HP HP ATP HP2-T26 Questions & Answers

• Question 71:

  A rack with a c7000 is to be relocated to a remote location. What should be used when moving the rack to ensure no damage will occur to the enclosure?

  A. packaging foam

  B. shipping bracket

  C. stabilization kit

  D. ballast kit

  Correct Answer: B

• Question 72:

  Which mezzanine card is compatible with the HP ProCurve 6120XG interconnect?

  A. HP NC326m PCIe Dual-Port 1Gb Server Adapter

  B. Emulex LPe1105-HP 4Gb Fibre Channel HBA

  C. HP 4X QDR IB CX-2 Dual Port Mezz HCA for HP BladeSystem c-Class

  D. HP StorageWorks 80GB IO Accelerator for BladeSystem c-Class

  Correct Answer: A

• Question 73:

  When a customer is using a StorageWorks 3Gb SAS BL Switch in the c7000 enclosure, what can be connected?

  A. an EVA4400 storage array to the server blades in a c7000 enclosure

  B. a SB40c storage blade to the server blades in a c7000 enclosure

  C. an MSA2000sa to the server blades in a c7000 enclosure

  D. the internal SAS drives of the server blades to other resources

  Correct Answer: C

• Question 74:

  What is the default ASR timer value after the HP Server Health driver is loaded?

  A. 10 seconds

  B. 10 minutes

  C. 1 minute

  D. 1 hour

  Correct Answer: B

• Question 75:

  When installing half-height c-Class server blades in a c3000 rack enclosure, what is the recommended sequence for installing them into the server bays when viewed from the front of the enclosure?

  A. from top to bottom, then right to left

  B. from bottom to top, then right to left

  C. from top to bottom, then left to right

  D. from bottom to top, then left to right

  Correct Answer: D

• Question 76:

  Which capability does Intel QuickPath technology provide?

  A. automatically allows a processor core to run faster than the base operating frequency if it is operating below power, current, and temperature specification limits

  B. allows each processor core to feature an integrated memory controller and high-speed interconnect to deliver greater performance, bandwidth, and reliability

  C. allows applications to execute threads in parallel within each processor in a server platform to enhance performance and energy efficiency

  D. provides Dynamic Power Management and Rapid Virtualization Indexing to improve application performance

  Correct Answer: B

• Question 77:

  Which method should you use to remove a jammed cartridge from a tape blade?

  A. Remove the tape blade from the enclosure, send it in for repair and request the cartridge back.

  B. Press the Eject button for 10 seconds and wait up to 10 minutes for the tape to rewind.

  C. Remove the tape blade and open the enclosure with a torx screwdriver to remove the cartridge.

  D. Pull the release latch to force an emergency eject.

  Correct Answer: B

• Question 78:

  Which HP c-Class server blade series only supports non hot-plug SATA drives?

  A. 100 Series

  B. 200 Series

  C. 400 Series

  D. 600 Series

  Correct Answer: B

• Question 79:

  What does an HP warranty include? (Select two.)

  A. software support

  B. parts and labor

  C. downtime protection as needed

  D. flexible support levels

  E. hardware protection against manufacturer defect

  Correct Answer: BE

• Question 80:

  Which information is required for a warranty check for a BL490c G6 Server? (Select three.)

  A. country/region

  B. service agreement ID

  C. spare part number

  D. serial number

  E. date of purchase

  F. product number

  Correct Answer: ADF
