VMware VMware Certifications VCP5-DCV Questions & Answers

• Question 501:

  Which network settings are only available with vSphere Distributed Switches?

  A. Jumbo Frames

  B. PVLAN

  C. Load Balancing

  D. Promiscuous Mode

  Correct Answer: B

  Reference: http://kb.vmware.com/selfservice/microsites/search.do? language=en_USandcmd=displayKCandexternalId=1010691

• Question 502:

  On which two vSphere elements can traffic shaping be configured? (Choose two.)

  A. On a vSphere Distributed Switch dvPort for inbound and/or outbound traffic

  B. On a vSphere Distributed Switch for inbound and/or outbound traffic

  C. On a vSphere Standard Switch port group or the entire vSwitch for inbound traffic

  D. On a vSphere Standard Switch port group or the entire vSwitch for inbound and outbound traffic

  Correct Answer: AB

  Reference: http://pubs.vmware.com/vsphere-4-esxi-installable- vcenter/topic/ com.vmware.vsphere.esxi_server_config.doc_41/esx_server_config/advanced_networki ng/ t_edit_dvport_policy_traffic_shaping.html

• Question 503:

  What would be a valid reason to enable traffic shaping?

  A. Limiting the bandwidth of a FTP server

  B. Restricting the load on a IDS server

  C. Limiting the bandwidth used by an independent hardware iSCSI adapter

  D. Improving the performance of a CPU-intensive application server

  Correct Answer: A

  By limiting the bandwidth of a FTP server, you can enable traffic shaping.

• Question 504:

  A vSphere 5.x implementation contains two ESXi hosts, ESXi01and ESXi02. There is a virtual machine "VM21" connected to the Production port group on ESXi01.

  ESXi01 has the following switch configuration.

  vSwitch0, single uplink to 10.1.20.0/24 Production port group VMkernel port for vMotion VMKernel port for management

  vSwitch1, single uplink to 10.1.40.0/24 Engineering port group VMKernel port for NFS storage ESXi02 has the following switch configuration.

  vSwitch0, single uplink to 10.1.20.0/24 Engineering port group VMkernel port for vMotion VMKernel port for management

  vSwitch1, single uplink to 10.1.40.0/24 Production port group VMKernel port for NFS storage

  Which two statements are true about this configuration? (Choose two.)

  A. vMotion is not available between the two hosts

  B. If VM21 is migrated to ESXi02 it will not be available on the network

  C. The virtual machine can be vMotion migrated to the target host.

  D. Broadcasts from the Production port group will not reach the Engineering port group.

  Correct Answer: BD

  If VM21 is migrated to ESXi 02, then according to the information provided, it will not be available on the network. Likewise, broadcasts from production port group will not reach engineering port group.

• Question 505:

  In vSphere, a bound physical NIC can be configured to transmit and receive jumbo frames. What is the default maximum transmission unit (MTU) in vSphere?

  A. 1500

  B. 5500

  C. 9000

  D. 9500

  Correct Answer: A

  Reference: http://www.experts-exchange.com/Software/VMWare/A_9132-HOW-TO-Enable- Jumbo- Frames-on-a-VMware-vSphere-Hypervisor-ESXi-5-0-host-server-using-the-VMware- (search for default MTU (Frame) size) vSphere-Client.html

• Question 506:

  When PSA is coordinating the VMware NMP and any installed third-party MPPs, the MPPs perform which task?

  A. Implement logical device bandwidth sharing

  B. Handle I/O queueing to the logical devices

  C. Provide logical device and physical path I/O statistics

  D. Manage physical path claiming and unclaiming

  Correct Answer: D

  Reference: http://pubs.vmware.com/vsphere-4-esxi-installable-vcenter/index.jsp? topic=/ com.vmware.vsphere.esxi_server_config.doc_41/esx_san_config/common/c_vmware_pluggab le_storage_architecture.html

• Question 507:

  When creating a dvPort group, which port binding option assigns a port to a virtual machine when the virtual machine is first powered on?

  A. Static binding

  B. Flexible

  C. Ephemeral

  D. Dynamic binding

  Correct Answer: D

  Reference: http://simongreaves.co.uk/blog/distributed-virtual-switch-guide (see port bindings, dynamic)

• Question 508:

  An administrator is enabling Network I/O Control (NIOC) on a vSphere Distributed Switch. Which types of network traffic can be prioritized with NIOC by default? (Choose three.)

  A. FCP Traffic

  B. NFS Traffic

  C. Virtual Machine Traffic By Virtual Machine

  D. iSCSI Traffic

  E. vSphere Replication (VR) Traffic

  Correct Answer: BDE

  Reference: http://www.vmware.com/products/datacenter-virtualization/vsphere/network-io- control.html#techinical

• Question 509:

  When an explicit failover order has been configured on a virtual switch with multiple uplinks, what determines which uplink is used when a failover event occurs?

  A. The first available uplink that reports a positive link state

  B. The reported uptime for the surviving uplinks

  C. The next available uplink on the list

  D. The uplink with the shortest route

  Correct Answer: C

  The next uplink is used logically when a failover event occurs. The next available uplink on the list will be the new uplink.

• Question 510:

  Which types of traffic can a VMkernel port be enabled to carry on a ESXi 5.x host? (Choose three.)

  A. NFS

  B. Fault Tolerant

  C. Management

  D. iSCSI

  E. vMotion

  Correct Answer: BCE

  Reference: http://www.epubbud.com/read.php?g=8MVD69ZNandtocp=15
