Traceout allows a route to be traced to a network using an Ethernet Routing Switch (ERS) 8600 CLI command. In the command output, the possible range of `w' values is 1-255.
The `w' value represents wait time for what?
A. Start of command execution
B. Time to live
C. Per probe
D. Completion of traceout report
A technician is adding the Virtual link Aggregation Control Protocol (VLACP) configuration to a Converged Campus Solution where all Ethernet Routing Switches
(ERSs) are directly connected without intermediary WAN transport devices.
What are two recommended configuration tasks? (Choose two.)
A. Configure all links to use the same timeout value.
B. For the Inter Switch Trunks (1ST) links, configure the long time-out value.
C. For the SMLT links, configure the long timeout value.
D. Configure all links to use a global reserved multicast MAC address for VLACP messages.
A technician discovers that an Ethernet Routing Switch (ERS) 8300 cat5e copper link is intermittent. The link connects a distant workstation to 8348GTX port 6/2. The cable path is undetermined at this point and it is suspected to traverse many patch panels. How can the ERS 8300 Time Domain reflectometer tool be of help in this situation?
A. The Virtual Circuit Test command config ethernet 6/2 vct test can detect opens, shorts, bad terminations.
B. The virtual circuit Repair command config ethernet 6/2 vct repair can detect the bad cable pairs and repair the cable by moving data to the good cable pairs.
C. The Virtual Circuit Echo command config ethernet 6/2 vct echo can detect the bad cable pairs only when connected to another ERS 8300.
D. The Virtual Circuit Detect command config ethernet 6/2 vct detect can detect how many patch panels are used between the device and switch and provide a percentage of dropped packets.
A customer is upgrading an existing ERS 8610 with the 8692SF to software version 7.x. Which statement regarding the upgrade is correct?
A. The customer must upgrade the 8692SF to an 8893SF for software release 7.x.
B. The customer can run 7.x with the existing 8692SF, although some features will be disabled.
C. The customer can add the SuperMezz module to the 8692SF and run release 7.x.
D. The customer must upgrade to an ERS 8810 chassis to run software release 7.x.
The ERS 8000 backplane hosts an EEPROM for storage of up to 4096 MAC addresses. The MAC addresses are automatically used up as they are assigned to which three of the following?
A. Switch physical ports
B. Multi-Link Trunking ports.
C. Multi-Link Trunking groups.
D. IPX interfaces.
E. VLANs.
The Ethernet Routing Switch (ERS) 8600 supports the feature IP VPN-Lite that does not require the use of an MPLS network. Which function does the ERS 8600 as a Provider Edge (PE) perform for IP VPN-Lite?'
A. The PE uses the Virtual Routing Forwarding (VRF) instances to provide traffic separation.
B. The PE provides route exchange with remote PE devices using OSPF.
C. The PE adds a shim header to the Ethernet header specifying which network the packet is crossing.
D. The PE incorporates Label Distribution Protocol across the core network to connect remote PE devices.
RSMLT Edge is enabled globally on two ERS 8800 switches. After recovering from a power outage some clients cannot communicate. A technician determined that only one of the core switches has recovered.
What should the technician check to ensure that this loss of communication does not occur in the event of a future power outage or other failure?
A. Turn off the Hold Up timer on both core switches.
B. Increase the Hold Up Timer to 9999 per VLAN for RSMLT Edge support.
C. Re-enable RSMLT Edge on each of the VLANs on both switches.
D. Set the VLAN to copy RSMLT info from a similarly configured VLAN.
Which set of procedures will upgrade the boot monitor on an Ethernet Routing Switch (ERS) 8600 with a single 8692SF module?
A. Copy the new image to flash.Activate the new image with SF module in service.
B. Copy the new image to flash.Boot the new image.
C. Copy the new image to flash.Modify the boot choice for run-time change.Activate the new image SF module in service.
D. Copy the new image to flash.Modify the boot choice for run-time image.Boot the new image.
When configuring Single Link Trunking (SLT) or Split Multi-Link Trunking (SMLT), what can be done to facilitate easily adding more VLANs to the network without impacting traffic?
A. 802.1Q-tag uplinks.
B. Disable STP on the ports.
C. Index the ports.
D. Use redundant MLTs.
An existing enterprise network is using Ethernet Routing Switch (ERS) 8600 switches in the campus core. It has been determined that 10 Gigabit links are required to replace the existing 1 gigabit uplinks will affect is connections on each of the ERS 8600 switches. Which statement describes how to accomplish this requirement in each ERS 8600 chassis?
A. Replace the two existing switches fabric modules with 8394SF systems.
B. Replace the two existing switch fabric modules with 8692SF and Supermez2
C. Replace the two existing 8616SXE modules with 8612XLRS modules.
D. Replace the six 8683XLK modules with 8612XLRS.
