Cisco CCNP Enterprise 300-430 Questions & Answers

• Question 241:

  Split Tunneling must be configured for traffic sent by the client to be classified based on packet content, using an ACL. To accomplish this, the packets must be either locally switched from Cisco FlexConnect AP or centrally-switched over CAPWAP. Which type of ACL must be configured to accomplish this switching?

  A. Interface

  B. CPU

  C. FlexConnect

  D. WLAN

  Correct Answer: C

  In a Cisco FlexConnect deployment, split tunneling allows the traffic sent by the client to be classified based on packet content using an Access Control List (ACL). In this context, the ACL is associated with the WLAN (Wireless LAN) configuration. The ACL defines which traffic should be locally switched at the FlexConnect Access Point (AP) or centrally switched over CAPWAP (Control and Provisioning of Wireless Access Points) to the Wireless LAN Controller (WLC).

• Question 242:

  Refer to the exhibit.





  Global multicast has been configured for multicast-multicast, but multicast is not functioning on any of the WLANs in the network. Which action enables multicast?

  A. Set the AP to local.

  B. Set the radio policy to All on the WLAN.

  C. Enable the Multicast VLAN feature.

  D. Enable WLAN advanced settings to support multicast-multicast mode.

  Correct Answer: C

• Question 243:

  An engineer configures QoS on an AireOS WLC v8.5. The engineer configures a WLAN for voice traffic and must give a higher priority to WMM clients than to non-WMM clients. Which two configurations should be performed? (Choose two.)

  A. Implement the Gold QoS profile.

  B. Set Multicast Default Priority to Voice.

  C. Set Unicast Default Priority to Platinum.

  D. Select Video from the Unicast Default Priority drop-down menu.

  E. Implement the Platinum QoS profile.

  Correct Answer: CE

• Question 244:

  During discovery, one out of five fabric-enabled WLAN controllers is not being properly discovered. The firewall rules are the same for all the controllers. Which element is missing?

  A. YANG

  B. SNMP management

  C. SNMP trap

  D. NETCONF

  Correct Answer: B

• Question 245:

  An engineer configures an AireOS WLC v8.2 that has Cisco Aironet 3700 Series APs and Cisco Hyperlocation modules. The engineer deploys and enables a WLAN that has Hyperlocation. During testing, the engineer notices poor location accuracy when the packets arrive. Which action resolves the issue?

  A. Open SNMP port 161 and NMSP port 16113 on the WLC.

  B. Enable Hyperlocation in the Global Configuration settings of the WLC.

  C. Wait 60 to 90 minutes for RRM to settle before recording location measurements.

  D. Install the software code for the WLC that supports the Hyperlocation module.

  Correct Answer: C

• Question 246:

  Which Cisco Prime Infrastructure report does an engineer run to troubleshoot client connectivity issues for a VoWiFi network?

  A. Up/Down Statistics

  B. Traffic Stream Metrics

  C. Airtime Fairness Statistics

  D. 802.11 Counters

  Correct Answer: B

• Question 247:

  An engineer can log in to a WLC but cannot log in to the AP. Which configuration change allows the engineer to log in to the AP without changing the global login policy?

  A. Change the WLC password.

  B. Set up AAA override.

  C. Override the credentials.

  D. Reload the WLC.

  Correct Answer: C

• Question 248:

  An engineer supports the network infrastructure within a football stadium, and there is a new requirement to send media over wireless. Multicast direct must be used to optimize multicast communication over wireless. Which multicast address must be added in the media stream configuration to meet this requirement?

  A. WLC multicast address

  B. video server multicast destination address

  C. AP multicast address group

  D. RP multicast address

  Correct Answer: B

• Question 249:

  After the rogue reports from Cisco Prime Infrastructure are reviewed, it is determined that the automatic rogue mitigation is not working as planned. Which security measure must be taken to help prevent rogue APs from being plugged into the network?

  A. Apply port security to the switch.

  B. Add a MAC filter to the switch.

  C. Apply a different version of spanning tree.

  D. Apply an IP access list to ports.

  Correct Answer: A

• Question 250:

  Refer to the exhibit.



  An engineer must identify jammer devices on the wireless network. The AP must scan all configured channels. Which AP mode must be configured to accomplish this?

  A. Monitor

  B. Local

  C. FlexConnect

  D. Bridge

  Correct Answer: A
