Cisco CCNP Enterprise 300-410 Questions & Answers

• Question 661:

  DRAG DROP

  Drag and drop the descriptions from the left onto the corresponding MPLS components on the right.

  Select and Place:



  Correct Answer:



• Question 662:

  DRAG DROP

  Arrange the below as per the recommended steps:

  Select and Place:



  Correct Answer:



• Question 663:

  DRAG DROP

  The steps for configuring BGP on Cisco IOS Router:

  Select and Place:



  Correct Answer:



• Question 664:

  DRAG DROP

  You are logged in to the DNA Center Client Health Dashboard. Under the client health, you see some color-coded fields that reflects the health status of the client devices. Drag the health scores on the left to their respective colors in the right.

  Select and Place:



  Correct Answer:



• Question 665:

  DRAG DROP

  An engineer must establish a connection between two CE routers for two customers with overlapping IP addresses Customer_a is connected to interfaces Gig0/0, and Customer_b is connected to interfaces Gig0/1. Routers CE1 and CE2 are configured as follows:



  Drag and drop the code snippets from the right onto the boxes in the configuration to establish the needed connection. Snippets may be used more than once.

  Select and Place:



  Correct Answer:



• Question 666:

  DRAG DROP

  Drag and drop the addresses from the left onto the correct IPv6 filter purposes on the right.

  Select and Place:



  Correct Answer:



  HTTP and HTTPs run on TCP port 80 and 443, respectively and we have to remember them.

  Syslog runs on UDP port 514 while NTP runs on UDP port 123 so if we remember them we can find out the matching answers easily.

  But maybe there is some typos in this question as 2001:d88:800:200c::c/126 only ranges from 2001:d88:800:200c:0:0:0:c to 2001:d88:800:200c:0:0:0:f (4 hosts in total).

  It does not cover host 2001:0D88:0800:200c::1f. Same for 2001:D88:800:200c::e/126, which also ranges from 2001:d88:800:200c:0:0:0:c to 2001:d88:800:200c:0:0:0:f and does not cover host 2001:0D88:0800:200c::1c.

• Question 667:

  DRAG DROP

  Drag and drop the DHCP messages from the left onto the correct uses on the right.

  Select and Place:



  Correct Answer:



  +

  server-to-client communication, refusing the request for configuration parameters: DHCPNAK

  +

  client-to-server communication, indicating that the network address is already in use: DHCPDECLINE

  +

  server-to-client communication with configuration parameters, including committed network address: DHCPACK

  +

  client-to-server communication, asking for only local configuration parameters that the client has already externally configured as an address: DHCPINFORM

  DHCPINFORM: If a client has obtained a network address through some other means or has a manually configured IP address, a client workstation may use a DHCPINFORM request message to obtain other local configuration parameters, such as the domain name and Domain Name Servers (DNSs). DHCP servers receiving a DHCPINFORM message construct a DHCPACK message with any local configuration parameters appropriate for the client without allocating a new IP address. This DHCPACK will be sent unicast to the client.

  DHCPNAK: If the selected server is unable to satisfy the DHCPREQUEST message, the DHCP server will respond with a DHCPNAK message. When the client receives a DHCPNAK message, or does not receive a response to a DHCPREQUEST message, the client restarts the configuration process by going into the Requesting state. The client will retransmit the DHCPREQUEST at least four times within 60 seconds before restarting the Initializing state.

  DHCPACK: After the DHCP server receives the DHCPREQUEST, it acknowledges the request with a DHCPACK message, thus completing the initialization process. DHCPDECLINE: The client receives the DHCPACK and will optionally perform a final check on the parameters. The client performs this procedure by sending Address Resolution Protocol (ARP) requests for the IP address provided in the DHCPACK. If the client detects that the address is already in use by receiving a reply to the ARP request, the client will send a DHCPDECLINE message to the server and restart the configuration process by going into the Requesting state.

  Reference https://www.cisco.com/c/en/us/support/docs/ip/dynamic-address-allocation-resolution/27470-100.html

• Question 668:

  DRAG DROP

  Drap and drop the MPLS concepts from the left onto the descriptions on the right

  Select and Place:



  Correct Answer:



• Question 669:

  DRAG DROP Drag and drop the LDP features from the left onto the descriptions on the right

  Select and Place:



  Correct Answer:



  Implicit null Label : LSR receives an MPLS header with the label set to 3 Ref :https://www.ciscopress.com/articles/article.asp?p=680824andseqNum=2 Explicit Null Label : packet is encapsulated in MPLS with the option of copying the IP precedence to EXP bit

  [Ref: https://www.ciscopress.com/articles/article.asp?p=680824andseqNum=2 ]

  Inbound Label Binding Filtering : Controls the amount of memory used to store Label Distribution Protocol (LDP) label bindings advertised by other devices.

  [Ref: : https://www.cisco.com/c/en/us/td/docs/ios-xml/ios/mp_ldp/configuration/15-sy/mp-ldp-15-sy-book/mp-ldp-inbound-filtr.html ]

  Entropy label : provides ways of improving load balancing by eliminating the need for DPI at transit Label Switching Routers (LSRs).

  [ Ref: https://www.cisco.com/c/en/us/td/docs/ios-xml/ios/mp_ldp/configuration/xe-16-8/mp-ldp-xe-16-8-book/mp-ldp-entropy.html ]

• Question 670:

  DRAG DROP

  Drag and drop the operations from the left onto the locations where the operations are performed on the right. Drag each definition on the left to the matching term on the right.

  Select and Place:



  Correct Answer:



  Label Switch Router

  1.

  Reads labels and forwards the packet based on the based on the label.

  2.

  Performs PHP

  Label Edge Router

  1 Assigns labels and unlabeled packets.

  2. Handles traffic between multiple VPNs
