Cisco CCNP Enterprise 300-410 Questions & Answers

• Question 231:

  Refer to the exhibit



  R2 has been receiving routes from R4 that originated outside AS300

  A network engineer configured an AS-Path ACL to avoid adding these routes to the R2 BGP table but the routes are still present in the R2 routing table Which action resolves the issue?

  A. Replace as-path access-list 1 with the ip as-path access-list 1 permit A300$ command

  B. Replace as-path access-list 1 with the ip as-path access-list 1 permit ..300." command

  C. Replace as-path access-list 1 with the ip as-path access-list 1 permit A300_ command.

  D. Replace as-path access-list 1 with the ip as-path access-list 1 permit A300." command

  Correct Answer: B

• Question 232:

  Which control plane process allows the MPLS forwarding state to recover when a secondary RP takes over from a failed primary RP?

  A. MP-BGP uses control plane services for label prefix bindings in the MPLS forwarding table

  B. LSP uses NSF to recover from disruption *i control plane service

  C. FEC uses a control plane service to distribute information between primary and secondary processors

  D. LDP uses SSO to recover from disruption in control plane service

  Correct Answer: D

• Question 233:

  Which router attaches the VPN label to incoming packets from CE routing?

  A. CE router

  B. core router

  C. P router

  D. PE router

  Correct Answer: D

• Question 234:

  Refer to the exhibit.



  The connected routers do not show up as OSPF neighbors. Which action resolves the issue?

  A. Change the R1 dead timer to 20.

  B. Change the R2 dead timer to 20.

  C. Change the R2 hello timer to 20.

  D. Change the R1 hello timer to 20.

  Correct Answer: A

• Question 235:

  Refer to the exhibit.



  R1 must advertise all loopback interfaces IP addresses to neighbors, but EIGRP neighbors receive a summary route. Which action resolves the issue?

  A. Redistribute connected routes into EIGRP Enable

  B. EIGRP on loopback Interfaces.

  C. Disable auto summarization on R1.

  D. Remove the 10.100.1.0/24 static route.

  Correct Answer: D

• Question 236:

  Refer to the exhibit.



  Users in VLAN46 cannot get the IP from the DHCP server. Assume that all the parameters are configured properly in VLAN 10 and on the DHCP server Which command on interlace VLAN46 allows users to receive IP from the DHCP server?

  A. ip dhcp-addreos 10.221.10.10

  B. ip dhcp server 10.221.10.10

  C. ip helper-addrets 10.221.10.10

  D. ip dhcp relay information trust-all

  Correct Answer: C

• Question 237:

  Refer to the exhibit.



  An engineer is investigating an OSPF issue reported by the Cisco DNA Assurance Center. Which action resolves the issue?

  A. One of the neighbor links is down Bring the interface up by running shut and no shut

  B. One of the interfaces is using the wrong MTU Match interface MTU on both links

  C. An ACL entry blocking multicast on the interfaces Allow multicast through the interface ACL

  D. One of the interfaces is using the wrong authentication Match interface authentication on both links

  Correct Answer: B

• Question 238:

  Refer to the exhibit.



  Not all connected and static routes of router B are received by router A even though EIGRP neighborship is established between the routers. Which configuration resolves the issue?



  A. Option A

  B. Option B

  C. Option C

  D. Option D

  Correct Answer: D

• Question 239:

  Refer to the exhibit



  An engineer configured NetFlow but cannot receive the flows from R1. Which two configurations resolve the issue? (Choose two )

  A. R3(config)#ip access-list extended DDOS R3(config-ext-nacl)#5 permit udp any host 10.66.66.66 eq 1090

  B. R4(config)#flow exporter FlowExporter1 R4(config-flow-exporter)#destination 10.66.66.66

  C. R3(config)#flow exporter FlowExporter1 R3(config-flow-exporter)#destination 10.66.66.66

  D. R1(config)#flow exporter FlowExporter1 R1(config-flow-exporter)#destination 10.66.60.66

  E. R4(config)#ip access-list extended DDOS R4(config-ext-naci)#5 permit udp any host 10.66.66.66 eq 1090

  Correct Answer: AE

• Question 240:

  Refer to the exhibit



  A customer reported an issue with a fiber link failure between RC and RE Users connected through the spoke location face disconnection and packet drops with the primary email server (172.16.16.1) but have no issues with the backup email server (172.16.26.1). All the router loopback IPs are advertised through the OSPF protocol. Which configuration resolves the issue?



  A. Option A

  B. Option B

  C. Option C

  D. Option D

  Correct Answer: B
