Cisco CCNP Data Center 350-601 Questions & Answers

• Question 281:

  An engineer is implementing traffic monitoring for a server vNIC that is configured with fabric failover enabled. The requirement is for the traffic to be sent to an analyzer, even during a failure of one of the fabric interconnects. The analyzer is connected to unconfigured Ethernet ports on both fabric interconnects.

  Which configuration accomplishes this task?

  A. Create two traffic monitoring sessions with different names, one per fabric. Connect an analyzer on each FI as the destination for the monitoring session local to the FI.

  B. Create two traffic monitoring sessions with the same name, one per fabric. Connect the analyzer connected to FI-A as the destination for both monitoring sessions.

  C. Create two traffic monitoring sessions with different names, one per fabric. Connect the analyzer connected to FI-B as the destination for both monitoring sessions.

  D. Create two traffic monitoring sessions with the same name, one per fabric. Connect an analyzer on each FI as the destination for the monitoring session local to that FI.

  Correct Answer: D

  Because a traffic monitoring destination is a single physical port, a traffic monitoring session can monitor only a single fabric. To monitor uninterrupted vNIC traffic across a fabric failover, create two sessions, one per fabric and connect two analyzers. Add the vNIC as the traffic source using the exact same name for both sessions.

• Question 282:

  An engineer must configure Cisco Nexus 9000 Series Switches for Cisco UCS Director integration. The configuration must enable automated onboarding of the switches as they come online. For security purposes, the switches must have the bare minimum of connection methods enabled. The connection protocol must allow authentication through credentials. Which protocol must be configured on the switches to allow automated onboarding?

  A. SNMP

  B. Telnet

  C. SSH

  D. HTTPS

  Correct Answer: C

  https://www.cisco.com/c/en/us/td/docs/unified_computing/ucs/ucs-director/network-devices-mgmt-guide/6-5/cisco-ucs-director-network-devices-mgmt-65/cisco-ucs-director-network-devices-mgmt65_chapter_010.html#id_33557:~:text=Protocol%20drop%2Ddown%20list

  https://community.cisco.com/kxiwq67737/attachments/kxiwq67737/5668j-docs-dc-ucs-director/299/11/UCSD_Tech_Module_Nexus_Ethernet_v1.0.pdf

• Question 283:

  Which protocol does Cisco Hyperflex use to share data among nodes in a VMware vSphere environment?

  A. CIFS

  B. FCoE

  C. SMB

  D. NFS

  Correct Answer: D

• Question 284:

  Refer to the exhibit.



  A storage engineer must monitor the traffic from the file server to the FC analyzer. The file server and the database use the same storage array. Which configuration must be applied to the Cisco MDS 9000 Series Switch to accomplish this goal?



  A. Option A

  B. Option B

  C. Option C

  D. Option D

  Correct Answer: B

• Question 285:

  An engineer must generate a Cisco UCS Manager backup. The backup should include all logical configuration and contain all system and logical configuration settings. Which backup type should be selected to meet these requirements?

  A. system configuration

  B. logical configuration

  C. all configuration

  D. full state

  Correct Answer: C

• Question 286:

  The Cisco UCS blade chassis must send SNMPv3 traps to a network monitoring system. The SNMP trap messages should be authenticated and have protection from closure. Which SNMP security privileged level should be configured?

  A. noPriv

  B. auth

  C. noAuth

  D. priv

  Correct Answer: D

• Question 287:

  Refer to the exhibit.



  An engineer must implement VXIAN with anycast gateway. To accomplish this, an engineer must set up PIM Source-Specific Multicast for host reachability. Which IP address must be applied to interface loopback1 to accomplish this goal?

  A. 10.10.0.1/32

  B. 10.255.0.100

  C. 10.10.0.2/32

  D. 255.0.0.1/8

  Correct Answer: B

• Question 288:

  An engineer upgrades the bash on the Cisco Nexus 9000 Series Switch.



  Which command must be sed to complete the task?

  A. rpm -qa

  B. rpm -Uhv C. upgrade -U

  D. update -vh

  Correct Answer: B

• Question 289:

  A DevOps engineer must implement a bash script to query a REST API and return the available methods. Which code snippet completes the script?



  A. DELETE

  B. TRACE

  C. POST

  D. OPTIONS

  Correct Answer: C

• Question 290:

  Refer to the exhibit.



  An engineer is troubleshooting intermittent connectivity issues between the client PC and the DHCP server. What does the last package captured from the Cisco Nexus 2000 Series Switch indicate?

  A. The DCHP server releases the IP address from the client.

  B. The client receives an IP address from the DHCP server.

  C. The DHCP server sends an IP address via a broadcast message.

  D. The client sends a unicast message to receive an IP address from the DCHP server.

  Correct Answer: A
