Avaya Avaya Certifications 71300X Questions & Answers

• Question 31:

  Which three functionalities does WebRTC provide? (Choose three.)

  A. NAT / Firewall Traversal

  B. adds click-to-call capabilities from a web application to an Avaya endpoint

  C. Internet-friendly codecs and Privacy

  D. real-time audio and video conferencing

  Correct Answer: ABD

  *

  One of the primary differentiating features for the WebRTC Snap-in is that the web application handles authentication and authorization of calls. This includes the capability to assert a calling user's phone number and restrict the numbers that can be called.

  *

  The Avaya SBCE enables secure firewall traversal for HTTP and SRTP packets, facilitates sending DTLS to provide secured key exchange for the SRTP flow, and takes care of all security requirements mentioned in the TURN protocol for the solution.

  *

  WebRTC can be a game changer for enterprise communications and customer engagement. Enterprises can now add real-time communications to any website. References: Avaya WebRTC Snap-in Reference,

  Release 3.1 (May 2016), page 9 https://downloads.avaya.com/css/P8/documents/101013939

• Question 32:

  In which two locations is the Switch Password configured?

  A. In `ip-services' form on Avaya Aura Communication Manager (CM) and in `TSAPI link' on Avaya Aura Application Enablement Services (AES)

  B. In `ip-services' form on Avaya Aura Communication Manager (CM) and in `Switch Connection' on Avaya Aura Application Enablement Services (AES)

  C. In `cti-link' form on Avaya Aura Communication Manager (CM) and in `Switch Connection' on Avaya Aura Application Enablement Services (AES)

  D. In `cti-link' form on Avaya Aura Communication Manager (CM) and in `TSAPI link' on Avaya Aura Application Enablement Services (AES)

  Correct Answer: B

  Enabling AE Services refers to administering the transport link between Communication Manager and AE Services. Procedure

  1.

  Type change ip-services. Communication Manager displays the IP SERVICES form

  2.

  Complete Page 1 of the IP SERVICES form

  3.

  Complete Page 3 of the IP SERVICES form as follows. a. In the AE Services Server field, type the name of the AE Services server b. In the Password field, create a password. This is the password that the AE Services administrator must set on the AE Server (Communication Manager Interface > Switch Connections > Edit Connection > Switch Password). The passwords must exactly match on both Communication Manager and the AE Services server. References: Avaya Aura Application Enablement Services Administration and Maintenance Guide, Release 6.3 (June 2014) , page 26 https://downloads.avaya.com/css/P8/documents/100171737

• Question 33:

  What is the process for establishing a command line session to the AES Management IP Address, and logging in with the default account and default password?

  A. Use PuTTY to Rlogin to > AES Management IP Addr > using port 21, then enter login=admin password=admin.

  B. Use PuTTY to SSH to > AES Management IP Addr > using port 22, then enter login=craft password=crftpw.

  C. Use PuTTY to SSH to > AES Management IP Addr > using port 22, then enter login=cust password=custpw.

  D. Use PuTTY to SSH to > AES Management IP Addr > using port 222, then enter login=admin password=admin01.

  Correct Answer: B

  Use port 22, not port 21 or port 222. Log in as craft and use the default password. References: Application Enablement Services Installation and Upgrade Guide for a Bundled Server Release 4.0, page 29 https://downloads.avaya.com/elmodocs2/AES/4.0/02_300356_4.pdf

• Question 34:

  To which other component does the Avaya Aura Application Enablement Services (AES) Switch Connections connect?

  A. Avaya Aura Media Server (AAMS) using H.323

  B. Avaya Aura Session Manager (SM) using SIP

  C. Avaya Aura Communications Manager (CM) using H.323

  D. Avaya Aura Communications Manager (CM) using SIP

  Correct Answer: C

  Adding a switch connection

  The procedure include the following steps:

  1.From the AE Services Management Console main menu, select Communication Manager Interface >

  Switch Connections.

  2. On the Switch Connections page, in the Add Connection field, type a switch connection name (for

  example Switch1)

  For the Secure H323 Connection check box, do one of the following:

  *

  For Communication Manager6.3.6 or later and TLS for the H.323 Signaling Channel (normally associated

  with FIPS Mode), select the Secure H323 Connection check box.

  *

  For any previous release of Communication Manager without TLS for the H.323 Signaling Channel,

  uncheck the Secure H323 Connection check box.

  Etc.

  References: Avaya Aura Application Enablement Services Administration and Maintenance Guide, page

  73

  https://downloads.avaya.com/css/P8/documents/100171737

• Question 35:

  What are three ways of accessing Avaya Aura Application Enablement Services (AES) to perform administration? (Choose three.)

  A. with an Open X.11 terminal window

  B. with web access

  C. with remote access using Rlogin

  D. with local access using a system console

  E. with remote access using SSH

  Correct Answer: BDE

  B: You can use a Web browser to access the Application Enablement Services Management Console (AE Services Management Console). DE: Administrators can access the AE Services Linux shell (command prompt) either locally using a system console or remotely using a secure shell (ssh) client. This access method applies primarily to AE Services Technicians (craft users) who perform specific tasks, such as viewing trace logs, installing patches, and so forth. References: Avaya Aura Application Enablement Services Administration and Maintenance Guide , page 52 https://downloads.avaya.com/css/P8/documents/100171737

• Question 36:

  Which configuration must be completed before configuring a TSAPI link on Avaya Aura Application Enablement Services (AES)?

  A. A CTI link must be configured on Avaya Aura Communication Manager (CM) first.

  B. A Switch Connection must be configured on Avaya Aura Application Enablement Services (AES) first.

  C. A signaling-group must be configured on Avaya Aura Communication Manager (CM) first.

  D. A CTI-user must be configured on Avaya Aura Application Enablement Services (AES) first.

  Correct Answer: A

  If you are administering the AE Server for TSAPI, JTAPI, DMCC with Call Control, Telephony Web Service,

  or an AE Services integration (Microsoft or IBM Sametime), you must administer a CTI link from

  Communication Manager to AE Services.

  Follow these steps from a Communication Manager SAT to administer a CTI link type ADJ-IP.

  Procedure

  1.

  Type add cti-link , for example add cti-link 5.

  2.

  Complete the CTI LINK form as follows:

  a.

  In the Extension field, type , for example 70001.

  b.

  In the Type field, type ADJ-IP.

  c.

  In the Name field, type , for example aeserver1. References: Avaya Aura Application Enablement Services Administration and Maintenance, page 30 Guide https://downloads.avaya.com/css/P8/documents/100171737

• Question 37:

  Which four kinds of services does the TSAPI standard provide for third-party call control over Avaya Aura Communication Manager (CM)? (Choose four.)

  A. receiving notifications of events

  B. controlling specific calls or stations

  C. invoking CM features

  D. performing a remote reboot to the CM server

  E. completing the routing of incoming calls

  F. adding new feature buttons to agent sets

  Correct Answer: ABCE

  A: The services in the Event Report group provide a client application with the reports of events that cause

  a change in the state of a call, a connection, or a device.

  B: The services in the call control group enable a telephony client application to control a call or connection

  on Communication Manager. Typical uses of these services are:

  placing calls from a device

  controlling a connection for a single call.

  C: The services in the query group allow a client to query device features and static attributes of a

  Communication Manager device.

  E: The services in the routing group allow Communication Manager to request and receive routing

  instructions for a call from a client application. References: Avaya Aura Application Enablement Services

  TSAPI for Avaya Communication Manager Programmer's Reference Release 6.1, page 128

  https://downloads.avaya.com/css/P8/documents/100141354

• Question 38:

  In Avaya Aura Communication Manager (CM) for TSAPI, which type of CTI-link needs to be configured?

  A. ASAI-IP

  B. TSAPI-IP

  C. ADJ-IP

  D. DMCC-IP

  Correct Answer: C

  The Avaya AES server forwards CTI requests, responses, and events between Invision CTI Server and

  Communication Manager. The Avaya AES server communicates with Communication Manager over an

  AES link. Within the AES link, CTI links may be configured to provide CTI services to CTI applications such

  as Invision CTI. Step 1: Enter the display system-parameters customer-options command. On Page 3,

  verify that Computer Telephony Adjunct Links is set to y.

  Step 2: Enter the add cti-link m command, where m is a number between 1 and 64, inclusive. Enter a valid

  Extension under the provisioned dial plan in Avaya Communication Manager, set the Type field to ADJ-IP,

  and assign a descriptive Name to the CTI link.

  Etc.

  References: Application Notes for Invision CTI with Avaya Aura Communication Manager and Avaya Aura

  Application Enablement Services ?Issue 1.0, page 6 https://www.devconnectprogram.com/fileMedia/

  download/edd26666-ae98-4f15-9a2a- a156d0807160

• Question 39:

  What is the process for Web browsing to the AES Management Console, and logging in with the default account and default password?

  A. Error! Hyperlink reference not valid. Management IP Addr>:8443, then enter login=craft password=crftpw

  B. Error! Hyperlink reference not valid. Management IP Addr> then enter login=admin password=admin01

  C. Error! Hyperlink reference not valid. Management IP Addr> then enter login=admin password=admin

  D. Error! Hyperlink reference not valid. Management IP Addr> then enter login=cust password- custpw

  Correct Answer: D

  Log in to the AE Server as the default administrator (cust). Make sure that the URL begins with "https://"

  and the host name or IP address of the AE Services Server is correct.

  References: Avaya Aura Application Enablement Services Administration and Maintenance Guide,

  Release 6.3 (June 2014), page 56

  https://downloads.avaya.com/css/P8/documents/100171737

• Question 40:

  Which access control method is used by the Avaya Aura Application Enablement Services (AES) server for administrators?

  A. Single Administrator simple password login

  B. Challenge-Response shared-key method only

  C. System Manager AES Management Menu

  D. Role-Based Access Control

  Correct Answer: D

  Role Based Access Control (RBAC)

  Access to AE Services Management Console Web pages can be restricted by user authorization level.

  The operations that users are allowed to perform such as read, edit and delete can also be restricted.

  References: Avaya Aura Application Enablement Services Overview and Specification, Release 7.0.1,

  Issue 2 (June 2016), page 20

  https://downloads.avaya.com/css/P8/documents/101014052
