Cisco CCNP Enterprise 300-410 Questions & Answers

• Question 531:

  Refer to the exhibit. R1 is configured with IP SLA to check the availability of the server behind R6 but it kept failing.



  Which configuration resolves the issue?

  A. R6(config)#ip sla responder udp-echo ip address 10.10.10.1 port 5000

  B. R6(config)#ip access-list extended DDOS R6(config-ext-nacl)#5 permit icmp host 10.10.10.1 host 10.66.66.66

  C. R6(config)#ip sla responder

  D. R6(config)#ip access-list extended DDOS R6(config-ext-nacl)#5 permit icmp host 10.66.66.66 host 10.10.10.1

  Correct Answer: B

  In this IP SLA tracking, we don't need a IP SLA Responder so the command "ip sla responder" on R6 is not necessary.

  We also notice that the ACL is blocking ICMP packets on both interfaces E0/0 and E0/1 of R6 so we need to allow ICMP from source 10.10.10.1 to destination 10.66.66.66.

• Question 532:

  Refer to the exhibit. An engineer configured IP SLA on R1 to avoid the ISP link flapping problem, but it is not working as designed. IP SLA should wait 30 seconds before switching traffic to a secondary connection and then revert to the primary link after waiting 20 seconds, when the primary link is available and stabilized.



  R1# *Nov 18 15:38:59.956: track-sta (700) Change #8 ip sla 700, state Up -> Down *Nov 18 15:38:59.956: %TRACK-6-STATE: 700 ip sla 700 state Up -> Down *Nov 18 15:38:59.956: track-sta (700) ip sla 700 state Up -> Down *Nov 18 15:38:59.956: track-que (700) Queuing CHANGED client event for Static IP Routing *Nov 18 15:38:59.956: track-que (700) Unqueuing CHANGED client event for Static IP Routing *Nov 18 15:39:04.965: track-sta (700) Change #9 ip sla 700, state Down -> Up *Nov 18 15:39:04.965: %TRACK-6-STATE: 700 ip sla 700 state Down -> Up *Nov 18 15:39:04.965: track-sta (700) ip sla 700 state Down -> Up *Nov 18 15:39:04.965: track-que (700) Queuing CHANGED client event for Static IP Routing *Nov 18 15:39:04.965: track-que (700) Unqueuing CHANGED client event for Static IP Routing



  Which configuration resolves the issue?

  A. R1(config)#track 700 ip sla 700 R1 (config-track)#delay down 30 up 20

  B. R1 (config)#ip sla 700 R1(config-ip-sla)#delay down 30 up 20

  C. R1 (config)#ip sla 700 R1(config-ip-sla)#delay down 20 up 30

  D. R1(config)#track 700 ip sla 700 R1(config-track)#delay down 20 up 30

  Correct Answer: A

  "wait 30 seconds before switching traffic to a secondary connection" -> delay down 30 "then revert to the primary link after waiting 20 seconds" -> up 20 Under the track object, you can specify delays so we have to configure delay under "track 700 ip sla 700" (not under "ip sla 700").

• Question 533:

  The network administrator configured CoPP so that all HTTP and HTTPS traffic from the administrator device located at 172.16 1.99 toward the router CPU is limited to 500 kbps. Any traffic that exceeds this limit must be dropped.

  access-list 100 permit ip host 172.16.1.99 any ! class-map CM-ADMIN match access-group 100 ! policy-map PM-COPP class CM-ADMIN police 500000 conform-action transmit ! interface E0/0 service-policy input PM-COPP

  CoPP failed to capture the desired traffic and the CPU load is getting higher.

  Which two configurations resolve the issue? (Choose two.)

  A. interface E0/0 no service-policy input PM-COPP ! control-plane service-policy input PM-COPP

  B. policy-map PM-COPP class CM-ADMIN no police 500000 conform-action transmit police 500 conform-action transmit ! control-plane service-policy input PM-COPP

  C. no access-list 100 access-list 100 permit tcp host 172.16.1.99 any eq 80

  D. no access-list 100 access-list 100 permit tcp host 172.16.1.99 any eq 80 access-list 100 permit tcp host 172.16.1.99 any eq 443

  E. policy-map PM-COPP class CM-ADMIN no police 500000 conform-action transmit police 500 conform-action transmit

  Correct Answer: A

• Question 534:

  Refer to the exhibit. A network administrator is troubleshooting IPv6 address assignment for a DHCP client that is not getting an IPv6 address from the server.

  ipv6 dhcp server:

  ipv6 unicast-routing ! int e0/1 ipv6 enable ipv6 add 2001:11::1/64 ipv6 nd other-config-flag no shut ipv6 dhcp server IPv6Pool ! ipv6 dhcp pool IPv6Pool dns-server 2002:555::1 domain-name my.net

  ipv6 dhcp client:

  interface Ethernet0/1 no ip address ipv6 address dhcp ipv6 enable no shut



  Which configuration retrieves the client IPv6 address from the DHCP server?

  A. ipv6 address autoconfig command on the interface

  B. ipv6 dhcp server automatic command on DHCP server

  C. ipv6 dhcp relay-agent command on the interface

  D. service dhcp command on DHCP server

  Correct Answer: A

• Question 535:

  Refer to the exhibit.



  A junior engineer configured SNMP to network devices. Malicious users have uploaded different configurations to the network devices using SNMP and TFTP servers. Which configuration prevents changes from unauthorized NMS and TFTP servers?

  A. access-list 20 permit 10.221.10.11

  access-list 20 deny any log

  !

  snmp-server group NETVIEW v3 priv read NETVIEW access 20

  snmp-server group NETADMIN v3 priv read NETVIEW write NETADMIN access 20

  snmp-server community Cisc0Us3r RO 20

  snmp-server community Cisc0wrus3r RW 20

  snmp-server tftp-server-list 20

  B. access-list 20 permit 10.221.10.11 access-list 20 deny any log ! snmp-server group NETVIEW v3 priv read NETVIEW access 20 snmp-server group NETADMIN v3 priv read NETVIEW write NETADMIN access 20 snmp-server community Cisc0wrus3r RO 20 snmp-server community Cisc0Us3r RW 20 snmp-server tftp-server-list 20

  C. access-list 20 permit 10.221.10.11 access-list 20 deny any log

  D. access-list 20 permit 10.221.10.11

  Correct Answer: A

• Question 536:

  Refer to the exhibit. An engineer must block access to the console ports for all corporate remote Cisco devices based on the recent corporate security policy but the security team still can connect through the console port.



  Switch# ! line con 0 logging synchronous line aux 0 line vty 0 4 password cisco@123 login transport input ssh telnet ! end

  Which configuration on the console port resolves the issue?

  A. login and password

  B. exec 0 0

  C. transport input telnet

  D. no exec

  Correct Answer: D

  "no exec" will disable access to a line. It is used if we want to allow only outgoing session (and disable incoming session) so this command will block all console port access. There is no "exec 0 0" command. We can only find the "exec prompt" command in IOS Version 15.4(2)T4.



  The most similar command is "exec-timeout 0 0" command, which is used to prevent Telnet/SSH sessions from timing out.

• Question 537:

  Which OSI model is used to insert an MPLS label?

  A. between Layer 2 and Layer 3

  B. between Layer 5 and Layer 6

  C. between Layer 1 and Layer 2

  D. between Layer 3 and Layer 4

  Correct Answer: A

• Question 538:

  Which function does LDP provide in an MPLS topology?

  A. It enables a MPLS topology to connect multiple VPNs to P routers.

  B. It provides hop-by-hop forwarding in an MPLS topology for LSRs.

  C. It exchanges routes for MPLS VPNs across different VRFs.

  D. It provides a means for LSRs to exchange IP routes.

  Correct Answer: B

  LDP provides a standard methodology for hop-by-hop, or dynamiclabel, distribution in an MPLS network by assigning labels to routes that have been chosen by the underlying Interior Gateway Protocol (IGP) routing protocols. The resulting labeled paths, called label switch paths (LSPs), forward label traffic across an MPLS backbone to particular destinations.

  Reference:https://www.cisco.com/c/en/us/td/docs/ios-xml/ios/mp_ldp/configuration/12-4t/mp-ldp-12-4t-book.pdf

• Question 539:

  Which mechanism provides traffic segmentation within a DMVPN network?

  A. BGP

  B. IPsec

  C. MPLS

  D. RSVP

  Correct Answer: C

  To use the DMPVN Traffic Segmentation Within DMVPN feature you must configure Multiprotocol Label Switching (MPLS) by using the mpls ip command. Reference:https://www.cisco.com/c/en/us/td/docs/ios-xml/ios/sec_conn_dmvpn/configuration/xe-16/sec-conn-dmvpn-xe-16-book/sec-conn-dmvpn-dmvpn.html

• Question 540:

  What are two characteristics of IPv6 Source Guard? (Choose two.)

  A. requires the user to configure a static binding

  B. used in service provider deployments to protect DDoS attacks

  C. requires that validate prefix be enabled

  D. requires IPv6 snooping on Layer 2 access or trunk ports

  E. recovers missing binding table entries

  Correct Answer: AD

  This is how I see it: For source guard to operate, binding table entries need to exists. So, A or D are required.

  A) static binding -> yes, or use ipv6 snooping #security-level glean to populate the binding table

  B) to protect against DDOS -> yes, but not just for service providers (it's rather prefix guard)

  C) can be configured with validate address or validate prefix (not explicitly needed)

  D) snooping on L2 access or trunk -> yes, or create static bindings

  E) not source guard itself, but the snooping feature glean recovers missing binding table entries
