VMware VMware Certifications VCPC610 Questions & Answers

• Question 41:

  An administrator needs to install a new IaaS Components server for vCloud Automation Center. Which two operating systems are supported for the installation? (Choose two.)

  A. Windows Server 2008 R2

  B. Windows Server 2012 R2

  C. Windows Server 2008 SP2

  D. Windows Server 2003 R2

  Correct Answer: AB

• Question 42:

  An administrator needs to limit CPU resources for a vCloud Automation Center Business Group. What should the administrator do?

  A. Create a Reservation that includes a vSphere Resource Pool that limits CPU utilization.

  B. Create a Reservation and specify CPU limits in the This Reservation field.

  C. Create a Reservation and specify a Reservation Policy that limits CPU utilization.

  D. Create a Reservation that enables Alerts based on CPU utilization.

  Correct Answer: A

• Question 43:

  Refer to the Exhibit.



  Which two reasons could be the cause of the vSphere Client reporting N/A for hyperthreading? (Choose two.)

  A. The physical CPUs in the host do not support hyperthreading.

  B. Hyperthreading is disabled in the host's BIOS.

  C. The physical CPUs in the host are not multi-core.

  D. The number of CPUs meets or exceeds the maximum without hyperthreading.

  Correct Answer: AB

• Question 44:

  An administrator needs to create an alarm to monitor when a specific ESXi host in an HA/DRS cluster becomes disconnected from other vSphere components like HA agents or the vCenter Server.

  Which process must the administrator use to accomplish this?

  A. Define a Host type alarm, monitor for the event Cannot connect host, and supply a conditional trigger on Host name equal to a specific label.

  B. Define a Cluster type alarm, monitor for the event Cannot connect host, and supply a conditional trigger on Host name equal to a specific label.

  C. Define a Cluster type alarm, monitor for the event Host status changed, and supply a specific label for each host.

  D. Define a Host type alarm, monitor for the condition Host status changed, and supply a specific label for each host.

  Correct Answer: A

• Question 45:

  Refer to the Exhibit.



  The vSphere administrator is configuring directory services for a host, as shown in the exhibit:



  What should the vSphere administrator do to configure the host to use CAM services?

  A. Check the Use vSphere Authentication Proxy checkbox.

  B. Set Select Directory Service Type to "CAM services".

  C. Specify "CAM$" for the Domain.

  D. Set Trusted Domains to "cam\name.tld" where name.tld is the domain that the host is joining.

  Correct Answer: A

• Question 46:

  Refer to the Exhibit.



  What is indicated by the performance chart shown?

  A. Guest memory is overcommitted.

  B. Host memory is overcommitted.

  C. Host is I/O constrained.

  D. Guest is I/O constrained.

  Correct Answer: B

• Question 47:

  A VMware administrator determines that the active memory on an ESXi 5.x host is 20% and the consumed memory is 90%.

  How much host memory is available to virtual machines?

  A. 80%

  B. 10%

  C. 70%

  D. 20%

  Correct Answer: A

• Question 48:

  An administrator needs to install vSphere Update Manager using an external SQL Server 2008 R2 database.

  The administrator has created the database successfully, but cannot establish connectivity when testing the DSN.

  Which configuration setting could be causing the issue?

  A. The database was configured to use Windows authentication.

  B. The DSN was configured using a 32-bit ODBC connection.

  C. Update Manager does NOT support the use of a remote database.

  D. Port 9087 is being blocked by Windows Firewall on the Update Manager server.

  Correct Answer: A

• Question 49:

  An application administrator reports application slowness when loading the application's web portal. The virtual machine is currently connected to a vSphere Distributed Switch. The application owner requests information about the virtual machine's network traffic.

  Which feature of a vSphere Distributed Switch should the administrator use to gather the needed information?

  A. NetFlow

  B. Port Mirroring

  C. Network I/O Control

  D. Promiscuous Mode

  Correct Answer: A

• Question 50:

  A vSphere administrator is attempting to upgrade an ESXi host using vSphere Update Manager.

  The administrator has attached the baseline and remediated the host. Update Manager reports the remediation process has completed successfully. However, upon inspection the host is not upgraded. What is the most likely reason for this issue?

  A. The ESXi host has less than 10MB free in its /tmp directory.

  B. The user performing the upgrade has insufficient privileges.

  C. The Update Manager service has not been configured with root level access to the host.

  D. The baseline has been configured using an invalid ISO image.

  Correct Answer: A
