• Question 111:

  When should a performance baseline be captured?

  A. after the initial installation of the equipment, during normal daily operation

  B. after the initial installation of the equipment, during peak operating conditions

  C. before and after each step of the initial installation of the equipment

  D. three times a day during the first week following the initial installation of the equipment

  Correct Answer: A

• Question 112:

  Which HP Insight Diagnostics log displays POST errors?

  A. Test Log

  B. Error Log

  C. Integrated Management Log (IML)

  D. Sys Log

  Correct Answer: C

• Question 113:

  How does a c7000 enclosure retain air handling integrity when a server blade is removed?

  A. The enclosure design uses blank panels to prevent air loss.

  B. A blanking panel causes the air flow to reverse, allowing warmer air to escape.

  C. The enclosure uses a self-closing door to prevent air loss.

  D. The fans increase in revolutions per minute to increase air volume.

  Correct Answer: B

• Question 114:

  Which feature of the BL465c G7 allows the server to accommodate 16 DIMM slots and retain the half- height form factor?

  A. PCIe Gen 2 x8 mezzanine expansion slots

  B. AMD SR5690/SP5100 chipset

  C. Hot Plug Drive Drawer

  D. Smart Array P410i Controller with 1GB FBWC

  Correct Answer: B

• Question 115:

  Which interconnect can be used with the Fibre Channel over Ethernet (FCoE) capability of the new G7 Series of c-Class blades?

  A. HP 1/10Gb-F Virtual Connect Ethernet

  B. HP Virtual Connect Flex-10 10Gb Ethernet

  C. Virtual Connect FlexFabric

  D. HP ProCurve 6120G/XG interconnect

  E. HP Virtual Connect FC Module

  Correct Answer: C

• Question 116:

  What happens when you turn the enclosure UID to "On" on the Insight Display of a c7000 enclosure?

  A. The rear enclosure UID LED illuminates and the color of the Insight Display changes to blue.

  B. The front enclosure UID LED illuminates and the color of the Insight Display changes to blue.

  C. The rear enclosure UID LED illuminates and the color of the Insight Display changes to green.

  D. The front enclosure UID LED illuminates and the color of the Insight Display changes to green.

  Correct Answer: A

• Question 117:

  Which full-height device bays are in Zone 3 of a c7000 enclosure?

  A. 1 and 2

  B. 3 and 4

  C. 5 and 6

  D. 7 and 8

  Correct Answer: C

• Question 118:

  Which HP BladeSystem component is used for power allocation and control for all blades and interconnects?

  A. Rack and Power Manager

  B. Power Manager

  C. Onboard Administrator

  D. Insight Display

  Correct Answer: C

• Question 119:

  What is the maximum number of c3000 enclosures that can be installed in a 42U rack?

  A. 4

  B. 5

  C. 6

  D. 7

  Correct Answer: D

• Question 120:

  Which HP c-Class server blades take up two c3000 enclosure server bays? (Select two.)

  A. BL860c

  B. BL870c

  C. BL685 G7

  D. BL490 G6

  E. BL2x220c G6

  Correct Answer: AC
