Avaya Avaya Aura 3100 Questions & Answers

• Question 51:



  Consider the ARS Digit Conversion Table and ARS Digit Analysis Table shown in the exhibit. A user dials the sequence 9602323501 in a system where the number 9 is assigned to Automatic Route Selection (ARS) FAC. What Route Pattern will route the call?

  A. Route Pattern 1

  B. Route Pattern 2

  C. Route Pattern 3

  D. Route Pattern 4

  Correct Answer: D

• Question 52:

  A customer wants to connect two branch offices with an ISDN trunk, where each branch office has a PBX system.

  Which service Type Should you selected in the configuration of the trunk?

  A. Tie

  B. Tandem

  C. Operator

  D. Internal

  Correct Answer: A

• Question 53:

  You must add 500 new stations with a four digit length, starting with station 4500.

  What information must you populate in the dial plan analysis form?

  A. Dialed String = 4; Total Length =4; Call type = sta

  B. Dialed String = 45; Total Length =4; Call type = ext

  C. Dialed String = 4; Total Length =4; Call type = ext

  D. Dialed String = 45; Total Length =4; Call type = sta

  Correct Answer: C

• Question 54:

  When adding an IP Station type 96xx, which statement is true regarding the port field?

  A. It is automatically populated by the system as "IP".

  B. It must be populated as "SOOOXX"

  C. It must be populated with an available port on an MM712 or TN2214

  D. It must be populated with an available port on the LAN switch.

  Correct Answer: A

• Question 55:

  You must verify in a production system that the number of rings between each point for coverage paths is two rings. You access the system-parameters coverage-forwarding from and check that the value for the local coverage Subsequent Redirection/ CFWD No Answer interval field is set to 2.

  Which users will be affected by this setting?

  A. users belonging to a specific COR

  B. users belonging to a specific COS

  C. users belonging to a specific COS-group

  D. all users in the system

  Correct Answer: D

• Question 56:

  You must set the calling privileges for a user so that the user can make calls but not receive calls. You assign COR5to the user's station.

  What other settings must be completed?

  A. In COR 5, set calling party restriction = `origination' and called party restriction = `none'

  B. In COR 5, set calling party restriction = `outward' and called party restriction = `termination'

  C. In COR 5, set calling party restriction = `origination' and called party restriction = `termination'

  D. In COR 5, set calling party restriction = `none' and called party restrictions = `termination'

  Correct Answer: D

• Question 57:

  Your customer does not use an AAA server. You have been asked to add four new administrative users with a new user profile that has display only access and no maintenance for the same categories as profile 20.

  Which interface must be used?

  A. ASA with GED1

  B. ASA with terminal emulation

  C. SMI

  D. SMI or ASA

  Correct Answer: D

• Question 58:

  A user reports that when attempting to dial an external call to local number the system does nothing ?just silence.

  You interview the user as follows.

  You: What happens if you longer after you dial your number?

  User: once I waited for about half a minute, then I heard these tones that supported the something was wrong.

  You: Did the sound stay on the same pitch or did it change pitches back and forth?

  User: Back and forth one pitch higher than the other.

  You: OK, that helps. What did you dial to get an outside line?

  User: Nine (9)

  You: Thank you, I appreciate the information, I will get back with you shortly.



  With reference to the scenario shown in the exhibit, which action should you take?

  A. Re-administer the Dial Plan to requiring 10 digits for making local external calls

  B. Determine the correct Feature Access Code to make an external call and inform the user

  C. Re-administer the feature access code for the user's situation to dial `9' to make an external call.

  D. Do nothing to the Dial Plan but delete the "*" Feature Access Code

  Correct Answer: B

• Question 59:

  Security Violation show valid and invalid attempts to access the system using three types of codes.

  In addition to station security codes, which two types of codes are measured in security Violation reports? (Choose two)

  A. Barrier codes

  B. Access security gateway (ASG) codes

  C. Dial access codes (DAC)

  D. Authorization codes

  E. Administrative login codes

  Correct Answer: AD

• Question 60:

  For which purpose is Automatic Alternate Routing (AAR) used?

  A. Calls placed within a company over a public network

  B. Calls placed within a company over a private network

  C. Calls placed from outside a company over a private network

  D. Calls placed from outside a company over a public network

  Correct Answer: B
