Cisco CCNP Collaboration 300-810 Questions & Answers

• Question 131:

  Which authentication method allows a user to log in to an SSO-enabled Cisco Unified Communications application by utilizing a Microsoft Windows login, thereby not requiring any credentials to be entered?

  A. Smart Card

  B. OAuth

  C. form-based

  D. Kerberos

  Correct Answer: D

• Question 132:

  An administrator is setting up the Cisco Unified IM and Presence on-premises high availability feature and wants the Server Recovery Manager to initiate failover after 90 seconds. However, failover is happening after 60 seconds How is this issue corrected?

  A. Change peer Heartbeat Timeout to 90 seconds.

  B. Change Keep Alive (Heartbeat) Interval to 90 seconds

  C. Change critical service delay to 90 seconds.

  D. Change keep Alive (Heartbeat) Timeout to 90 seconds.

  Correct Answer: D

• Question 133:

  An engineer is assisting a user who is reporting Jabber desk phone control issues. The user has two desk phones, but jabber controls only one of them. The user is mot given the option to select the second phone within the Jabber client. Everything else is functioning normally with Jabber and with both desk phones. Which action resolves this issue?

  A. Set the Owner User ID on the second phone

  B. Ensure that both phones are in the same device pool

  C. Add the problematic phone to the user's Controlled Devices list

  D. Enable "Allow Control of Device from CTI" on the second phone.

  Correct Answer: D

• Question 134:

  The collaboration infrastructure of a large company was hacked, which lead to toll fraud and a bill that was substantially higher than usual.Anengineer must configure Cisco Unity Connection to block all calls to international phone numbers and numbers that contain 10 digits and begin with 0.

  Which two rules must be configured in the Unity Connection restriction table?(Choose two.)

  A. 9!

  B. 0?????????

  C. 0XXXXXXXXX

  D. 9*

  E. 0-9*

  Correct Answer: BE

  References: https://www.cisco.com/c/en/us/td/docs/voice_ip_comm/connection/10x/administration/guide/10xcucsagx/10xcucsag170.html https://www.cisco.com/c/en/us/td/docs/voice_ip_comm/connection/10x/administration/guide/10xcucsagx/10xcucsag080.html

• Question 135:

  Refer to the exhibit

  A collaboration engineer is troubleshooting a Cisco Jabber for Windows client issue The end user reports that they cannot control their Cisco 8845 IP Phone from the Cisco Jabber client



  Which configuration addition to the end user profile resolves the issue?

  A. “Standard CTI allows control of phones supporting Xfer and conf” and the “Standard CTI Enabled” group.

  B. “Standard CTI allows control of all devices” and the “Standard CTI Enabled” group.

  C. “Standard CTI allows control of phones supporting rollover mode” and the “Standard CTI Enabled” group.

  D. “Standard CTI secure connection” and the “Standard CTI Enabled” group.

  Correct Answer: A

• Question 136:

  Refer to the exhibit.



  Cisco UCM is integrated with Cisco Unity connection via a SIP truck and is configured using a globalized dial plan (directory number are configured with "*"). Using cisco best practices, which implementation allows call transfers to internal directory numbers but not to PSTN numbers?

  A. remove PSTN-PT from Voicemail_CSS

  B. change the order of partitions to put GLOBAL-INTERNAL-PT first in Voicemail_CSS

  C. create a BLOCK-PSTN-PT partition and add it to Voicemail CSS

  D. block pattern +’ in the Cisco Unity restriction table

  Correct Answer: A

• Question 137:

  After integrating Cisco Unity Express with Cisco Unified Communications Manager Express, users report that the system does not respond to their digit presses.

  Which two configuration snippets resolve this issue? (Choose two.)

  A. dial-peer voice 6800 voip destination-pattern 5... session protocol sipv2 session target ipv4:10.3.6.127 dtmf-relay sip-kpml codec g729r8

  B. dial-peer voice 6800 voip destination-pattern 5... session protocol sipv2 session target ipv4:10.3.6.127 dtmf-relay sip-notify codec g711ulaw

  C. dial-peer voice 6800 voip destination-pattern 5... session protocol sipv2 session target ipv4:10.3.6.127 dtmf-relay rtp-nte codec g711ulaw

  D. dial-peer voice 6800 voip destination-pattern 5... session protocol sipv2 session target ipv4:10.3.6.127 dtmf-relay sip-kpml codec g711ulaw

  E. dial-peer voice 6800 voip destination-pattern 5... session protocol sipv2 session target ipv4:10.3.6.127

  dtmf-relay sip-notify

  codec g729r8

  Correct Answer: BC

• Question 138:

  A collaboration engineer is implementing toll fraud prevention on Cisco Unity Connection. The engineer wants to block calls to 9005551234 for any caller that reaches the Caller System Transfer conversation. Which configuration accomplishes this goal?

  A. 9005551234 blocked on the Default System Transfer Restriction Table

  B. 9005551234 blocked on the Default Outdial Restriction Table

  C. 900 blocked on the Default Transfer Restriction Table

  D. 900 blocked on the Default Outdial Restriction Table

  Correct Answer: A

• Question 139:

  A collaboration engineer is troubleshooting Cisco IM and Presence high availability. The system is version 10.x. The engineer has confirn that the server recovery manager service is configured using system defaults. The engineer notices that user sessions have not fallen back to the homed nodes.

  What is the cause this Issue?

  A. The engineer did not click the Fallback button for the redundancy group

  B. The user accounts were moved to the redundant server,

  C. The failed service Of server was offline longer than the Client Re-Login upper Lint setting.

  D. The failed service or server has not been active for at least 30 minutes.

  Correct Answer: A

• Question 140:

  An administrator is configuring call handlers in Cisco Unity Connection. The administrator must ensure that internal extensions are restricted so that callers must go through the company operator to reach employees, and so that callers hear an error message if they attempt to dial extensions directly. Which setting is configured to accomplish this task?

  A. Transfer Rules

  B. Caller Input

  C. Greetings

  D. Message Settings

  Correct Answer: B
