Cisco CCNA 200-301 Questions & Answers

• Question 201:

  Refer to the exhibit.



  A network engineer must provide configured IP addressing details to investigate a firewall rule Issue. Which subnet and mask Identify what is configured on the en0 interface?

  A. 10.8.0.0/16

  B. 10.8.64.0/18

  C. 10.8.128.0/19

  D. 10.8.138.0/24

  Correct Answer: C

• Question 202:

  What determines the sequence in which materials are planned during the material requirements planning (MRP) run?

  A. The control parameters of the MRP run

  B. The creation date of the materials

  C. The low-level code of the materials

  D. The replenishment lead time of the materials

  Correct Answer: C

• Question 203:

  What is a reason to implement IPv4 private addressing?

  A. Reduce the risk of a network security breach

  B. Comply with PCI regulations

  C. Comply with local law

  D. Reduce the size of the forwarding table on network routers

  Correct Answer: D

• Question 204:

  What is the difference between 1000BASE-LX/LH and 1000BASE-ZX interfaces?

  A. 1000BASE-ZX is supported on links up to 1000km, and 1000BASE-LX/LH operates over links up to 70 km.

  B. 1000BASE-LX/LH interoperates with multimode and single-mode fiber, and 10008ASE- ZX needs a conditioning patch cable with a multimode.

  C. 1000BASE-LX/LH is supported on links up to 10km, and 1000BASE-ZX operates over links up to 70 km

  D. 1000BASE-ZX interoperates with dual-rate 100M/1G 10Km SFP over multimode fiber, and 1000BASE-LX/LH supports only single-rate.

  Correct Answer: C

  1000BaseSX multi-mode fiber to 550 m.

  1000BaseLX/LH multi-mode fiber to 550 m. Single-mode fiber to 10 km.

  1000BaseZX single mode fiber to 70 km.

  https://www.cisco.com/c/en/us/products/collateral/interfaces-modules/gigabit-ethernet-gbic-sfp-modules/datasheet-c78-366584.html?dtid=osscdc000283

• Question 205:

  What is the primary purpose of private address space?

  A. conserve globally unique address space

  B. simplify the addressing in the network

  C. limit the number of nodes reachable via the Internet

  D. reduce network complexity

  Correct Answer: A

• Question 206:

  Refer to the exhibit.



  Wireless LAN access must be set up to force all clients from the NA WLAN to authenticate against the local database. The WLAN is configured for local EAP authentication. The time that users access the network must not be limited. Which action completes this configuration?

  A. Uncheck the Guest User check box

  B. Check the Guest User Role check box

  C. Set the Lifetime (seconds) value to 0

  D. Clear the Lifetime (seconds) value

  Correct Answer: B

  Lifetime valid range is 60 to 2,592,000 seconds, default is 86,400 seconds.

  For unlimited time Guest User has to be unchecked,

  https://www.cisco.com/c/en/us/td/docs/wireless/controller/7-6/configuration-guide/b_cg76/b_cg76_chapter_0101100.pdf

• Question 207:

  When should an engineer implement a collapsed-core architecture?

  A. for small networks with minimal need for growth

  B. the access and distribution layers must be on the same device

  C. for large networks that are connected to multiple remote sites

  D. only when using VSS technology

  Correct Answer: A

  A collapsed core architecture is typically implemented in small networks, wheres as a three tier architecture is deployed into larger networks where scalabily will be a factor

• Question 208:

  Which device segregates a network into separate zones that have their own security policies?

  A. IPS

  B. firewall

  C. access point

  D. switch

  Correct Answer: B

• Question 209:

  An engineer must configure neighbor discovery between the company router and an ISP



  What is the next step to complete the configuration if the ISP uses a third-party router?

  A. Enable LLDP globally.

  B. Disable CDP on gi0/0.

  C. Enable LLDP TLVs on the ISP router.

  D. Disable auto-negotiation.

  Correct Answer: A

• Question 210:

  Refer to the exhibit.



  The network engineer is configuring router R2 as a replacement router on the network After the initial configuration is applied it is determined that R2 failed to show R1 as a neighbor. Which configuration must be applied to R2 to complete the OSPF configuration and enable it to establish the neighbor relationship with R1?

  A. R2(config)#router ospf 1 R2(config-router)#network 192.168.1.0 255.255.255.0 area 2

  B. R2(config)#interface g0/0/0 R2(config-if)#ip ospf hello-interval 10

  C. R2(config)#interface g0/0/0 R2(config-if)#ip ospf dead-interval 40

  D. R2(config)#router ospf 1 R2(config-router)#router-id 192.168.1.2

  Correct Answer: C

  For OSPF the hello and dead timers must match to become neighbors. R1 is configured with a dead time of 40 seconds, while R2 is set to 45 seconds.
