VMware VMware Certifications VCP-510 Questions & Answers

• Question 41:

  Which two statements are true about High Priority vMotion requests in vSphere 5.x? (Choose two)

  A. Migrations always proceed regardless of whether or not resources have been successfully reserved.

  B. Migrations do not proceed if resources are not successfully reserved.

  C. vCenter Server attempts to reserve resources on both the source and destination hosts to be shared among all concurrent migrations with vMotions.

  D. vCenter Server attempts to reserve resources on both the source and destinations hosts for each individual High Priority migration with vMotion.

  Correct Answer: AC

• Question 42:

  What are three methods of adding VMkernel networking to a vNetwork Distributed Switch? (Choose three)

  A. A VMkernel Network adapter can be created and added to a standalone port.

  B. A VMkernel network adapter can be created along with a VMkernel port group on the selected vNetwork Distributed Switch.

  C. A VMkernel port can be cloned from a vNetwork Standard Switch

  D. A VMkernel network adapter can be associated with a port group on a vNetwork Distributed Switch.

  E. A VMkernel port can be migrated from a vNetwork Standard Switch.

  Correct Answer: ADE

• Question 43:

  An administrator is enabling Enhanced vMotion Compatibility in a DRS cluster. The administrator wants the greatest degree of flexibility when adding new hosts in the cluster. Which setting satisfies this requirement?

  A. Any baseline compatible with the existing ESXi hosts in the cluster

  B. The highest baseline that is compatible with the ESXi hosts in the cluster

  C. The lowest baseline that is compatible with all ESXi hosts in the cluster

  D. The highest baseline that is compatible with vSphere 4.x and 5.x

  Correct Answer: C

• Question 44:

  When using a hardware iSCSI initiator with an ESXi host, which two tasks are performed by VMKernel? (Choose two)

  A. Encapsulation of iSCSI PDUs TCP/IP packets

  B. Mapping requests for blocks on the virtual disk to blocks on the appropriate physical device

  C. Issuing iSCSI commands to the virtual disk

  D. Encapsulation of I/O requests into iSCSI Protocol Data Units (PDUs)

  Correct Answer: BC

• Question 45:

  The database server administrator requests a virtual machine with a small system disk and a single data disk that must be 3TB in size. The storage administrator has already created a 3TB LUN. A 500GB VMFS3 datastore already exists. Which process will the vSphere administrator use to provision the data disk?

  A. No action is required on the VMFS3 Datastore. On that volume, creates a critical compatibility mode RDM mapping to the 3TB LUN.

  B. No action is required on the VMFS3 Datastore. On that volume, create a physical compatibility mode RDM mapping to the 3TB LUN.

  C. Upgrade the VMFS3 Datastore to VMFS5. On that volume, creates a physical compatibility mode RDM mapping to the 3TB LUN.

  D. Upgrade the VMFS3 Datastore to VMFS5. On that volume create a virtual compatibility mode RDM mapping to the 3TB LUN

  Correct Answer: C

• Question 46:

  An administrator has received calls about a virtual machine experiencing intermittent application issues during the evening. To troubleshoot, the administrator needs to capture the virtual machine in the state it is in during the evening hours for later analysis. Which two tasks would accomplish this requirement? (Choose two)

  A. Create a scheduled task to clone the virtual machine once per evening

  B. Create an alarm that is triggered when a loss of VMware Tools heartbeat to the virtual machine occurs.

  C. Use esxtop in batch mode and capture metrics during the evening hours.

  D. Create a scheduled task to create a snapshot of the virtual machine once per evening

  Correct Answer: CD

• Question 47:

  Which two methods can be used to migrate a virtual machine from a vNetwork Standard to a vNetwork Distributed Switch? (Choose two)

  A. Edit the virtual adapter settings for the ESXi host and select a dvPort group from the list.

  B. Migrate the port group containing the virtual machine from a vNetwork Standard Switch using the Migrate Virtual machine networking option.

  C. Use the Migrate Virtual machine networking option to select the virtual machine from a list of virtual machines.

  D. Edit the Network Adapter settings for the virtual machine and select a dvPort group from the list.

  Correct Answer: CD

• Question 48:

  A vSphere 5 environment has an ESXi 5 x host configured to boot from a Software iSCSI adapter. What is the expected outcome if the administrator attempts to disable the iSCSI Software adapter?

  A. The adapter will be disabled, but is re-enabled the next time the host boots up.

  B. The adapter will be disabled and the host will not boot the next time the host boots up

  C. The adapter will not be disabled and the vSphere Client will return an error message

  D. The adapter will be enabled, but the host will boot into troubleshooting mode the next time the host boots

  Correct Answer: A

• Question 49:

  A host failure occurs in vSphere HA cluster, but virtual machines from the failed host are not restarted on the surviving nodes in the cluster. Which two conditions explain this behavior? (Choose two)

  A. HA has been configured to use a dedicated failure host, and the failed host is designated failover host.

  B. An anti-affinity rule configured and restarting the VMs would place them on the same host.

  C. The virtual machines on the failed host are HA disabled.

  D. Host Monitoring is disabled

  Correct Answer: CD

• Question 50:

  An administrator receives a call indicating users reported extremely slow access to virtual machines the previous evening. Access to virtual machines performs as expected as checked by the administrator. Over the course of several days, the administrator continues to receive calls about the issue, which appears to occur at intermittent times each evening.

  Which step can be taken to collect information about the issue?

  A. Create a condition alarm to alert when Datastore Disk Usage (*) exceeds 70%

  B. Collect esxtop performance data in batch mode and analyze total number of I/O operations (CMDS/s) metrics

  C. Create an event alarm to alert when a storage device is disconnected

  D. Collect esxtop performance data in batch mode and analyze average device latency (DAVG/cm-d) metrics.

  Correct Answer: D
