Huawei Huawei Certifications H12-811 Questions & Answers

• Question 701:

  Which of the following parameters cannot be used for advanced access control lists? ()

  A. Physical interface

  B. B. time limit

  C. C. Agreement number

  D. Destination port number

  Correct Answer: A

• Question 702:

  The configuration information of a certain router is shown in the figure. Which of the following statements are correct? () (Single-choice question) # aaa authentication-scheme default authentication-scheme huawei authentication-mode radius authorization-scheme default authorization-scheme huawei

  accounting-scheme default domain default domain default admin domain huawei authentication-scheme huawei authorization-scheme huawei local-user huawei password cipher 123456 local-user huawei@huawei password cipher 654321 #

  A. The domain with the domain name huawei does not use the billing plan

  B. Use the username huawei for authentication. The password needs to be 654321

  C. The authentication method adopted for the domain with the domain name huawei is local authentication

  D. The authorization method for the domain with the domain name huawei is local authorization

  Correct Answer: D

• Question 703:

  FIT AP can work independently without relying on AC. ()

  A. True

  B. False

  Correct Answer: B

• Question 704:

  Network equipment running the SNMP protocol can take the initiative to report alarm information so that network administrators can find faults in time. ()

  A. True

  B. False

  Correct Answer: A

• Question 705:

  When using the ping command on the VRp platform, if you need to specify an IP address as the source address of the echo request message, which of the following parameters should be used? ()

  A. =-a

  B. =-S

  C. =-d

  D. =-1n

  Correct Answer: A

• Question 706:

  Complete the ACL configuration shown in the figure on the router RTA. Which of the following descriptions is correct? () (Single-choice question) (RTA) acl 2001 (RTA-acl-basic-2001) rule 20 permit source 20.1.1.0 0.0.0.255 RTA-acl-basic-2001rule 10 deny source 20.1.1.0 0.0.0.255

  A. The VRP system will adjust the sequence number of the first rule to 5 according to the configuration sequence.

  B. The VRP system will not adjust the sequence number, but will first match the rule permit source 20.1.1.00.0.0.255

  C. The VRP system will first match the rule deny source20.1.1.00.0.0.255 according to the sequence number.

  D. The sequence number of configuration error rules must be configured from small to large

  Correct Answer: C

• Question 707:

  "The network administrator created VLAN 10 on the Layer 3 switch and configured an IP address under the virtual interface of the VLAN. When using the command "display ip interface brief to view the port status, and found that the VLANIF10 interface is in the dow state, what should be done? Operation to restore the VLANIF10 interface to normal? ()

  A. Assign an interface that must be Up and must be of type Trunk into VLAN 10

  B. Assign any physical interface to VLAN10

  C. Assign a physical interface that must be Up to VLAN 10

  D. Use the command "undo shutdown" under the VLANIF10 interface

  Correct Answer: D

• Question 708:

  Telnetlib is a module that implements the Telnet protocol that comes with Python ()

  A. True

  B. False

  Correct Answer: A

• Question 709:

  The mac address of the existing switch is shown in the figure. Which of the following statements is correct ()? (Multiple Choice Questions)



  A. When the switch restarts, the mac address learned by port Eth0/0/2 does not need to be relearned

  B. The data frame with the source mac address of 5489-9885-18a8 and the destination mac address of 5489-989d-1d30 learned from the port is forwarded from the Eth0/0/1 port

  C. The source mac address learned from the port is 5489-9811-0b49. The data frame with the destination mac address 5489-989d-1d30 is forwarded from the Eth0/0/2 port

  D. When the switch restarts, the mac address learned by port Eth0/0/3 needs to be re- learned

  Correct Answer: B

• Question 710:

  The network shown in the figure below assumes that all routers can enable OSPF at the same time. Which router is the DR in this network? () (Single-choice question)



  A. Router B

  B. B. Router D

  C. C. Router A

  D. Router C

  Correct Answer: A
