Cisco CCNP Data Center 300-615 Questions & Answers

• Question 161:

  An engineer removes a VMM domain from an endpoint group called EPG-1, but the distributed port group fails to be deleted. Which action must be taken to resolve the issue?

  A. Remove the port group manually.

  B. Migrate all virtual machines in the EPG-1 to different hypervisors.

  C. Remove the remaining EPGs from the VMM domain.

  D. Migrate all virtual machines in the EPG-1 to different port groups.

  Correct Answer: C

• Question 162:

  Refer to the exhibit.



  HSRP adjacency fails to form between Nexus7K-1 and Nexus7K-2. Which action should be taken to solve the problem?

  A. Configure preempt on one of the switches in the HSRP group.

  B. Configure the same HSRP priority between the two switches.

  C. Configure the correct subnet mask on Nexus7K-1.

  D. Configure HSRP version 2 on Nexus7K-2.

  Correct Answer: D

• Question 163:

  Refer to the exhibit.



  A network engineer has connected the Nexus switch management port to the Internet using DHCP to allow the Guest shell running on the switch to download Python packages. The engineer can ping google.com successfully from the Nexus switch, but the Guest shell failed to download any Python packages. Which action resolves the problem?

  A. Update the Python packages on the Cisco Nexus switch directly.

  B. Manually configure DNS in the Guest shell, even if it is claimed on the Cisco Nexus switch through DHCP.

  C. Manually configure NTP in the Guest shell.

  D. Connect Guest shell to data plane interfaces to be able to connect to the networks outside the Cisco Nexus switch.

  Correct Answer: B

• Question 164:

  Refer to the exhibit.



  vPC between switch1 and switch2 is not working. Which two actions are needed to fix the problem? (Choose two.)

  A. Match vPC domain ID between the two devices.

  B. Configure IP address on the interface.

  C. Activate VLANs on the vPC.

  D. Configure vPC peer link and vPC peer keepalive correctly.

  E. Configure one of the switches as primary for the vPC.

  Correct Answer: AD

• Question 165:

  Refer to the exhibit.



  Sw1 and Sw2 are two Cisco Nexus 9000 Series Switches that run Cisco NX-OS. They are VTEPs in the same vPC domain. Which statement describes what happens in this scenario?

  A. Sw1 drops all traffic because there is no (S, G) OIF list to encapsulate VXLAN multicast packets and send them out to the underlay network through the uplink interfaces.

  B. Sw1 performs the VxLAN multicast encapsulation and decapsulation for all traffic associated with the VxLAN VNIs.

  C. Sw1 and switch 2 perform the VxLAN multicast encapsulation and decapsulation for all traffic associated with the VxLAN VNIs, depending on the hashing.

  D. Sw2 did not send an IP PIM register to the rendezvous point for the multicast group of the VXLAN VNI.

  Correct Answer: B

• Question 166:

  Refer to the exhibit.



  An OSPF adjacency between Router-A and Router-B cannot reach the FULL state. Which action resolves the issue?

  A. Adjust the MTU on Router-A to 1600.

  B. Disable the check of the MTU value.

  C. Set the OSPF media type to point-to-point.

  D. Adjust the MTU on Router-B to 1604.

  Correct Answer: B

• Question 167:

  The Cisco Nexus switch is connected to a peer switch that is not running Cisco NX-OS. The switches are connected using port channel and are experiencing packet loss. Which action should be performed on the Cisco Nexus switch ports to resolve this issue?

  A. Turn on lacp suspend-individual.

  B. Turn on lacp graceful-convergence.

  C. Turn off lacp graceful-convergence.

  D. Turn off lacp suspend-individual.

  Correct Answer: C

• Question 168:

  Refer to the exhibit.



  The HSRP configuration in the exhibit fails to function. Which action resolves this issue?

  A. Enable IP redirects.

  B. Set the MTU to 1500 bytes.

  C. Configure HSRP version 2.

  D. Configure the same HSRP group on both devices.

  Correct Answer: A

• Question 169:

  Refer to the exhibit.



  The HSRP instance on both switches is showing as active. Which action resolves the issue?

  A. Configure the HSRP timers to be the same.

  B. Allow VLAN 100 between the switches.

  C. Configure the IP address of N9K-B on the same subnet as N9K-A.

  D. Configure preempt on only one of the switches.

  Correct Answer: B

• Question 170:

  An engineer is troubleshooting a fabric discovery failure. Which two requirements must an engineer verify about switch connectivity to solve the problem? (Choose two.)

  A. A Cisco APIC must be attached to a spine node only.

  B. A Cisco APIC must be attached to leaf nodes.

  C. Spine nodes must connect to other spine nodes.

  D. A Cisco APIC must be dual-attached to two separate spine nodes.

  E. Leaf nodes must connect to spine nodes only.

  Correct Answer: BE
