Cisco CCNA 200-301 Questions & Answers

• Question 1401:

  Refer to the exhibit.



  What is preventing host A from reaching the internet?

  A. LAN and WAN network segments are different.

  B. The domain name server is unreachable.

  C. The default gateway should be the first usable IP address.

  D. IP address assignment is incorrect.

  Correct Answer: B

• Question 1402:

  Refer to the exhibit.



  The IPv6 address for the LAN segment on router R2 must be configured using the EUI-64 format. When configured which ipv6 address is produced by the router?

  A. 2001:db8:d955:1008:12D8:BAFE:FF01:1

  B. 2001:db8:d955:1008:4598:785F:FE25:1

  C. 2001:db8:d955:1008:1030:ABFF:FECC:1

  D. 2001:db8:d955:1008:10D8:BAFF:FEC2:1

  Correct Answer: D

• Question 1403:

  What is used to identify spurious DHCP servers?

  A. DHCPACK

  B. DHCPREQUEST

  C. DHCPOFFER

  D. DHCPDISCOVER

  Correct Answer: D

• Question 1404:

  Which AP mode is used for capturing wireless traffic and forwarding that traffic to a PC that is running a packet analyzer?

  A. bridge

  B. monitor

  C. rouge detector

  D. sniffer

  Correct Answer: D

  The controller enables you to configure an access point as a network “sniffer”, which captures and forwards all the packets on a particular channel to a remote machine that runs packet analyzer software. These packets contain information on

  time stamps, signal strength, packet sizes, and so on.

• Question 1405:

  What are two capabilities provided by VRRP within a LAN network? (Choose two.)

  A. redundancy

  B. granular QoS

  C. load sharing

  D. dynamic routing updates

  E. bandwidth optimization

  Correct Answer: AC

  Redundancy-VRRP enables you to configure multiple routers as the default gateway router, which reduces the possibility of a single point of failure in a network.

  Load Sharing-You can configure VRRP in such a way that traffic to and from LAN clients can be shared by multiple routers, thereby sharing the traffic load more equitably among available router

• Question 1406:

  Which components are contained within a virtual machine?

  A. physical resources, including the NIC, RAM, disk, and CPU

  B. configuration files backed by physical resources from the Hypervisor

  C. applications running on the Hypervisor

  D. processes running on the Hypervisor and a guest OS

  Correct Answer: A

  VM-that is, an OS instance that is decoupled from the server hardware-still must execute on hardware. Each VM has configuration as to the minimum number of vCPUs it needs, minimum RAM, and so on. The virtualization system then starts each VM on some physical server so that enough physical server hardware capacity exists to support all the VMs running on that host. So, at any one point in time, each VM is running on a physical server, using a subset of the CPU, RAM, storage, and NICs on that server.

• Question 1407:

  Which interface IP address serves as the tunnel source for CAPWAP packets from the WLC to an AP?

  A. service

  B. trunk

  C. AP-manager

  D. virtual AP connection

  Correct Answer: C

  The AP-manager IP address is used as the tunnel source for CAPWAP packets from the controller to the access point and as the destination for CAPWAP packets from the access point to the controller.

• Question 1408:

  What does a switch search for in the CAM table when forwarding a frame?

  A. source MAC address and aging time

  B. destination MAC address and flush time

  C. source MAC address and source port

  D. destination MAC address and destination port

  Correct Answer: D

• Question 1409:

  Which Windows command is used instead of the route print command to display the contents of the IP routing table?

  A. netstat-n

  B. ipconfig

  C. ifconfig

  D. netstat-r

  Correct Answer: D

• Question 1410:

  What is represented by the word "LB13" within this JSON schema?



  A. array

  B. value

  C. object

  D. key

  Correct Answer: B
