F5 F5 Certifications 301A Questions & Answers

• Question 111:

  Refer to the exhibit.



  A pool is contoured with four members. A user has a current connection established with 10.18.1.40. The virtual server has a persistence Profile configured.

  A. 10.18.1.10

  B. 10.18.1.20

  C. 10.18.1.40

  D. 10.18.1.30

  Correct Answer: C

• Question 112:

  A BIG IP device delivers the online shopping website https://shop.example.com. Two pool members

  handle the traffic. An iRule directs requests with the hip parameter "environment=development" to a third

  pool member for a staging environment.

  Which combination of profiles is needed at minimum?

  A. tcp, http, request logging

  B. tcp, http, clientssl

  C. tcp, clientssl, serverssl

  D. http, clientssl, persistence

  Correct Answer: B

• Question 113:

  A new web application is being deployed Mutual SSL authentication must be used to authenticate clients. Which of the following two tasks must be completed to meet the requirements? (Choose two)

  A. configure the server SSL profile with "Client Certificate" Set to require

  B. configure the client SSL profile with "Client Certificate" set to require

  C. instruct the desktop team to update the web browser to the most recent release

  D. generate a CSR to register a certificate with the CA

  E. configure the client SSL profile with the Trusted .Certificate Authorities

  Correct Answer: BE

• Question 114:

  An unwanted IP address tries to connect to the configuration utility via Self IP An LTM Specialist needs to block the attempts based on the IP address. How should the ITM Specialist block the attempts without affecting other users?

  A. SSH IP allow list

  B. Port lockdown

  C. Device trust

  D. Packet filter

  Correct Answer: D

• Question 115:

  An LTM Specialist is configuring a virtual server with an IP address. Which configuration is unsupported?

  A. Performance 14 virtual server with an HTTP profile

  B. Standard virtual server with an HTTP profile

  C. Performance 14 virtual server with a FastHTTP profile

  D. Standard virtual server with a TCP profile

  Correct Answer: A

• Question 116:

  A virtual server is experiencing intermittent port exhaustion. What should be done to fix this issue?

  A. add more SNAT addresses

  B. add more pool members

  C. enable advanced routing

  D. enable SNAT automap

  Correct Answer: A

• Question 117:

  Refer to the exhibit



  Given the bigip conf extract shown where the servers only talk http on port 80, which node will receive the next user request?

  A. 72.10.1.1

  B. 10.1.1.1

  C. 10.1.1.2 0

  D. 10.1.1.3

  Correct Answer: D

• Question 118:

  AN LTM Specialist is setting up a new HTTPS virtual server to decrypt client traffic. SNAT the traffic and send the encrypted traffic to the poor member, the client's IP address must be included in the traffic sent to the pool member. What is a complete set of profiles that must be configured for the virtual server to meet these requirements?

  A. TCP, Client SSL, Server SSL

  B. TCP , Server SSL, HTTP

  C. TCP, Client SSL, HTTP

  D. TCP, Client SSL, Server SSL, HTTP

  Correct Answer: D

• Question 119:

  A customer wants to select the pool for an application based on information found in the path of the URL.

  For example:

  http://www.example.com/app 1 should be sent to the app 1 pool http.//www.exampie.com/app 2 should be

  sent to the app2 pool Which two profiles need to be assigned to the virtual server? (Choose two.)

  A. Client SSL

  B. Persistence

  C. TTP Compression

  D. HTTP

  E. TCP

  Correct Answer: DE

• Question 120:

  An LTM device provides load balancing to a web application? The LTM device has two dual-core processors and a licensed SSL Transactions Per Second (TPS) limit of 500 CMP is enabled. TLS connections are used between client systems and virtual servers on the LTM device, as well as from the LTM device to servers used as part of LTM pool. TLS enabled virtual servers utilize certificates based on 2048-bit keys During a peak period. 2560 new TLS transactions per second are attempted to the web application via the LTM device. What will happen in this scenario?

  A. 560 new TLS transactions will be silently discarded due to the SSL TPS license limit

  B. Nothing: TLS transactions per second are NOT affected by an SSL TPS license limit

  C. 2060 new TLS transactions will be silently discarded due to the SSL TPS license limit

  D. Nothing: 2560 TLS transactions per second is within the SSI TPS license limit.

  Correct Answer: A
