VMware VMware Certifications VCP-510 Questions & Answers

• Question 31:

  What are two functions of zoning in Fibre Channel switches? (Choose two.)

  A. Controls and isolates LUNs on a Fibre Channel storage array

  B. Restrict connections on a storage array to ESXi hosts that use the array

  C. Prevents non-ESXi hosts from possibly destroying VMFS data

  D. Reduces the number of targets and LUNs presented by a Fibre Channel storage array

  Correct Answer: CD

• Question 32:

  What are the differences between Private and Public Cloud Computing?

  A. private cloud is provided to a single party, public is provided to public and organizations

  B. private cloud is managed by a single party and public cloud is managed by third-party

  C. private cloud is on-premises and public cloud is off-premises

  D. unknown choice

  Correct Answer: A

• Question 33:

  Which two circumstances would prevent the option of joining a Linked Mode group during vCenter Server installation? (Choose two).

  A. An administrator is installing the first of the vCenter Server instances.

  B. An administrator installed vCenter Server instances using different domain accounts.

  C. An administrator has vCenter Server instances in multiple domains

  D. An administrator is upgrading a VirtualCenter Server installation.

  Correct Answer: AD

• Question 34:

  Click the Exhibit button. In the process of troubleshooting the networking configuration on an ESXi 5.x host, you need to retrieve information for the network attached to vSwitch0.



  Using the exhibit, which selection would display CDP (Cisco Discovery Protocol) information for the desired network?

  A. Bubble labeled with the number 1

  B. Bubble labeled with the number 2

  C. Bubble labeled with the number 3

  D. Bubble labeled with the number 4

  Correct Answer: B

• Question 35:

  Your manager has requested that you look for ways to ensure that your storage is utilized evenly. Which feature of vSphere 5 would help achieve this request?

  A. sDRS

  B. profile driven storage

  C. VAAI

  D. thin provisioning

  Correct Answer: A

• Question 36:

  An administrator is upgrading an application running in a virtual machine. Before performing the upgrade a snapshot called pre-upgrade is created. NO other snapshots exist. The upgrade operation succeeds and the administrator wants to keep the changes from the snapshot. Which two operations can the administrator perform to ensure that the upgrade cannot be reverted? (Choose two)

  A. Use the Delete All option within the Snapshot Manager

  B. Use the Delete option within the Snapshot Manager

  C. Use the Consolidate option with the Snapshot Manager

  D. Use the Go To option in the snapshot

  Correct Answer: AB

• Question 37:

  When writes from a virtual machine are delivered to a Fibre Channel storage array, which two actions are taken by the VMkernel? (Choose two)

  A. The modified I/O request is sent from the physical HBA to the device driver.

  B. The file corresponding to the virtual machine is located on the VMFS datastores.

  C. The request for blocks on the virtual disk is mapped to blocks on the appropriate physical device.

  D. The I/O request is converted from binary data form to optical data from.

  Correct Answer: BC

• Question 38:

  Windows VM is experiencing the poor application performance. The suspected issue is a lack of available memory. Windows Task Manager shows 30% of the memory within the VM is not currently being used. What this indicate and what could be checked next?

  A. Windows Task Manager is not reading actual memory usage in the VM. Windows System Monitor should be used to get precise reading on memory usage.

  B. The application problems are defintely due to a non-memory related problem. CPU affinity settings should be checked for this VM.

  C. The VM has memory available, however it may not actually have "Physical" memory available. VMkernel swap activity on the ESX Server host should be checked next.

  D. The application problems are definitely due to a non-memory related problem. CPU utilization should be checked next using Windows Task Manager.

  Correct Answer: C

• Question 39:

  The remote console performance for a virtual machine on an ESXi host appears to be degraded. What are two possible causes of the problem? (Choose two)

  A. The virtual NIC assigned to the virtual machine has a speed or duplex mismatch.

  B. The physical NIC assigned to the virtual machine port group containing the affected virtual machine has a speed or duplex mismatch.

  C. The physical NIC assigned to the Service Console port group has a speed or duplex mismatch.

  D. The physical NIC assigned to the VMkernel port group has a speed or duplex mismatch.

  Correct Answer: BD

• Question 40:

  An administrator is cloning a vSphere 5 virtual machine. The resulting clone will be placed in a datastore cluster. The virtual machine requires high availability on high storage performance. Which option can be selected during the cloning process to meet these requirements?

  A. Change the format of the virtual disks to Flat

  B. Apply a VM Storage Profile

  C. Select Disable Storage DRS for this virtual machine

  D. Do not select a datastore cluster, manually select an appropriate datastore

  Correct Answer: B
