HP HP Certifications HPE6-A45 Questions & Answers

• Question 91:

  An AOS-Switch needs to use captive portal to integrate with an Aruba ClearPass Guest solution. The solution should allow guests to connect their own devices to the network, be redirected to a portal, log in, and be granted access transparently.

  What is one setting administrators should configure for this solution?

  A. ClearPass should be defined as the enhanced Web Auth (EWA) server.

  B. RADIUS MAC-Auth should be enabled on the guest ports.

  C. Web-Auth should be enabled on the guest ports.

  D. BYOD redirect should be enabled globally.

  Correct Answer: B

• Question 92:

  Refer to the exhibit.



  Switch-1 is routing traffic to 192.0.2.0/24 over a less-than-optimal path.

  Which issue could prevent Switch-1 from selecting the first route listed in the table as a best BGP route?

  A. It does not have AS 46501 configured on it.

  B. It has no route to 192.168.2.1 in its IP routing table.

  C. It has no network statement for 192.168.2.0/24 in its BGP configuration.

  D. It has learned the same route using OSPF.

  Correct Answer: B

• Question 93:

  A network administrator wants to use an ACL, acl1, to control traffic from devices in VLAN 12 as the traffic is routed out of VLAN 12. The ACL should not control traffic within the VLAN.

  Which keyword should the administrator enter at the administrator enter at the end of this command:

  Switch(config)# vlan 12 ip access-group acl1____

  A. in

  B. out

  C. vlan-in

  D. vlan-out

  Correct Answer: B

• Question 94:

  A company has a wireless Aruba solution and wired users that connect to AOS-Switches. The company wants deep insight into the types of applications that wired users run. The company also wants more control over the traffic.

  What can the company do to meet these goals?

  A. Use tunneled node to send traffic through an Aruba Mobility Controller

  B. Configure extended IP ACLs on the AOS-Switches to filter the traffic.

  C. Configure RMON receives on the switches.

  D. Set up remote traffic mirroring between the AOS-Switches and Aruba Mobility Controllers.

  Correct Answer: A

• Question 95:

  Refer to the exhibit.



  Switch-1 and Switch-2 are configured to provide VRRP in VLAN 2. Based on the output, what will happen when a client in VLAN 2 sends an ARP request for its default gateway IP address?

  A. Only Switch-2 will respond, and it will respond with its own MAC address.

  B. Only Switch-2 will respond, and it will respond with the virtual MAC address for VRID 2.

  C. Both Switch-1 and Switch-2 will respond, and both will respond with the virtual MAC address for VRID

  2.

  D. Both Switch-1 and Switch-2 will respond, and each will respond with its own MAC Address.

  Correct Answer: B

• Question 96:

  Refer to the exhibits. Exhibit 1.



  Exhibit 2.



  The exhibits show the current operational state for routes on Switch-3 to send all traffic to 172.16.0.0/16 through Switch-2 during normal operation.

  Which single configuration change creates the desired behavior?

  A. Set a cost of 100 in the redistribute static command on Switch-2 to change the external LSA metric.

  B. Change the OSPF external metric type to 1 on Switch-1, and set a cost of 100 on Switch-3 VLAN 104.

  C. Change the OSPF external metric type to 1 on Switch-1, and set a cost of 100 on Switch-3 VLAN 108.

  D. Set a cost of 100 in the redistribute static command on Switch-1 to change the external LSA metric.

  Correct Answer: D

• Question 97:

  Refer to the exhibits. Exhibit 1



  Exhibit 2



  A network administrator needs to understand why endpoints that use Switch-3 as their default router can no longer reach some resources. The exhibit shows the OSPF link state database (LSDB) on Switch-1 when the OSPF solution was first deployed and the current LSDB.

  What is a likely place to find the issue?

  A. in the connectivity status between Switch-3 and Switch-1

  B. in the connectivity status between Switch-1 and Switch-2

  C. in the Switch-1 OSPF Area 1 configuration settings

  D. in the Switch-3 OSPF Area 1 configuration settings

  Correct Answer: B

• Question 98:

  Refer to the exhibit.



  The company wants the fastest convergence and best load sharing of traffic over the links between Switch1 and the VSF fabric.

  Which technology should the network administrator implement on these links?

  A. RPVST+

  B. MSTP

  C. loop protection

  D. LACP

  Correct Answer: D

• Question 99:

  Refer to the exhibit.



  Switch-1 and Switch-2 are AOS-Switches, which are iBGP peers. ISP 1 and ISP 2 advertise some routes to the same Internet destinations. Switch-1 and Switch-2 must select between these routes based on AS path length.

  What is required for Switch-1 and Switch-2?

  A. iBGP synchronization enabled

  B. Multihop enabled for the connection to the iBGP neighbor

  C. ECMP disabled for BGP

  D. eBGP and iBGP administrative distance set to the same value

  Correct Answer: D

• Question 100:

  A network administrator needs to control traffic based on TCP or UDP application, as well as IP protocol, such as GRE or ICMP.

  What should the administrator configure for this purpose?

  A. a standard IP ACL and an extended MAC ACL only

  B. both a standard IP ACL and an extended MAC ACL

  C. an extended IP ACL only

  D. both a standard IP ACL and a standard MAC ACL

  Correct Answer: C
