Cisco CCNP Data Center 350-601 Questions & Answers

• Question 471:

  Refer to the exhibit.



  Why does the python code for Cisco NX-API print error message?

  A. The "type" is wrong in the header of the request and should be "cli_ conf".

  B. NX-API does not allow configuration for features via the requests module.

  C. The "type" is wrong is the body of the request and should be "cli_ conf".

  D. The JSON is not a supported format for the NX-API.

  Correct Answer: C

• Question 472:

  Refer to the exhibit.



  What is the result of this series of commands?

  A. It reboots the server immediately.

  B. It verifies the firmware update on the server.

  C. It activates the firmware on the next adapter boot.

  D. It updates the firmware on adapter 1/1/1 immediately.

  Correct Answer: C

  https://www.cisco.com/c/en/us/td/docs/unified_computing/ucs/ucs-manager/CLI-User- Guides/Firmware- Mgmt/4-0/b_UCSM_CLI_Firmware_Management_Guide_4- 0/ b_UCSM_CLI_Firmware_Management_Guide_4-0_chapter_011.html



• Question 473:

  Refer to the exhibit.



  Which statement about the ERSPAN configuration in this environment is true?

  A. Host A is the source of ERSPAN spanned traffic and host B is the traffic analyzer.

  B. Host B is the source of ERSPAN spanned traffic and host A is the traffic analyzer.

  C. The session number of the source of ERSPAN spanned traffic must have a session ID of 48 for the traffic analyzer to receive the traffic.

  D. The session number of the source of ERSPAN spanned traffic must have a session ID of 47 for the traffic analyzer to receive the traffic.

  Correct Answer: A

• Question 474:

  An engineer is asked to use SaaS to manage Cisco computing. Which two items are needed to accomplish the task? (Choose two.)

  A. UCS Manager

  B. Node name/Serial Number

  C. Device/Claim ID

  D. UCS Central

  E. Intersight

  Correct Answer: AE

  https://www.cisco.com/c/en/us/products/collateral/cloud-systems-management/intersight/intersight-ds.html

• Question 475:

  An engineer is enabling port security on a Cisco MDS 9000 Series Switch. Which feature of enabling port security on a Cisco MDS 9000 Series Switch must be considered?

  A. It always learns about switches that are logging in.

  B. It can be distributed by using Cisco Fabric services.

  C. It authorizes only the configured sWWN to participate in the fabric.

  D. It binds the fabric at the switch level.

  Correct Answer: B



  https://www.cisco.com/c/en/us/td/docs/switches/datacenter/mds9000/sw/6_2/configuration/guides/security/nx-os/sec_cli_6-x/psec.html#92130

• Question 476:

  An engineer is seeking the most optimal on demand CPU performance while configuring the BIOS settings of UCS C-series rack mount server.

  A. C0/C1 state

  B. C6 Retention

  C. C2 state

  D. C6 non-Retention

  Correct Answer: A

  https://www.cisco.com/c/en/us/td/docs/unified_computing/ucs/c/sw/gui/config/guide/4_0/b_Cisco_UCS_C-Series_GUI_Configuration_Guide_for_S3260_Servers_40/b_Cisco_UCS_CSeries_GUI_Configuration_Guide_for_S3260_Servers_40_appendix_010011.html

• Question 477:

  Refer to the exhibit.



  Which result of running the command is true?

  A. The PIM database is deleted.

  B. Multicast traffic forwarding is suspended.

  C. PIM join messages are suspended.

  D. MRIB is flushed

  Correct Answer: A

  When you restart PIM, the following tasks are performed: The PIM database is deleted. The MRIB and MFIB are unaffected and forwarding of traffic continues. The multicast route ownership is verified through the MRIB. Periodic PIM join and prune messages from neighbors are used to repopulate the database.

  https://www.cisco.com/c/en/us/td/docs/switches/datacenter/nexus9000/sw/6-x/multicast/configuration/guide/b_Cisco_Nexus_9000_Series_NX-OS_Multicast_Routing_Configuration_Guide/b_Cisco_Nexus_9000_Series_NXOS_Multicast_Routing_Configuration_Guide_chapter_011.html

• Question 478:

  Refer to the exhibit.



  What is configured as a result of running these commands?

  A. reverse lookup for outbound packets

  B. strict unicast RPF

  C. loose unicast RPF

  D. IP Source Guard

  Correct Answer: B

  https://tools.cisco.com/security/center/resources/unicast_reverse_path_forwarding

  The ip verify unicast source reachable-via rx command enables Unicast RPF in strict mode. To enable loose mode, administrators can use the any option to enforce the requirement that the source IP address for a packet must appear in the routing table.

• Question 479:

  A small remote office is set to connect to the regional hub site via NSSA ASBR. Which type of LSA is sent to the remote office OSPF area?

  A. type 7 LSA

  B. type 3 LSA

  C. type 1 LSA

  D. type 5 LSA

  Correct Answer: A

• Question 480:

  Refer to the exhibit.



  What is a characteristic presented in the service profile of the UUID?

  A. based on the hardware

  B. vendor assigned

  C. unique system generated

  D. allocated from a UUID pool

  Correct Answer: A

  There is no parameter for 'set identity dynamic-uuid' to specify a pool name-you can only state "derived" or a 32 hex character string (128-bits, therefore full UUID). ucspe /org/service-profile # set identity dynamic-uuid derived Derived FFFFFFFF-FFFF-FFFF-FFFF-FFFFFFFFFFFF Dynamic UUID The documentation, as usual for Cisco, is poor. Shagua references old v1.4.1 documentation but it's the same in 4.1. It's inaccurate as uuid-pool should now read uuid-suffix- pool. You can use UCSPE to check the CLI with contextual help. ucspe /org/service-profile # set identity dynamic-uuid Dynamic UUID dynamic-wwnn Dynamic WWNN uuid-suffix-pool UUID Suffix Pool wwnn-pool WWNN Pool If set identity dynamic-uuid only gives us the option of a static UUID or the parameter "derived", and set identity uuid-suffix-pool is the option to assign a pool... I would suggest that the most logical answer here is -derived from the hardware. https://www.cisco.com/en/US/docs/unified_computing/ucs/sw/cli/config/guide/1.4.1/CLI_Config_Guide_1_4_1_chapter27.html
