Cisco CCNP Data Center 350-601 Questions & Answers

• Question 441:

  An engineer is implementing OTV on a transport that supports multicast. The solution needs to meet the following requirements:

  1.

  Establish adjacency to the remote peer by using multicast.

  2.

  Enable OTV advertisements for VLAN 100 to the other site.

  Which two commands should be configured to meet these requirements? (Choose two.)

  A. otv site-vlan 100

  B. otv data-group 232.2.2.0/28

  C. otv use-adjacency-server 172.27.255.94

  D. otv extend-vlan 100

  E. otv control-group 232.1.1.1

  Correct Answer: DE

• Question 442:

  An engineer needs to install a new package on a Cisco Nexus 9000 Series Switch. What is the impact of running the install commit command on the switch?

  A. The switch is restarted after the upgrade is complete.

  B. The package is used after the switch is restarted

  C. The package is used in the running configuration.

  D. The previous package that was in use is deleted from bootflash.

  Correct Answer: B

• Question 443:

  Refer to the exhibit.



  Service degradation is reported on a VM that is deployed on a Cisco UCS blade server. The traffic from the vNIC is required to SPAN in both directions to a packet analyzer that is connected to UCS-A slot 2 port

  12. Which two commands are needed to complete the configuration? (Choose two.)

  A. UCS-A /org/service-profile/vnic/mon-src* # set direction both

  B. UCS-A /eth-traffic-mon/fabric/eth-mon-session' # create dest-interface 2 12

  C. UCS-A /org/service-profile/vnic/mon-src* # set direction receive transmit

  D. UCS-A /eth-traffic-mon/fabric/eth-mon-session # activate

  E. UCS-A /eth-traffic-mon/fabric/eth-mon-session* # create eth-mon-session/dest-interface 2 12

  Correct Answer: AB

  https://www.cisco.com/en/US/docs/unified_computing/ucs/sw/cli/config/guide/1.4.1/CLI_Config_Guide_1_4_1_chapter42.html

• Question 444:

  An engineer must ensure fabric redundancy when implementing NPV mode on a Cisco MDS 9000 Series Switch. Which action enables fabric redundancy?

  A. Connect the NPV devices to multiple upstream switches.

  B. Add a port channel to upstream switches.

  C. Configure the NPV devices to use on external FLOGI database.

  D. Use TE ports to connect to upstream switches.

  Correct Answer: B

• Question 445:

  What is required for using puppet in a Cisco NX-OS environment?

  A. Open Agent Container

  B. XML management interface

  C. NX-API

  D. OpenNP

  Correct Answer: A

• Question 446:

  Which adjacency server configuration makes two OTV edge devices located in the same site bring up the dual-site adjacency?



  A. Option A

  B. Option B

  C. Option C

  D. Option D

  Correct Answer: B

• Question 447:

  An engineer installed a new Nexus switch with the mgm0 interface in vrf management. Connectivity to the rest of the network needs to be tested from the guest shell of the NX-OS. Which command tests connectivity from the guest shell of the NX-OS?

  A. [guestshell@guestshell ~]$ dohost ''ping vrf management 173.37.145.84''

  B. [guestshell@guestshell ~]$ chvrf management ping 173.37.145.84

  C. [guestshell@guestshell ~$ ping 173.37.145.84 vrf management

  D. [guestshell@guestshell ~]$ iping vrf management ip 173.37.145.84

  Correct Answer: B

  Reference: https://www.cisco.com/c/en/us/td/docs/switches/datacenter/nexus9000/sw/7-x/programmability/guide/b_Cisco_Nexus_9000_Series_NX-OS_Programmability_Guide_7x/Guest_Shell.html

• Question 448:

  What are two capabilities of the Cisco Network Assurance Engine? (Choose two.)

  A. It verifies the speed of network packet flows by using telemetry.

  B. It predicts the network load on a data center.

  C. It validates that devices comply with network security policies.

  D. It ensures that network performance meets an SLA.

  E. It predicts the impact of changes to the network.

  Correct Answer: CE

  1.

  Predict the impact of network changes

  2.

  Verify network-wide behavior

  3.

  Ensure network security policy and compliance https://www.cisco.com/c/en/us/products/collateral/data-center-analytics/network-assurance-engine/at-a-glance-c45-740230.html

• Question 449:

  Refer to the exhibit.



  An engineer configures FCIP on a Cisco MDS 9000 Series switch. What is the result of implementing the configuration?

  A. The switch attempts to make two TCP connections

  B. Compression is performed by using hardware

  C. Mode2 is enabled by default.

  D. Compression is performed by using software.

  Correct Answer: B

  https://www.cisco.com/c/en/us/td/docs/switches/datacenter/mds9000/sw/8_x/config/ip_serv ices/ipsvc/cfcip.html

• Question 450:

  An engineer is converting a Cisco MDS switch to support NPIV mode. What should be considered when implementing the solution?

  A. It must be enabled on VSAN 1 only.

  B. It must be enabled globally on all VSANs.

  C. It requires mapping of external interface traffic.

  D. It requires the FLOGI database to be disabled.

  Correct Answer: B

  https://www.cisco.com/c/en/us/td/docs/switches/datacenter/mds9000/sw/5_0/configuration/guides/int/nxos/cli_interfaces/npv.html
