Cisco CCNP Data Center 350-601 Questions & Answers

• Question 401:

  An administrator is implementing DCNM so that events are triggered when monitored traffic exceeds the configured percent utilization threshold. The requirement is to configure a maximum limit of 39913690 bytes that applies directly to the statistics collected as a ratio of the total link capacity. Which DCNM performance monitoring configuration parameter must be implemented to achieve this result?

  A. Absolute Values

  B. Baseline

  C. Util%

  D. Per Port Monitoring

  Correct Answer: A

• Question 402:

  A network administrator must perform a system upgrade on a Cisco MDS 9000 Series Switch. Due to the recent changes by the security team:

  1.

  The AAA server is unreachable.

  2.

  All TCP communication between the MDS 9000 Series Switch and AAA servers is disabled. Which actions must be used to perform the upgrade?

  A. Log in locally to the MDS 9000 Series Switch using a network-admin role and download the upgrade files from the remote TFTP server.

  B. Log in locally to the MDS 9000 Series Switch using a server-admin role and download the upgrade files from the remote FTP server.

  C. Log in to a server storing the upgrade files remotely using a server-admin role and download the files to the MDS 9000 Series Switch using SFTP.

  D. Log in to a server storing the upgrade files remotely using a network-admin role and download the files to the MDS 9000 Series Switch using HTTP.

  Correct Answer: A

  Of all the answer choices, only TFTP does not use TCP. TFTP is a UDP based protocol.

• Question 403:

  A company is investigating different options for IT automation tools. The IT team has experience with Python programming language and scripting using a declarative language. The proposed tool should be easy to set up and should not require installing an agent on target devices. The team will also need to build custom modules based on the Python programming language to extend the tool's functionality. Which automation tool should be used to meet these requirements?

  A. Ansible

  B. Chef

  C. Puppet

  D. NX-API

  Correct Answer: A

• Question 404:

  An engineer must implement an automation solution to allow the backup of the configuration of Cisco Nexus Series Switches to a centralized location. The solution must:

  1.

  support the team-developed custom monitoring scripts that are packaged using RPM packaging that the framework must support.

  2.

  be decoupled from the underlying Cisco Nexus operating system.

  3.

  have no impact on the operating system of the underlying switch if the resource contention occurs.

  4.

  use Python to expand the existing automation framework. Which solution meets these requirements?

  A. Guest Shell

  B. Vegas Shell

  C. Bash Shell

  D. TCL Shell

  Correct Answer: A

• Question 405:

  An engineer evaluates a UI-based infrastructure management system capable of monitoring and deploying standalone VXLAN BGP EVPN deployments. The storage administrators also need the solution to manage the Cisco MDS 9000 Series Switches. Which solution meets these requirements?

  A. DCNM

  B. Tetration

  C. UCSD

  D. Intersight

  Correct Answer: A

• Question 406:

  An engineer is using REST API calls to configure the Cisco APIC. Which data structure must be used within a POST message to receive a login token?

  A. {"aaaUser":{"attributes":{"name":"apiuser","pwd":"cisco123"}}}

  B.

  C. {aaaUser:{attributes:{name:apiuser,pwd:cisco123}}}

  D. apiusercisco123

  Correct Answer: A

  https://www.cisco.com/c/en/us/td/docs/switches/datacenter/aci/apic/sw/2-x/rest_cfg/2_1_x/b_Cisco_APIC_REST_API_Configuration_Guide/ b_Cisco_APIC_REST_API_Configuration_Guide_chapter_01.html

• Question 407:

  An engineer must use the Embedded Event Manager to monitor events that occur on a Cisco Nexus 9000 Series Switch. An environment variable needs to be created so that several policies use the monitored events in their actions. The

  external email server is represented by IP address 10.10.10.10. Which command sets the environment variable?

  A. n9k2# event manager environment mailserver "10.10.10.10"

  B. n9k2(config)# event manager environment mailserver "10.10.10.10"

  C. n9k2(config-applet)# environment mailserver "10.10.10.10"

  D. n9k2(config)# event manager policy environment mailserver "10.10.10.10"

  Correct Answer: B

  To set an Embedded Event Manager (EEM) environment variable, use the event manager environment command in global configuration mode. To disable an EEM environment variable, use the no form of this command. https://www.cisco.com/c/en/us/td/docs/ios-xml/ios/eem/command/eem-cr-book/eem-cr-e1.html

• Question 408:

  A network engineer must prevent data corruption due to cross fabric communication in an FCoE environment. Which configuration must be applied to the Cisco Nexus Unified Switches to achieve this objective?

  A. switch(config-if)# shutdown lan

  B. switch(config-if)# no fcoe fcf-priority 0

  C. switch(config)# fcoe fcmap 0e.fc.2a

  D. switch(config)# no fcoe fcf-priority 255

  Correct Answer: C



  https://www.cisco.com/c/en/us/td/docs/switches/datacenter/nexus5000/sw/fcoe/ b_Cisco_Nexus_5000_Series_NXOS_Fibre_Channel_over_Ethernet_Configuration_Guide_/ Cisco_Nexus_5000_Series_NX-OS_Fibre_Channel_over_Ethernet_Configuration_Guide__chapter3.html

  You can prevent data corruption due to cross-fabric talk by configuring an FC-Map that identifies the Fibre Channel fabric for this Cisco Nexus device. When the FC-Map is configured, the switch discards the MAC addresses that are not part of the current fabric. switch(config)# fcoe fcmap fabric-map Configures the global FC-Map. The default value is 0E.FC.00. The range is from 0E.FC.00 to 0E.FC.FF.

  https://www.cisco.com/c/en/us/td/docs/switches/datacenter/nexus5000/sw/fcoe/513_n1_1/b_Cisco_n5k_fcoe_config_gd_re_513_n1_1/_Cisco_n5k_fcoe_config_gd_re_513_n1_1_c hapter_011.html

• Question 409:

  A network engineer configures a converged network adapter (CNA) and must associate a virtual Fibre Channel 7 interface to VSAN 7. The CNA is connected to the interface Eth1/7, and VLAN 700 is mapped to the VSAN. Which configuration

  must be applied to create the virtual Fibre Channel interface and associate it with the Ethernet physical interface?

  A. switch(config)# interface vfc 7 switch(config-if)# bind interface ethernet 1/7

  B. switch(config)# vlan 700 switch(config-vlan)# fcoe vsan 7

  C. switch(config)# vsan database switch(config-vsan)# vsan 7 interface vfc 7

  D. switch(config)# interface ethernet 1/7 switch(config-if)# vfc 7 attach vlan 1,700

  Correct Answer: A

• Question 410:

  A company is running a pair of Cisco Nexus 7706 Series Switches as part of a data center segment. All network engineers have restricted read-write access to the core switches. A network engineer must add a new FCoE VLAN to allow traffic from servers toward FCoE storage. Which set of actions must be taken to meet these requirements?

  A. 1. Assign the network-admin role to a user.

  2. Commit the role to the switch to the active user database.

  B. 1. Modify a network-operator role and add the required privileges.

  2. Assign a VDC-operator role to a user.

  C. 1. Create a user-defined role and add the required privileges.

  2. Assign a role to a user.

  D. 1. Add the required privilege to the VDC-admin role.

  2. Commit the changes to the active user database.

  Correct Answer: B
