HP HP ATP HP2-T26 Questions & Answers

• Question 181:

  Which statement is true about the background color of the Insight Display?

  A. If there is an error detected in the Insight Display, the background color will be amber regardless of the status of the enclosure UID indication.

  B. If the enclosure UID is active, the Insight Display background color will be blue.

  C. An Insight Display background color of green will override a red error indication.

  D. The enclosure UID cannot be enabled if there is an error detected by the Onboard Administrator.

  Correct Answer: B

• Question 182:

  Which processor type is used with the HP BL460c G6 Server Blade?

  A. Dual-Core Intel?Itanium?Processor

  B. Intel?Xeon?Processor

  C. HP PA-RISC FSB, double data rate

  D. AMD Opteron processor

  Correct Answer: B

• Question 183:

  What is needed to connect a Windows-based laptop to the c7000 or c3000 enclosure service port and successfully communicate with the Onboard Administrator?

  A. a laptop with the network interface set to DHCP and a null modem cable

  B. a laptop with the network interface set to DHCP and a standard CAT5 patch cable

  C. a laptop with the network interface set to an address in the 192.168.1.x range and a CAT5 crossover cable

  D. a laptop with the network interface set to an address in the 192.168.1.x range and a standard CAT5 patch cable

  Correct Answer: B

• Question 184:

  How can you access the RBSU to verify Advanced Processor settings? (Select two.)

  A. Press F9 during POST.

  B. Press F12 during POST.

  C. Use Windows RBSU Configuration Utility.

  D. Use HP Insight Diagnostics Offline Edition.

  E. Use BIOS USB Console.

  F. Use BIOS Serial Console.

  Correct Answer: AF

• Question 185:

  A c7000 enclosure is fully populated with power supplies. Each power supply will have 2400W available if the N+1 power mode is configured. What is the total amount of available power?

  A. 7200W

  B. 12000W

  C. 14400W

  D. 16800W

  Correct Answer: C

• Question 186:

  After replacing a defective memory module, you boot the latest version of SmartStart so you can run a custom diagnostic test to ensure that previous problems have been resolved. After loading HP Insight Diagnostics, which tab should you choose to set up a user-defined memory test?

  A. Complete Test

  B. Diagnose

  C. Quick Test

  D. Custom Test

  Correct Answer: D

• Question 187:

  A server has been shutting down sporadically for the past two months. VCRM is not installed and configured. Where can you locate the latest versions of firmware that are available for this server?

  A. PSP DVD

  B. SmartStart

  C. HP website

  D. server image file from two months ago

  Correct Answer: C

• Question 188:

  Which feature is supported by the zx2 chipset in the Integrity BL860c?

  A. hot spare and hot-plug of memory DIMMs

  B. up to 512GB of memory (not fully buffered DIMMs)

  C. memory DIMM error correction (chip sparing)

  D. 512-bit, 800MHz (800 MT/s, 1600MHz data rate) memory bus

  Correct Answer: C

• Question 189:

  How does humidity affect a data center? (Select two.)

  A. The potential for condensation increases when humidity increases.

  B. When humidity decreases within the data center, flexible joints become fragile.

  C. When humidity increases, the potential for ESD increases.

  D. The potential for condensation decreases when humidity decreases.

  E. When humidity increases within the data center, flexible joints become fragile.

  F. When humidity decreases, the potential for ESD increases.

  Correct Answer: AC

• Question 190:

  Both the c3000 and c7000 chassis have a capacity for a maximum of six power supplies. Which feature does the c3000 have that differentiates it?

  A. 2400W power supplies

  B. 12 v DC output

  C. 200-240VAC

  D. 1200W power supplies

  Correct Answer: B
