Cisco CCNP Enterprise 300-410 Questions & Answers

• Question 261:

  A company Is redesigning WAN infrastructure so that all branch sites must communicate via the head office and the head office can directly communicate with each site independently. The network engineer must configure the head office router by considering zero-touch technology when adding new sites in the same WAN infrastructure. Which configuration must be applied to the head office router to meet this requirement?



  A. Option A

  B. Option B

  C. Option C

  D. Option D

  Correct Answer: D

• Question 262:

  Refer to the exhibit



  While troubleshooting an issue on the network, an engineer notices that a TCP Connect operation failed on port 3000 between R101 and R201. Which command must be configured on R201 to respond to the R101 IP SLA configurations with a control connection on UDP port 1967?

  A. ip sla responder udp-echo ipaddress 1.1.1.1 port 1967

  B. ip sla responder tcp-connect ipaddress 1.1.1.1 port 3000

  C. ip sla responder tcp-connect ipaddress 2.2.2.2 port 3001

  D. ip sla responder

  Correct Answer: A

• Question 263:

  Refer to the exhibit.



  An engineer configured router R3 to redistribute the prefix 10.10.10.0/24 from OSPF into EIGRP R1 has no connectivity to the prefix. Which action enables receipt of prefixes on R1?

  A. R3 is advertising the 10.20.20 0'24 prefix with a TTL of 1, R3 must set the TTL to 2 for this prefix.

  B. R1 docs not have a neighbor relationship with R2. The EIGRP process should be cleared on R1.

  C. Duplicate router IDs on R1 and R3, R1 should modify its router ID.

  D. R1 is not receiving the next-hop IP address of R3. R2 must enable the network 10 20.20.0V24 within EIGRP.

  Correct Answer: B

• Question 264:

  Refer to the exhibit.



  The R1 OSPF neighbor is not receiving type 5 external LSAs for 132.108.2.0/24 and 132.108.3.0/24 networks. Which configuration command resolves the issue?

  A. access-list 1 permit 132.108.0.0 0.0.1.255

  B. access-list 1 permit 132.108.0.0 0.0.3.255

  C. access-list 1 permit 132.108.2.0 0.0.0.255

  D. access-list 1 permit 132.108.4.0 0.0.3.255

  Correct Answer: B

• Question 265:

  Which router translates the customer routing information into VPNv4 routes to exchange VPNv4 routes with other devices through MP-BGP?

  A. PE

  B. CE

  C. P

  D. VPNv4 RR

  Correct Answer: D

• Question 266:

  Refer to the exhibit.



  An error message "an OSPF-4-FLOOD_WAR" is received on SW2 from SW1. SW2 is repeatedly receiving its own link-state advertisement and flushes it from the network. Which action resolves the issue?

  A. Change area 5 to a normal area from a nonstub area

  B. Resolve different subnet mask issue on the link

  C. Configure Layer 3 port channel on interfaces between switches

  D. Resolve duplicate IP address issue in the network

  Correct Answer: D

• Question 267:

  Refer to the exhibit.



  Router R4 is configured correctly with default OSPF values. A network engineer configured R7 for OSPF. R7 must not be elected as a DR for the segment between R4-R7. The adjacency between R4 and R7 failed to form. Which configuration resolves the issue?



  A. Option A

  B. Option B

  C. Option C

  D. Option D

  Correct Answer: C

• Question 268:

  Refer to the exhibit.



  The IT manager received reports from users about slow application through network x. which action resolves the issue?

  A. Use the variance 2 command to enable load balancing.

  B. Increase the bandwidth from the service provider.

  C. Move the servers into the users subnet.

  D. Upgrade the IOS on router E.

  Correct Answer: A

  A. could potentially fix something... but very rarely. it's good to keep them updated but not because the older IOS's are necessarily slower. B. what would moving them into the same subnet even do? you still have to actually send the data to the server through the network, needlessly complicating things more. C. yeah lemme just ask my service provider for more bandwidth if things are slow. sounds reasonable. i mean, it would maybe be more plausible if we had reason to believe that was the problem but we don't, it appears that it's our own network causing issues.

  D. load balancing is the most likely to actually do something and is something we can control. might as well try this first.

• Question 269:

  Refer to the exhibit.



  The default route is not advertised to the neighboring router. Which action resolves the issue?

  A. Configure the redistribute static metric 200 subnets command under OSPF.

  B. Configure OSPF on the Dialer0 interface.

  C. Configure the network 0.0.0.0 255.255.255.255 area 0 command under OSPF.

  D. Configure the default-information originate command under OSPF.

  Correct Answer: D

• Question 270:

  A network administrator successfully established a DMVPN tunnel with one hub and two spokes using EIGRP. One of the requirements was to enable spoke-to-spoke tunnels through the hub router using EIGRP. Which configuration command must the engineer configure to meet the requirement?

  A. no ip eigrp 1 mode multipoint

  B. no ip eigrp 1 split-horizon

  C. no ip eigrp 1 tunnel-redirect

  D. no ip eigrp 1 mode mgre

  Correct Answer: B
