Avaya Avaya Aura 3100 Questions & Answers

• Question 81:



  Consider the settings shown in exhibit displayed by using the display route ?pattern command. You must deny calls from users in COR 10 to use route pattern 1. What should the fault restriction level (FRL) for COR 10 be?

  A. 2

  B. 3

  C. 4

  D. 5

  E. 6

  Correct Answer: A

• Question 82:

  You need to configure a station so that when a department manager makes calls to employees the manager's calls will ring even though the called station might have Sent All Calls activated. Although the manager's station can be designated as a VIP telephone, the manger must be able to selectively activate this feature.

  Which feature addresses this need?

  A. Button activated Executive Calling

  B. FAC or button activated Automatic Inclusion

  C. FAC or button activated Priority Calling

  D. Button activated Send All Calls override

  Correct Answer: C

• Question 83:



  With reference to the Dial Plan Analysis Tables, how many codes are available in the system for activation / deactivation of features?

  A. 2

  B. 3

  C. 11

  D. 21

  Correct Answer: B

• Question 84:

  You have to add a new G650 Media Gateway to the system.

  Which command will perform this I

  A. add cabinet next

  B. add port network next

  C. add media ?gateway next

  D. add G6SO-port next.

  Correct Answer: C

• Question 85:

  Although not exactly the same, a bridged call appearance and a team button can perform some of the same functions.

  Which statement correctly contrasts the team button and bridged call appearance?

  A. The team button does not allow conferencing to an active call or speed dial to the monitored station.

  B. The team button allows conferencing to an active call and making outgoing calls for the monitored station.

  C. The bridged call appearance does not allow conferencing to an active call or speed dial to the mirrored station.

  D. The bridged call appearance allows conferencing to an active call and making outgoing calls for the mirrored station.

  Correct Answer: D

• Question 86:

  You want a user's station to be able to dial extension 5605 and 5608 only.

  Which station configuration will achieve this?

  A. Assign COR 11 to user' station, In COR11 Set COR-to COR calling permission = `n' for all except COR 10. Assign COR to 5605 and 5608. Ensure that these two CORs are not assigned to any other station object.

  B. The FRL = 7to user's station. FRL = 7 to station 5606 and 5608. Set FRL for all other stations to 6 and lesser

  C. Assign COR 10 to user's station. In COR 11, set CPR-to-COR calling permission = `n' for all except. Assign COR 11 to 5605 and 5608. Ensure that these two CORs are not assigned to any other object.

  D. The FRL = 5 to user's station, FRL = 7 to station 5606 and 5608. Set FRL for all other stations to 5 or lesser.

  Correct Answer: A

• Question 87:

  The Avaya Extension to Cellular feature provides users with the capability to have one administered telephone that supports communication manager features for both an office telephone and one outside cellular or wireless telephone, two

  fields must be set to "Yes" in order to use this functionality:

  Enhanced EC500 and extended Cvg/Fwd Admin.

  Which command do you use to verify the field settings?

  A. System-parameters features

  B. System-parameters customer-options

  C. System-parameters wireless

  D. System-parameters converge-forwarding

  Correct Answer: B

• Question 88:

  A remote user Avaya softphone to work from home reports that the client desktop application will not register. After verifying that the user has configured the softphone application to "point"to the current IP address of a Communication Manager Gatekeeper using an administered extension, you ask if the user supplied a password when logging on. The user confirms that the password was used on each log-on attempt.

  You look up the user's information and note that the type field is 4620 (IP telephone) and the security code field is.



  With reference to the scenario described in the exhibit, which action should you take to ensure that the user can use the IP SoftPhone?

  A. Change the IP SoftPhone field to y.

  B. Change the Converge Path 1 value to match the value in converge path 2.

  C. Change the message Lamp Ext value to match the extension number.

  D. Change the name in the name field to match the name as administered in the LDAP directory.

  Correct Answer: A

• Question 89:

  Communication Manager Backups are done through the system management interface (SMI).

  Which three statements about the Communication Manager backup function are correct? (Choose three)

  A. The backup function creates two complete files on the internal hardware drive.

  B. The backup function can create a file on a network device using protocols: SCP, SFTP, or FTP.

  C. The backup function can encrypt the file with a pass phrase.

  D. The backup is done dynamically and cannot be scheduled in advance.

  E. The full Backup option does not do Save Transaction Command Automatically before creating the backup file.

  Correct Answer: BCE

• Question 90:

  You are adding ten new IP telephones in a small company administered with a G430 Media Gateway and a S8300D ICC main server. The G430 has the S8300D inserted in the slot V1, and MM71 in the slot V2, and an MM712 in the slot V3. Which hardware module will act as Gatekeeper for the telephones?

  A. MM710

  B. MM712

  C. MGP on the media gateway

  D. S8300D server using Processor Ethernet (PE)

  Correct Answer: D
