMware VMware Certifications VCP5-DCV Questions & Answers

• Question 341:

  Which option could be used for vSphere HA heartbeats?

  A. An iSCSI LUN used for booting the master ESXi host.

  B. An iSCSI LUN backing an RDM connected over 10GB Ethernet

  C. An NFS datastore shared with the all hosts, sync, no_root_squash and read only options

  D. A Fibre Channel LUN on an 8GB active/active array backing a VMFS5 datastore

  Correct Answer: D

  Fibre Channel LUN on an 8GB active/active array backing up a VMFS5 datastore will work with vSphere HA heartbeats.

• Question 342:

  Which two components can be installed in monitored virtual machines to trigger vSphere HA Application Monitoring? (Choose two.)

  A. A custom script utilizing the appmonitor executable

  B. The vSphere Fault Tolerant agent

  C. Third-party utilities such as Neverfail or ApplicationHA

  D. The vSphere HA application agent

  Correct Answer: AC

  Custom script using appmonitor executable can be installed in monitored VMs that will help triggering vSphere HA Application monitoring. You can also install third-party utilities like Neverfail or ApplicationHA to trigger vSphere HA Application monitoring.

• Question 343:

  A vSphere environment is created with two virtual machines, VM23 and VM43. Each virtual machine has an instance of the front-end web application for the company's manufacturing management database. A physical load-balancer is configured for the application.

  Which type of DRS rule should be implemented for VM23 and VM43?

  A. Separate Virtual Machines

  B. Virtual Machines to Hosts

  C. Host DRS Groups

  D. Keep Virtual Machines Together

  Correct Answer: A

  Separate virtual machines can be implemented for VM 23 and VM43.

• Question 344:

  Which two migration techniques can be used together to move a running virtual machine to a local datastore on a different server? (Choose two.)

  A. Cold migration

  B. Storage vMotion

  C. vMotion

  D. vSphere Clone

  Correct Answer: BC

  Reference: http://www.datadisk.co.uk/html_docs/vmware/vmotion.htm

• Question 345:

  In a vSphere HA cluster, what is the maximum number of point-to-point communication links to the slaves does each master maintain?

  A. 32

  B. 64

  C. 512

  D. 1024

  Correct Answer: A

  Reference: http://globalknowledgeblog.com/technology/vmware/ten-vsphere-ha-and-drs- (see non-optimal sizing of clusters) misconfiguration-issues-distributed-resource-scheduler-issues/

• Question 346:

  Which two conditions could prevent HA from powering on a virtual machine? (Choose two.)

  A. There is not enough free memory to meet the guests memory reservation.

  B. The virtual machine has been assigned a required affinity rule.

  C. Strict admission control is disabled for the HA cluster.

  D. The vCenter is hosted on the ESXi host that failed.

  Correct Answer: AB

  Reference: http://pubs.vmware.com/vsphere-50/index.jsp?topic= % 2Fcom.vmware.vsphere.troubleshooting.doc_50%2FGUID-A7C83499-FA81-4893-8376- A4B91AC81FA7.html

• Question 347:

  Which conditions are true regarding an ESXi 5.x host placed into maintenance mode while a member of a DRS cluster? (Choose two.)

  A. If the DRS cluster is in partially automated mode and vMotion is configured, its virtual machines will be moved automatically to other hosts in the cluster.

  B. If the DRS cluster is in fully automated mode and vMotion is configured, its virtual machines will be moved automatically to other hosts in the cluster.

  C. If the DRS cluster is in partially automated mode and vMotion is configured, its virtual machines that have a high restart priority will be migrated to other hosts in the cluster.

  D. All the virtual machines on the host must be migrated or powered off before the ESXi host will complete entering maintenance mode.

  Correct Answer: BD

  Reference: http://searchitchannel.techtarget.com/feature/Enabling-VMware-HA-DRS-Advanced- (see `Configuring DRS') vSphere-features

• Question 348:

  An administrator wants to configure a DRS Migration Threshold that allows automated migration only when a host is placed into maintenance or to satisfy cluster constraints. What setting should be utilized?

  A. Priority 2

  B. Priority 4

  C. The most conservative setting

  D. The default setting

  Correct Answer: C

  NOTE: The options are wrong I guess. See the following reference: http://www.joshodgers.com/tag/fully-automated/

• Question 349:

  What is an accurate statement about the secondary virtual machine of a VM that has VMware Fault Tolerance enabled?

  A. The secondary virtual machine cannot be stored on an NFS datastore.

  B. The secondary virtual machine is created on the same host as the primary.

  C. The secondary virtual machine can prevent other virtual machines from powering up.

  D. The secondary virtual machine can be used for load balancing.

  Correct Answer: C

  Reference: http://kb.vmware.com/selfservice/microsites/search.do? language=en_USandcmd=displayKCandexternalId=1013428

• Question 350:

  What is true about the HA agent on ESXi 5.x hosts?

  A. HA agent logs and entries use the prefix aam

  B. HA agents are set to start by default

  C. HA agents can store configuration information locally

  D. vSphere client cannot determine which HA agent is master

  Correct Answer: C

  Reference: http://pubs.vmware.com/vsphere-50/index.jsp?topic= %2Fcom.vmware.vsphere.avail.doc_50% 2FGUID-7442EF04-56C9-4910-ACBA- (see configuration files protected using file system permissions) DF42E97ED311.html
