Avaya ACIS 3605 Questions & Answers

• Question 81:

  A technician is setting up switch clustering using Split Multi-Link Trunking (SMLT). Which link is configured between the aggregation switches?

  A. Inter-switch trunk

  B. Multi-Link trunk

  C. Split MAC trunk

  D. LAG trunk

  Correct Answer: A

• Question 82:

  A technician is troubleshooting some IP telephones that are connected to an Ethernet Routing switch (ERS) 8300 8348TX-PWR I/O module. The IP telephones will not turn on. The 48V LED on the module has been checked and it is steady amber.

  A. 48V is present.

  B. PoE is disabled.

  C. 48V is not available.

  D. Module is booting.

  Correct Answer: D

• Question 83:

  Which group of commands will configure Ethernet Routing Switch (ERS) 8600 to deny any source in the multicast group from reaching the multicast receivers connected to ERS 8600-B?

  A. config ip prefix-list "2" add-prefix 10.1.1.0/30config vlan 2 ip igmp access-control 2 create 172.3.1.0 255.255.255.0 deny-tx

  B. config ip prefix-list "2" add-prefix 192.4.0-0/12config vlan 2 ip igmp access-control 2 create 172.3.1.0 255.255.255.0 deny-rx

  C. config ip prefix-list "2" add-prefix 238.1.1.0/24config vlan 2 ip igmp access-control 2 create 172.3.1.0 255.255.255.0 deny-tx

  D. config ip prefix-list "2" add-prefix 238.1.1.0/24config vlan 2 ip igmp access-control 2 create 194.4.10.0 255.255.255.0 deny-tx

  Correct Answer: C

• Question 84:

  Virtual forwarding eliminates the need for multiple physical routers. What is the difference in the Virtual Routing forwarding (VRF)-Lite configuration from Ethernet Routing switches (ERS) 8600/8800 to ERSS300?

  A. 8300 supports 250 virtual routers; ERS 8600/8800 supports 256.

  B. On ERS 8600/8800, VRF-Lite virtualizes the control and data plane as well as the routing tables.

  C. ERS 8300 supports Inter-VRF routing policies

  D. ERS 8600/8800 supports inter-VRF routing policies.

  Correct Answer: D

• Question 85:

  Based on the command line output shown in the exhibit, how many Gigabit Ethernet ports are available on this Ethernet Routing Switch (ERS) 8600?



  A. 16

  B. 24

  C. 26

  D. 28

  Correct Answer: C

• Question 86:

  The technician is setting up an Ethernet Routing Switch (ERS) 8300 switch for QoS. It has been determined that unimportant traffic will be marked on the edge of the network with a default IEEE 802.Ip setting off 0. Since the ERS 8300 is in the core, the traffic must be identified with the proper class of service. The technician has used JDM to look at the TrafficClass Map with the shown in the exhibit.



  What can be determined from the ERS 8300 parameters?

  A. The ERS 8300 mapping has been altered since the IEEE 802.lp settings do not map directly to the same Traffic Class.

  B. The ERS 8300 mapping is normal and should be left as is

  C. The ERS 8300 mapping will push the IEEE 802. ip setting off 0 above the network control traffic.

  D. The ERS 8300 as a core device will not use the IEEE 802.1 p to Traffic Class Map for this application.

  Correct Answer: A

• Question 87:

  Which statement describe step in provisioning SPBM in an Enterprise network?

  A. IP addresses on the core links.

  B. Enable SPBM and IS -IS globally on all nodes and on the core facing links.

  C. Configure the MAC table.

  D. Configure L2 and L3 VSNs on the core SPBM nodes.

  Correct Answer: B

• Question 88:

  Syslog in the Ethernet Routing Switch (ERS) 8600 allows the mapping of ERS 8600 errors to be Specified to the facility Local 0 Local 7. What is another piece of information that syslog provides?

  A. severity level

  B. message frequency

  C. syslog table location

  D. system status

  Correct Answer: A

• Question 89:

  The goal of the Converged Campus architecture is to provide a highly reliable infrastructure with subscribed failover preventing any interruption of traffic on the network? What are the two primary benefits of this design goal? (Choose two)

  A. In the event of a failure, no less of connectivity or application availability will be experienced by the end user.

  B. This architecture provides high performance Layer 3 switching, resiliency, security, and services.

  C. This design goal provides numerous connectivity options including Asynchronous Transfer Mode (ATM), Packet over SONET (POS), and 10 Gigabit Ethernet.

  D. The design goal provides the ability to provide hitless software upgrade for the core of the network.

  Correct Answer: AD

• Question 90:

  Not long after bootup of an upgraded Ethernet Routing Switch (ERS) 8310, the system hangs. Which statement describes the cause of this problem?

  A. The CPU module was configured in slot 5.

  B. An ERS 8600 module was configured in the 8300 chassis

  C. The system includes dual 839xSF modules

  D. The system was running in full duplex mode.

  Correct Answer: C
